Table of Contents

Advertisement

Quick Links

Download this manual
2 0 1 5
P r o m a s t e r
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProMaster 2015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RAM Commercial ProMaster 2015

Summary of Contents for RAM Commercial ProMaster 2015

  • Page 1 2 0 1 5 P r o m a s t e r O W N E R ’ S M A N U A L...
  • Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or op- name Chrysler Canada Inc.

  • Page 3: Introduction 3

    TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .

  • Page 5: Table Of Contents

    INTRODUCTION CONTENTS INTRODUCTION ......4 VAN CONVERSIONS/CAMPERS ... .6 HOW TO USE THIS MANUAL .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained techni- Congratulations on selecting your new FCA US LLC cians and genuine parts, and cares about your satisfaction. vehicle. Be assured that it represents precision workman- ship, distinctive styling, and high quality - all essentials HOW TO USE THIS MANUAL that are traditional to our vehicles.
  • Page 7 INTRODUCTION 5...

  • Page 8: Van Conversions/Campers

    6 INTRODUCTION WARNINGS AND CAUTIONS Operating instructions for the special equipment in- stalled by the conversion/camper manufacturer should This Owner’s Manual contains WARNINGS against also be supplied with your vehicle. If these instructions operating procedures that could result in a collision or are missing, please contact your authorized dealer for bodily injury.

  • Page 9: Vehicle Modifications/Alterations

    INTRODUCTION 7 frame and underbody as well as the Automobile Infor- VEHICLE MODIFICATIONS/ALTERATIONS mation Disclosure Label affixed to a window on your vehicle, the vehicle registration and title. WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.
  • Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ To Arm The System .....15 A WORD ABOUT YOUR KEYS ... . .11 ▫...
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Child Restraints ..... . .52 POWER DOOR LOCKS ....20 ▫...

  • Page 13: A Word About Your Keys

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 A WORD ABOUT YOUR KEYS The Key Fob contains the Remote Keyless Entry (RKE) transmitter with an integrated key. To use the mechanical key, simply push the mechanical key release button. The vehicle is supplied with a code card containing key code numbers to order duplicate keys, and the autho- rized studio that sold you your new vehicle has the key code numbers for your vehicle locks.
  • Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK and re- move the Key Fob from the vehicle. When leaving the vehicle, always lock your vehicle. •...

  • Page 15: Locking Doors With A Key

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key-In-Ignition Reminder WARNING! (Continued) Opening the driver’s door when the key is in the ignition • Do not leave children or animals inside parked and the ignition switch position is OFF/LOCK sounds a vehicles in hot weather.

  • Page 16: Replacement Keys

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key which has not been programmed is also Replacement Keys considered an invalid key, even if it is cut to fit the NOTE: Only keys that have been programmed to the ignition switch lock cylinder for that vehicle.

  • Page 17: Vehicle Security Alarm - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 • This device must accept any interference that may be Rearming Of The System received, including interference that may cause unde- If the system has not been disabled, the Vehicle Security sired operation. Alarm will rearm itself after the 15 additional minutes of turn lamps flashing.

  • Page 18: Security System Manual Override

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Vehicle Security Alarm will also disarm if a pro- ILLUMINATED ENTRY grammed Sentry Key® is inserted into the ignition switch. The courtesy lights will turn on when you use the To exit the alarming mode, push the RKE transmitter Remote Keyless Entry (RKE) transmitter or manually UNLOCK button, or insert a programmed Sentry Key®...

  • Page 19: Remote Keyless Entry (Rke)

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 REMOTE KEYLESS ENTRY (RKE) This system allows you to lock or unlock the doors from distances up to approximately 66 ft (20 m) using a hand-held Remote Keyless Entry (RKE) transmitter. The RKE transmitter does not need to be pointed at the vehicle to activate the system.

  • Page 20: To Lock The Doors

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Doors The recommended replacement battery is CR2032. Push and release the LOCK button on the RKE transmit- 1. Push the mechanical key release button and release the ter to lock all doors. The turn signal lights will flash to mechanical key to access the battery case screw lo- acknowledge the signal;...

  • Page 21: General Information

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 3. Take out the battery case. Remove and replace the NOTE: Changes or modifications not expressly approved battery observing its polarity. by the party responsible for compliance could void the user’s authority to operate the equipment. 4.
  • Page 22 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE POWER DOOR LOCKS The load compartment power door lock switch is located on the driver door trim panel. Use this switch to lock or The central LOCK/UNLOCK button has an LED that unlock the load compartment doors.
  • Page 23 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 WARNING! WARNING! (Continued) • Never leave children alone in a vehicle, or with • Do not leave children or animals inside parked access to an unlocked vehicle. Allowing children to vehicles in hot weather. Interior heat build-up may be in a vehicle unattended is dangerous for a cause serious injury or death.

  • Page 24: Automatic Door Locks

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks The auto door lock feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 12 mph (20 km/h). The auto door lock feature can be enabled or disabled through the EVIC or the Uconnect®...

  • Page 25: Wind Buffeting

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 To open the window part way, push the window switch WARNING! and release it when you want the window to stop. • Never leave children alone in a vehicle, or with NOTE: The power window switches remain active for up access to an unlocked vehicle.

  • Page 26: Occupant Restraints Systems

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS SYSTEMS 2. If a child from 2 to 12 years old (not in a rear-facing child restraint) must ride in the front passenger seat, Some of the most important safety features in your move the seat as far back as possible and use the vehicle are the restraint systems: proper child restraint (Refer to “Child Restraints”).

  • Page 27: Seat Belt Systems

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 6. All occupants should always wear their lap and WARNING! shoulder belts properly. • Never place a rear-facing child restraint in front of 7. The driver and front passenger seats should be moved an air bag.
  • Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they The BeltAlert warning sequence begins after the vehicle can reduce the seriousness of injuries in a collision. Some speed is over 5 mph (8 km/h) by blinking the Seat Belt of the worst injuries happen when people are thrown Reminder Light and sounding an intermittent chime.
  • Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 pets be restrained in the rear seat (if equipped) in pet normal conditions. However, in a collision the seat belt harnesses or pet carriers that are secured by seat belts, will lock and reduce your risk of striking the inside of the and cargo is properly stowed.
  • Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • It is dangerous to ride in a cargo area, inside or • Two people should never be belted into a single outside of a vehicle. In a collision, people riding in seat belt.
  • Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 WARNING! (Continued) WARNING! (Continued) • A seat belt that is buckled into the wrong buckle bones. Wear the seat belt over your shoulder so that will not protect you properly. The lap portion could your strongest bones will take the force in a colli- ride too high on your body, possibly causing inter- sion.
  • Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, and next to your arm in the rear seat (for vehicles equipped with a rear seat).
  • Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Inserting Latch Plate Into Buckle Positioning The Lap Belt 4. Position the lap belt so that it is snug and lies low 5. Position the shoulder belt across the shoulder and across your hips, below your abdomen. To remove chest with minimal, if any slack so that it is comfort- slack in the lap belt portion, pull up on the shoulder able and not resting on your neck.
  • Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the seat belt, push the red button on the 3. Slide the latch plate upward over the folded webbing. buckle. The seat belt will automatically retract to its The folded webbing must enter the slot at the top of stowed position.
  • Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 Adjustable Anchorage Adjustable Anchorage As a guide, if you are shorter than average, you will NOTE: The adjustable upper shoulder belt anchorage is prefer the shoulder belt anchorage in a lower position, equipped with an Easy Up feature.
  • Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts And Pregnant Women NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be We recommend that pregnant women use the seat belts worn snugly and positioned properly.
  • Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Automatic Locking Retractor (ALR) The seat belt in the passenger seating position is equipped with a Switchable Automatic Locking Retractor (ALR) which is used to secure a child restraint system. For additional information, refer to “Installing Child Restraints Using The Vehicle Seat Belt”...
  • Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the passenger seating position is equipped with an ALR and is being used for normal usage, only pull the seat belt webbing out far enough to comfortably wrap around the occupant’s mid-section so as to not activate the ALR.
  • Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 How To Disengage The Automatic Locking Mode WARNING! Unbuckle the combination lap/shoulder belt and allow it • Never place a rear-facing child restraint in front of to retract completely to disengage the Automatic Locking an air bag.

  • Page 40: Supplemental Restraint System (Srs)

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Knee Impact Bolsters WARNING! (Continued) • Advanced Front Air Bags • Do not use the Automatic Locking Mode to restrain occupants who are wearing the seat belt or children • Supplemental Side Air Bags who are using booster seats.
  • Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 WARNING! • Being too close to the steering wheel or instrument panel during Advanced Front Air Bag deployment could cause serious injury, including death. Air bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel.
  • Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bag Features WARNING! The Advanced Front Air Bag system has multistage • No objects should be placed over or near the air driver and front passenger air bags. This system provides bag on the instrument panel or steering wheel, output appropriate to the severity and type of collision as because any such objects could cause harm if the...
  • Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Advanced Front Air Bag Operation Seat belts are necessary for your protection in all colli- sions, and also are needed to help keep you in position, Advanced Front Air Bags are designed to provide addi- away from an inflating air bag.
  • Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Knee Impact Bolsters Supplemental Side Air Bags The Knee Impact Bolsters help protect the knees of the Your vehicle is equipped with two types of supplemental Side Air Bags: driver and front passenger, and position the front occu- •...
  • Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 • Supplemental Side Air Bag Inflatable Curtains The SABs may help to reduce the risk of occupant injury (SABICs): Located above the side windows. The trim during certain side impacts, in addition to the injury covering the SABICs is labeled “SRS AIRBAG”...
  • Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SABICs may help reduce the risk of head injury to front WARNING! and rear seat outboard occupants in certain side impacts. • Your vehicle is equipped with left and right Supple- SABICs may reduce the risk of injuries in certain side impacts, in addition to the injury reduction potential mental Side Air Bag Inflatable Curtains (SABICs).
  • Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 The SABICs and SABs (“Side Air Bags”) are designed to angled or offset frontal collisions where the Advanced Front Air Bags deploy. activate in certain side impacts. The Occupant Restraint Controller (“ORC”) determines whether the deployment Side Air Bags are a supplement to the seat belt restraint of the Side Air Bags in a particular impact event is system.
  • Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If A Deployment Occurs WARNING! The Advanced Front Air Bags are designed to deflate • Side Air Bags need room to inflate. Do not lean immediately after deployment. against the door or window. Sit upright in the NOTE: Front and/or side air bags will not deploy in all center of the seat.
  • Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 • As the air bags deflate, you may see some smoke-like WARNING! particles. The particles are a normal by-product of the process that generates the non-toxic gas used for air Deployed air bags and seat belt pretensioners cannot bag inflation.
  • Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Accident Response System Air Bag Warning Light In the event of an impact, if the communication network The air bags must be ready to inflate for your remains intact, and the power remains intact, depending protection in a collision.
  • Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • The Air Bag Warning Light comes on intermittently or ON/RUN position. After the self-check, the Air Bag Warning Light will turn off. If the ORC detects a mal- remains on while driving. function in any part of the system, it turns on the Air Bag NOTE: If the speedometer, tachometer, or any engine Warning Light, either momentarily or continuously.
  • Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Redundant Air Bag Warning Light Maintaining Your Air Bag System If a fault with the Air Bag Warning Light is WARNING! detected, which could affect the Supplemental Restraint System (“SRS”), the Redundant Air •...
  • Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Event Data Recorder (EDR) WARNING! (Continued) This vehicle is equipped with an event data recorder • Do not attempt to modify any part of your air bag (EDR). The main purpose of an EDR is to record, in system.

  • Page 54: Child Restraints

    52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE These data can help provide a better understanding of Child Restraints the circumstances in which crashes and injuries occur. Everyone in your vehicle needs to be buckled up at all times, including babies and children. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs;...
  • Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Before buying any restraint system, make sure that it has WARNING! a label certifying that it meets all applicable Safety Standards. You should also make sure that you can install In a collision, an unrestrained child can become a it in the vehicle where you will use it.
  • Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Infants and Toddlers Children who are two years old or Either an Infant Carrier or a Convertible younger and who have not reached Child Restraint, facing rearward in the the height or weight limits of their...
  • Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Infants And Child Restraints WARNING! Safety experts recommend that children ride rear-facing • Never place a rear-facing child restraint in front of in the vehicle until they are two years old or until they an air bag.
  • Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE have outgrown the rear-facing weight or height limit of WARNING! their rear-facing convertible child seat. Children should • Improper installation can lead to failure of an infant remain in a forward-facing child seat with a harness for as long as possible, up to the highest weight or height or child restraint.
  • Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Children Too Large For Booster Seats If the answer to any of these questions was “no,” then the child still needs to use a booster seat in this vehicle. If the Children who are large enough to wear the shoulder belt child is using the lap/shoulder belt, check seat belt fit comfortably, and whose legs are long enough to bend periodically and make sure the seat belt buckle is latched.
  • Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints in Commercial Vehicles WARNING! (Continued) This commercial vehicle is not designed for use as a passenger Air Bag. In a collision, a passenger Air Bag family vehicle and is not intended for carrying children may deploy causing severe injury or death to infants in the front passenger seat(s).
  • Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Front Bucket Seat Automatic Locking Retractor (ALR) Front Bench Seat Automatic Locking Retractor (ALR) Location Locations • ALR = Switchable Automatic Locking Retractor...
  • Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing a Child Restraint with a Switchable 6. Try to pull the webbing out of the retractor. If it is Automatic Locking Retractor (ALR): locked, you should not be able to pull out any web- bing.

  • Page 63: Transporting Pets

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Transporting Pets NOTE: After an accident, remember to cycle the ignition to the STOP (OFF/LOCK) position and remove the key Air Bags deploying in the front seat could harm your pet. from the ignition switch to avoid draining the battery. An unrestrained pet will be thrown about and possibly If no fuel leaks or damage to vehicle electrical devices injured, or injure a passenger during panic braking or in...

  • Page 64: Engine Break-In Recommendations

    62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Reactivating the fuel cut off switch: WARNING! 1. Push the button A to reactivate the fuel cut off switch. Before reactivating the fuel cut off switch, carefully check for fuel leaks or damage to vehicle electrical devices (e.g.

  • Page 65: Safety Tips

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 The engine oil installed in the engine at the factory is a SAFETY TIPS high-quality energy conserving type lubricant. Oil Transporting Passengers changes should be consistent with anticipated climate NEVER TRANSPORT PASSENGERS IN THE CARGO conditions under which vehicle operations will occur.

  • Page 66: Exhaust Gas

    64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the WARNING! engine running, adjust your heating or cooling Exhaust gases can injure or kill. They contain carbon controls to force outside air into the vehicle.

  • Page 67: Safety Checks You Should Make Inside The Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Safety Checks You Should Make Inside The is not lit during starting, see your authorized dealer. If the Vehicle light stays on, flickers, or comes on while driving, have the system checked by an authorized dealer. Seat Belts Defroster Inspect the seat belt system periodically, checking for cuts,...
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.

  • Page 69: Periodic Safety Checks You Should Make Outside The Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for proper closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
  • Page 71 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Swivel Seat — If Equipped....83 MIRRORS ......72 ▫...
  • Page 72 70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Headlights ......92 WINDSHIELD WIPERS AND WASHERS ..98 ▫...
  • Page 73 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 71 ▫ To Vary The Speed Setting ....103 OVERHEAD CONSOLE — IF EQUIPPED ..114 ▫ To Accelerate For Passing ....104 ▫...

  • Page 74: Mirrors

    72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).

  • Page 75: Outside Mirrors Folding Feature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73 Power Mirrors — If Equipped WARNING! The power mirror controls are located on the driver-side Vehicles and other objects seen in an outside convex door trim panel. mirror will look smaller and farther away than they really are.

  • Page 76: Heated Mirrors - If Equipped

    74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE switch. Tilt the control wand in the direction you want the mirror to move. When you are finished adjusting the mirror, turn the control to the center position “O” to prevent accidentally moving a mirror. Heated Mirrors —...
  • Page 77 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75 If the mirror head or pivot exhibits a slight amount of play, the mirror should be power folded closed, then power folded open (This may require multiple button pushes). NOTE: The intended use of the power fold mirrors is by pushing the buttons to fold and unfold the mirrors.

  • Page 78: Seats

    76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS Manual Front Seat Adjustments Seats are a part of the Occupant Restraint System of the The driver and passenger seats can be adjusted forward, vehicle. rearward, reclined, front and rear height and lumbar adjustments.
  • Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 Forward And Rearward Adjustment The adjusting bar is at the front of the seat, near the floor. Pull the bar upward to move the seat forward or rear- ward. Release the bar once the seat is in the desired position.
  • Page 80 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Height Adjustment (Without Swivel Seat) — If Equipped The height adjusting levers are located on the center outboard side of the seat. Lift up on the front lever to adjust the front of the seat up or down. Lift up on the rear lever to adjust the rear of the seat up or down.
  • Page 81 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 Height Adjustment (With Swivel Seat) — If Equipped The height adjusting knobs are located on the center outboard side of the seat. Rotate the front knob to adjust the front of the seat up or down. Rotate the rear knob to adjust the rear of the seat up or down.
  • Page 82 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Recliner Adjustment — Without Swivel Seat Recliner Adjustment — With Swivel Seat The recliner knob is on the rear outboard side of the seat. The recliner lever is located at the lower front outboard To recline the seatback, lean back, rotate the knob rearward side of the seat.
  • Page 83 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 84: Air Seat - If Equipped

    82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Air Seat — If Equipped The seat is equipped with a mechanical spring system and hydraulic shock absorber to ensure maximum com- fort and safety. The system of springs also effectively absorbs impact from uneven road surfaces. Damper Weight Adjustment Use the weight adjustment knob to set the required setting based on body weight, with settings between...

  • Page 85: Swivel Seat - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Swivel Seat — If Equipped If the driver or the passenger seats are not locked in facing forward position before the first vehicle move- The swivel seat lever is located at the lower front inboard ment, shifting out of park is not allowed until the seats side of the seat.

  • Page 86: Flap On Bench - If Equipped

    84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If a fault is present in the system and it is not possible to Flap On Bench — If Equipped check the correct position of the swivel seats, a message If your vehicle is equipped with a bench seat, the seat is and the generic warning light appears in the EVIC to equipped with a fold-down flap that can be used as a inform about the failure.

  • Page 87: Underseat Storage Tray (Driver Side Only) - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 The fold-down flap is equipped with two cup holders Underseat Storage Tray (Driver Side Only) — and a support surface with a paper holder clip. If Equipped A storage tray is located under the drivers seat that can be easily removed by withdrawing the hooks on the support base.

  • Page 88: Heated Seats - If Equipped

    86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped Push the switch once to turn on the heated seats. Push the switch a second time to shut the heating elements off. On some models, the front driver and passenger seats may be equipped with heaters in both the seat cushions NOTE: Once a heat setting is selected, heat will be felt and seatbacks.

  • Page 89: Head Restraints

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 WARNING! (Continued) WARNING! (Continued) in a seat that has been overheated could cause Driving a vehicle with the head restraints improperly serious burns due to the increased surface tempera- adjusted or removed could cause serious injury or ture of the seat.
  • Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • A loose head restraint thrown forward in a colli- sion or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment.

  • Page 91: Adjustable Armrests - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Adjustable Armrests — If Equipped Turn the adjuster wheel to the right or left to adjust the height of the armrest up or down. The seat adjustable armrest can be raised and adjusted for height.

  • Page 92: To Open And Close The Hood

    90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD 2. Move to the outside of the vehicle, reach into the opening beneath the center of the hood and push the To open the hood, two latches must be released. safety latch lever to the right to release it, before 1.
  • Page 93 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 3. Raise the hood and place the hood prop rod in hood CAUTION! slot to secure the hood in the open position. To prevent possible damage: • Before closing hood, make sure the hood prop rod is fully seated into its storage retaining clips.

  • Page 94: Lights

    92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlights Multifunction Lever To turn on the headlights, turn the end of the The multifunction lever controls the operation of the multifunction lever to the headlight position. headlights, parking lights, turn signals, headlight beam When the headlight switch is on, the parking selection and the passing lights.

  • Page 95: Daytime Running Lights - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 Daytime Running Lights — If Equipped NOTE: When the headlights are turned on, the Daytime Running Lights will be deactivated. To activate the Daytime Running Lights (DRL), rotate the end of the multifunction lever to the O (Off) position. NOTE: The low beams and side/taillights will not be on with DRL.

  • Page 96: Battery Saver

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Battery Saver NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside To protect the life of your vehicle’s battery when the light bulb.

  • Page 97: High Beam/Low Beam Select Switch

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 High Beam/Low Beam Select Switch is pulled, the activation of the lights will be extended by 30 seconds. The activation of the lights can be extended to Pull the multifunction lever toward you to switch the a maximum of 210 seconds.

  • Page 98: Map/Dome/Lights

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Map/Dome/Lights These lights are mounted between the sun visors on the overhead console. Each light is turned on by pushing the corresponding switch. Left Switch • Push the left switch to the left to turn OFF the auto dome lights.

  • Page 99: Cargo Lamp

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Cargo Lamp Your vehicle may be equipped with a Side Cargo Lamp located at the upper rear area of the passenger side The Rear Cargo Lamp is located at the upper rear cargo sliding door opening.

  • Page 100: Windshield Wipers And Washers

    98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Cargo Lamps can be set to three different positions NOTE: The windshield wipers/washers will only oper- (Off/Right Position, Center Position, On/Left Position). ate with the ignition in the ON/RUN position. • Push the Cargo Lamp lens to the right from its center position and the lamp is always off.

  • Page 101: Intermittent Wiper System

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Intermittent Wiper System NOTE: The mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the Push the lever downward to the first detent and rotate windshield. The wash function must be used in order to the center ring to use one of the four intermittent wiper spray the windshield with washer fluid.

  • Page 102: Telescoping Steering Column

    100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use. TELESCOPING STEERING COLUMN This feature allows you to lengthen or shorten the steering column.

  • Page 103: Electronic Speed Control

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.

  • Page 104: To Activate

    102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate To Set A Desired Speed Rotate the center ring upward on the electronic speed Turn the Electronic Speed Control ON. When the vehicle control lever to turn the system ON. The Cruise Indicator has reached the desired speed, move the electronic speed Light in the instrument cluster will illuminate.

  • Page 105: To Resume Speed

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 To Resume Speed U.S. Speed (mph) • Tapping the Speed Control lever up (+) once will result To resume a previously set speed, push the RES button and release. Resume can be used at any speed above in a 1 mph increase in set speed.

  • Page 106: To Accelerate For Passing

    104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Decrease Speed Metric Speed (km/h) • Tapping the Speed Control lever down (-) once will When the Electronic Speed Control is set, you can decrease speed by tapping the Speed Control lever down (-). result in a 1 km/h decrease in set speed.

  • Page 107: Parksense® Rear Park Assist - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 NOTE: The Electronic Speed Control system maintains PARKSENSE® REAR PARK ASSIST — speed up and down hills. A slight speed change on IF EQUIPPED moderate hills is normal. The ParkSense® Rear Park Assist system provides an audible indication of the distance between the rear On steep hills, a greater speed loss or gain may occur so fascia/bumper and a detected obstacle when backing up,...

  • Page 108: Parksense® Rear Park Assist Sensors

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense® Rear Park Assist Sensors The four ParkSense® Rear Park Assist sensors, located in the rear fascia/bumper, monitor the area behind the vehicle that is within the sensors’ field of view. The sensors can detect obstacles, in the horizontal direction, from approximately 12 in (30 cm) up to 55 in (140 cm) from the center of the rear fascia/bumper and up to 24 in (60 cm) from the corners of the rear fascia/bumper,...

  • Page 109: Parksense® Rear Park Assist Alerts

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 ParkSense® Rear Park Assist Alerts between the tones are directly proportional to the dis- tance from the obstacle. Pulses emitted in quick succes- If an obstacle is behind the vehicle when REVERSE gear sion indicate the presence of a very close obstacle.

  • Page 110: Parksense® Rear Park Assist Failure Indications

    108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SIGNAL MEANING INDICATION Failure Sensor or System failures Visual Signal (instrument panel) • Icon appears on display. • Message is displayed on multifunction display (where provided). While audible signals are emitted, the audio system is not ParkSense®...

  • Page 111: Cleaning The Parksense® Rear Park Assist System

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 The sensors and wiring are tested continuously when the ParkSense® Rear Park Assist System Usage ignition is in the ON/RUN position. Failures are indi- Precautions cated immediately if they occur when the system is ON. NOTE: Even if the system is able to identify that a specific sensor •...
  • Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Objects such as bicycle carriers, etc., must not be CAUTION! (Continued) placed within 12 in (30 cm) from the rear fascia/ • The vehicle must be driven slowly when using bumper while driving the vehicle. Failure to do so can ParkSense®...

  • Page 113: Parkview® Rear Back Up Camera - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 PARKVIEW® REAR BACK UP CAMERA — WARNING! (Continued) IF EQUIPPED • Before using ParkSense®, it is strongly recom- Your vehicle may be equipped with the ParkView® Rear mended that the ball mount and hitch ball assem- Back Up Camera that allows you to see an on-screen bly is disconnected from the vehicle when the image of the rear surroundings of your vehicle whenever...
  • Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the vehicle is shifted out of REVERSE and/or when the rear doors are closed, the rear camera mode is exited and the navigation or audio screen appears again. When displayed, static grid lines will illustrate the width of the vehicle and will show separate zones that will help indicate the distance to the rear of the vehicle.
  • Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 NOTE: ParkView® Rear Back Up Camera can be enabled CAUTION! or disabled by Uconnect® system menu. • To avoid vehicle damage, ParkView® should only WARNING! be used as a parking aid. The ParkView® camera is unable to view every obstacle or object in your Drivers must be careful when backing up even when drive path.

  • Page 116: Overhead Console - If Equipped

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE — IF EQUIPPED Left Switch • Push the left switch to the left to turn OFF the auto The overhead console is located on the headliner above the review mirror. The overhead console contains the dome lights.

  • Page 117: Power Outlets - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 POWER OUTLETS — IF EQUIPPED Passenger Compartment Power Outlet The cigar lighter and the power socket are located in the center console. It only operates with the ignition key at MAR/ON. Map/Dome Lights 1 —...
  • Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Load Compartment Power Outlet The Load Compartment Power Outlet is located on the left rear side of the rear cargo compartment. The outlet can be is used for powering 12 Volt adaptive accessories and recharging communications devices.
  • Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of outlet power from the vehicle’s battery, even when not in should be inserted into any 12 Volt outlet.

  • Page 120: Cigar Lighter And Ash Receiver - If Equipped

    118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — CUPHOLDERS IF EQUIPPED The cupholders for the drivers and passenger area are A removable ash receiver and cigar lighter are available. located near the floor just under the center stack storage compartment.

  • Page 121: Storage

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 STORAGE Front Door Storage — If Equipped Glove Compartments Storage areas and bottle holders are located in both the front door trim panels. The glove compartments are located on the right side of the instrument panel.

  • Page 122: Dash Storage

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dash Storage Dashboard Clipboard The dash storage is located on the right side of the Located on top of the dashboard is a clipboard and two instrument panel. storage bins on each side of the clipboard. Dash Storage Clipboard And Storage Bins...

  • Page 123: Cargo Area Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 CARGO AREA FEATURES Cargo Area The cargo area may be equipped with different options such as a optional side panels, rear seats and an optional floor.
  • Page 125 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Trip Functions ..... . .147 INSTRUMENT PANEL FEATURES ..126 ▫...
  • Page 126 124 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ General......153 Uconnect® RADIOS .....180 ▫...
  • Page 127 UNDERSTANDING YOUR INSTRUMENT PANEL 125 ▫ Radio ......194 Uconnect® 5.0 VOICE RECOGNITION QUICK TIPS .

  • Page 128: Instrument Panel Features

    126 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 10 — Lower Glove Compartment 19 — Uconnect® Phone Buttons 2 — Multifunction Lever (External Lights) 11 — Cup Holder 20 — Tilt Steering Column Release Lever 3 — Instrument Cluster 12 —...

  • Page 129: Instrument Cluster

    UNDERSTANDING YOUR INSTRUMENT PANEL 127 INSTRUMENT CLUSTER...

  • Page 130: Instrument Cluster Descriptions

    128 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 3. Stop Light Failure Indicator 1. Speedometer This light will illuminate if one or more of the stop light bulb fails. The speedometer shows the vehicle speed in miles per hour (mph) and/or kilometers per hour (km/h). The failure relating to this light could be: •...
  • Page 131 UNDERSTANDING YOUR INSTRUMENT PANEL 129 NOTE: If the driver’s door is open, and the headlights or as it was before the repair or service. If s/he cannot do so, park lights are left on, the high beam indicator light will then the odometer must be set at zero, and a sticker must remain illuminated, and a chime will sound until lights be placed in the door jamb stating what the mileage was...
  • Page 132 130 UNDERSTANDING YOUR INSTRUMENT PANEL 8. External Light Failure Indicator — If Equipped 9. Vehicle Security Light The External Light Failure Indicator will come on when a If during starting, the key code is not correctly failure to one of the following lights is detected: recognized, the Vehicle Security Light comes •...
  • Page 133 UNDERSTANDING YOUR INSTRUMENT PANEL 131 11. Tachometer 14. Charging System Light — If Equipped The tachometer indicates engine speed in Revolutions This light shows the status of the electrical charg- Per Minute (RPM x 1000). ing system. The light should come on when the ignition switch is first turned to ON/RUN and remain on 12.
  • Page 134 132 UNDERSTANDING YOUR INSTRUMENT PANEL If the light remains on when the parking brake has been NOTE: The light may flash momentarily during sharp disengaged, and the fluid level is at the full mark on the cornering maneuvers, which change fluid level condi- master cylinder reservoir, it indicates a possible brake tions.
  • Page 135 UNDERSTANDING YOUR INSTRUMENT PANEL 133 Operation of the Brake Warning Light can be checked by testing, the light will come on when the ignition is first turning the ignition switch from the OFF position to the turned on and remain on, as a bulb check, until the ON/RUN position.
  • Page 136 134 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Temperature Gauge CAUTION! The temperature gauge shows engine coolant tempera- Prolonged driving with the Malfunction Indicator ture. Any reading within the normal range indicates that Light (MIL) on could cause damage to the engine the engine cooling system is operating satisfactorily.
  • Page 137 UNDERSTANDING YOUR INSTRUMENT PANEL 135 If the light turns on while driving, safely pull over and WARNING! stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the ve- A hot engine cooling system is dangerous. You or hicle.
  • Page 138 136 UNDERSTANDING YOUR INSTRUMENT PANEL when the engine is running, immediate service is re- 22. Fuel Gauge/Fuel Door Reminder quired, and you may experience reduced performance, When the ignition switch is in the ON/RUN an elevated/rough idle, or engine stall; your vehicle may position, the pointer will show the level of fuel require towing.
  • Page 139 UNDERSTANDING YOUR INSTRUMENT PANEL 137 24. Air Bag Warning Light a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should deter- This light will turn on for four to eight seconds mine the proper tire inflation pressure for those tires). as a bulb check when the ignition switch is first As an added safety feature, your vehicle has been turned to ON/RUN.
  • Page 140 138 UNDERSTANDING YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not The TPMS has been optimized for the original operating properly. The TPMS malfunction indicator is equipment tires and wheels. TPMS pressures and combined with the low tire pressure telltale.
  • Page 141 UNDERSTANDING YOUR INSTRUMENT PANEL 139 26. Seat Belt Reminder Light 28. Electronic Stability Control (ESC) Activation/ Malfunction Indicator Light When the ignition switch is first turned to ON/RUN, this light will turn on for four to The “ESC Activation/Malfunction Indicator eight seconds as a bulb check.
  • Page 142 140 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: 29. Anti-Lock Brake (ABS) Light • The “ESC Off Indicator Light” and the “ESC This light monitors the Anti-lock Brake System Activation/Malfunction Indicator Light” come on (ABS). The light will turn on when the ignition momentarily each time the ignition switch is turned switch is turned to the ON/RUN position and to ON/RUN.

  • Page 143: Electronic Vehicle Information Center (Evic)

    UNDERSTANDING YOUR INSTRUMENT PANEL 141 ELECTRONIC VEHICLE INFORMATION CENTER This system allows the driver to select a variety of useful (EVIC) information by pushing the switches mounted on the instrument panel. The EVIC Menu items consists of the The Electronic Vehicle Information Center (EVIC) fea- following: tures a driver-interactive display that is located in the •...
  • Page 144 142 UNDERSTANDING YOUR INSTRUMENT PANEL • Seat Belt Buzzer (*) • (*) just available after SBR disable made by CHR Service • Service (Diesel Only) • DRL - Daytime Running Light (if equipped) • Exit Menu The system allows the driver to select information by pushing the following buttons mounted on the instru- ment panel to the left of the steering column: EVIC Control Buttons...

  • Page 145: Electronic Vehicle Information Center (Evic) Setup Menu

    UNDERSTANDING YOUR INSTRUMENT PANEL 143 • UP Arrow Button The setup menu can be activated by pushing the MODE button. Single pushes on the UP or DOWN but- Push and release the UP arrow button to scroll tons will scroll through the setup menu options. The upward through the main menu and sub- menu items include the following functions: menus or adjust the illumination on the instru-...
  • Page 146 144 UNDERSTANDING YOUR INSTRUMENT PANEL • Seat Belt Buzzer (*) Selecting An Option Of The Main Menu Without • (*) just available after SBR disable made by CHR Submenu Service 1. Briefly push and release the MODE button to select •...

  • Page 147: Change Engine Oil Indicator System

    UNDERSTANDING YOUR INSTRUMENT PANEL 145 3. Briefly push and release the MODE button to select Change Engine Oil Indicator System the displayed submenu option and to open the rel- Change Engine Oil evant setup menu. Your vehicle is equipped with an engine oil change indi- 4.

  • Page 148: Trip Computer

    146 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Turn the ignition switch to the OFF/LOCK position. New Trip To reset: NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not • Push and hold the TRIP button to reset the system reset.

  • Page 149: Trip Functions

    UNDERSTANDING YOUR INSTRUMENT PANEL 147 • Instantaneous consumption Exit Trip • Average speed A To exit the Trip function, wait until all the values have been displayed or hold the MENU button for longer than • Travel time A (driving time) one second.

  • Page 150: Values Displayed

    148 UNDERSTANDING YOUR INSTRUMENT PANEL Values Displayed Average Economy This value shows the approximate average consumption Range since the last reset. This indicates the distance which may be traveled with the fuel remaining in the tank, assuming that driving Instant Economy conditions will not change.

  • Page 151: Personal Settings (Customer-Programmable Features)

    UNDERSTANDING YOUR INSTRUMENT PANEL 149 • Service (Diesel Only) Personal Settings (Customer-Programmable Features) • DRL - Daytime Running Light (if equipped) • Speed Beep • Exit menu • Trip B Data NOTE: • Set Time • If equipped with Uconnect® 5.0 radio, some cus- •...

  • Page 152: Uconnect® Rh3

    150 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® RH3 Recommendations Introduction Road Safety Your vehicle is equipped with a radio that has an We recommend that you learn how to use the various AM/FM radio receiver and a USB port for playing MP3, radio features (for example, Station Preset) before you WMA and AAC files.

  • Page 153: Identification Number

    UNDERSTANDING YOUR INSTRUMENT PANEL 151 Reception may be affected by mountains, buildings or Identification Number bridges, especially when further away from the transmit- The radio has a unique identification number (found on ter of the tuned radio station. the warranty card). This card is required as proof of ownership if the radio is stolen or when seeking assis- CAUTION! tance.

  • Page 154: Understanding Your Instrument Panel

    152 UNDERSTANDING YOUR INSTRUMENT PANEL You must enter the security (shown on the warranty Action Display card , for example, 4359) code as follows: Push the number 4 preset button 4 3 0 - until the fourth digit of the code Action Display number is displayed.

  • Page 155: General

    UNDERSTANDING YOUR INSTRUMENT PANEL 153 General General • Separate BASS and TREBLE settings The radio offers the following features: • BALANCE/FADE (balances left/right and front/rear Radio (Tuner Mode) channels) • Automatic/Manual station tuning • Equalizer • Manual storage of 30 stations: 18 in the FM band (6 in •...

  • Page 156: Uconnect® Rh3 Display

    154 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® RH3 Display Buttons: Station search in automatic mode, station search in manual mode, forward/reverse tracks, forward/reverse within track. Mute/Pause Button: Interrupts the sound by muting or pausing the audio. DISP Button: Switches between display modes, clock display.

  • Page 157: General Functions And Settings

    UNDERSTANDING YOUR INSTRUMENT PANEL 155 Buttons 1 And 2: Forward/reverse folder. turned on. If the ignition is turned off with the radio off, the radio continues to be turned off when the ignition is Band/AS Button: Select tuned frequency band, preset turned on again.
  • Page 158 156 UNDERSTANDING YOUR INSTRUMENT PANEL Equalizer display returns to the previously selected view and the settings will be saved. USER equalization must be Pushing the AUDIO button for more than two seconds selected to activate the Bass and Treble functions. activates the audio equalizer functions in the following sequence: FLAT...
  • Page 159 UNDERSTANDING YOUR INSTRUMENT PANEL 157 Balance Loudness The display will show the message BAL 00 to indicate The display will show LOUD 00 to indicate that you can that the balance function can be set. Turn the ROTARY set the loudness (enhanced sound) function. Turn the knob clockwise to transfer the sound to the right-hand ROTARY knob clockwise to enable the loudness function side;...

  • Page 160: Tuner Mode (Am/Fm Radio)

    158 UNDERSTANDING YOUR INSTRUMENT PANEL Tuner Mode (AM/FM Radio) Searching for Stations In Automatic Mode When you enter TUNER mode, the radio tunes to the When you push for less than two seconds, the most recently selected station and will remain on the radio will search for the next valid station.
  • Page 161 UNDERSTANDING YOUR INSTRUMENT PANEL 159 Hz for AM). When the search button is pushed and Pushing the button again restores the audio without held, the radio station frequency will continue to be changing the original volume setting. The display will increased or decreased.
  • Page 162 160 UNDERSTANDING YOUR INSTRUMENT PANEL Storing Stations In Memory Retuning the band: When the BAND/AS button is pushed for less than two seconds, the radio will alternate Push and hold the memory buttons (1 through 6) for between bands in the sequence: FM1 more than two seconds to associate the tuned station FM1.

  • Page 163: Setup Menu

    UNDERSTANDING YOUR INSTRUMENT PANEL 161 To record the stations that are found, these are sorted in (MVOL) Auto Switch (AUTO) Beep (BEEP) ascending order of frequency and the first one is stored in Set Clock Maximum Volume (MVOL). If this memory position 1, and so on, until positions 1-6 are all button or the button for adjusting the selected function in use.

  • Page 164: Clock

    162 UNDERSTANDING YOUR INSTRUMENT PANEL Auto Switch Clock This function changes the on/off sequence of the radio as Pushing the DISP button for more than two seconds described in the section: Turning the device on and off. enables or disables the clock display. When this feature is To enable it, turn the ROTARY knob clockwise.
  • Page 165 UNDERSTANDING YOUR INSTRUMENT PANEL 163 In USB mode, the radio plays MP3, WMA and AAC files CAUTION! (Continued) stored on the device connected to the USB port that is Due to the extensive range of makes and models of located on the lower right side of the steering wheel on storage devices available on the market, not all the instrument panel.
  • Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL If playable files are found, the radio will also check that the will start from the point where it was interrupted (file and connected device is the same as the one used immediately music runtime). If not, the file played will be the first valid before the USB function.
  • Page 167 UNDERSTANDING YOUR INSTRUMENT PANEL 165 Play Sequence (File) Comments Track 1_1 If there are MP3, WMA or AAC (extensions mp3, wma, m4a, mp4 and 3gp) files in the root folder, these will be played first. Track 2_1 Folders within the same level are sorted in ascending order by name (up to folder number 100, after which the order follows that in which they were Track 3_1 recorded on the USB device).
  • Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL Forward/Reverse Track this case, the display will show TRKyyy for two seconds and then return to the DISP function view. When you push for less than two seconds, the radio Whenever the radio switches from one folder to will advance to the next audio file on the device.
  • Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 runtime of the music in the format 003 01:32 (track Turn the ROTARY knob to resume playing the music and number and runtime). When the operation is com- change the volume accordingly. The display will feature pleted, the display will continue to display the music the information described in the volume function.
  • Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL ID3 tag is not processed. As the knob is turned, the Forward/Reverse Folder TRKyyy message changes to the track selected. When you push the memory 1 button, the radio will When the ROTARY knob is pushed or if its position is not advance to the first track in the next folder containing changed for five seconds, the track is selected, the ID3 tag audio files, if you push button 2, the radio will return to...
  • Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 Whenever the radio skips from one folder to another, the If the RND function is enabled, the music forward/ reverse will be random, both in normal mode and Fast display will show the name of the folder to which you are Track mode.

  • Page 172: Uconnect® Settings

    170 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® SETTINGS The Uconnect® system uses a combination of buttons on the touchscreen and buttons on the faceplate located on the center of the instrument panel that allows you to access and change the customer programmable features. Many features can vary by vehicle.

  • Page 173: Buttons On The Faceplate

    UNDERSTANDING YOUR INSTRUMENT PANEL 171 Buttons On The Faceplate Buttons on the faceplate are located below the Uconnect® system in the center of the instrument panel. In addition, there is a Scroll/Enter control knob located on the right side. Turn the control knob to scroll through menus and change settings (i.e., 30, 60, 90), push the center of the control knob one or more times to select or change a setting (i.e., ON, OFF).

  • Page 174: Buttons On The Touchscreen

    172 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons On The Touchscreen When making a selection, press the button on the touch- screen to enter the desired mode. Once in the desired Buttons on the touchscreen are accessible on the Uconnect® mode, press and release the preferred setting. Once the display.
  • Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 • Display Brightness With Headlights ON the Set Language button on the touchscreen, then press the desired language button. The button will highlight This feature allows you to select the display brightness showing that setting has been selected. Press the arrow when the headlights are on.
  • Page 176 174 UNDERSTANDING YOUR INSTRUMENT PANEL • Units — If Equipped Clock & Date After pressing the Clock button on the touchscreen the Press the Units button to select the correct unit for following settings will be available: Temperature (°F or °C), Distance (mi or km) and Fuel Consumption.
  • Page 177 UNDERSTANDING YOUR INSTRUMENT PANEL 175 hours up or down. Press the back arrow/Done button on highlight showing that setting has been selected. Press the touchscreen to return to the previous menu or press the back arrow/Done button on the touchscreen to return the ”X”...
  • Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL Safety/Assistance had been selected. Press the arrow back/Done button on the touchscreen to return to the previous menu. After pressing the Safety/Assistance button on the touch- • ParkView® Backup Camera Delay screen the following settings will be available: •...
  • Page 179 UNDERSTANDING YOUR INSTRUMENT PANEL 177 • Equalizer Doors & Locks After pressing the “Doors & Locks” button on the touch- This feature allows you to adjust the Bass, Mid and Treble screen the following settings will be available: settings. Adjust the settings with the “–” or “+” arrow buttons on the touchscreen or by selecting any point on •...
  • Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL • Loudness — If Equipped button on the touchscreen, choose a level from –3 to +3 followed by pressing the back arrow/Done button on the Loudness improves sound quality at lower volumes. To touchscreen. make your selection, press the “Loudness” button on the •...
  • Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 • Paired Audio Sources • Subscription Information This feature shows which audio devices are paired to the New vehicle purchasers or lessees will receive a free Phone/Bluetooth® system. For further information, refer limited time subscription to SiriusXM Satellite Radio to the Uconnect®...

  • Page 182: Uconnect® Radios

    180 UNDERSTANDING YOUR INSTRUMENT PANEL Restore Settings — If Equipped iPod®/USB/MP3 CONTROL — IF EQUIPPED The USB Input and Auxiliary Jack is located on the After pressing the Restore Settings button on the touch- instrument panel left of the radio (driver’s lower right). screen the following settings will be available: This feature allows an iPod®...

  • Page 183: Usb Charging Port

    UNDERSTANDING YOUR INSTRUMENT PANEL 181 iPod® control supports Mini, 4G, Photo, Nano, 5G iPod® and iPhone® devices. Some iPod® software versions may not fully support the iPod® control features. Please visit Apple’s website for software updates. For further information, refer to the Uconnect® Supple- ment Manual.

  • Page 184: Steering Wheel Audio Controls

    182 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! Do not plug in or remove the iPod® or external device while driving. Failure to follow this warning could result in a collision. STEERING WHEEL AUDIO CONTROLS The remote sound system controls are located on the surface of the steering wheel.

  • Page 185: Radio Operation

    UNDERSTANDING YOUR INSTRUMENT PANEL 183 The following describes the right-hand control operation 3. Do not apply paper or tape to the disc; avoid scratch- in each mode. ing the disc. Radio Operation 4. Do not use solvents such as benzene, thinner, cleaners, or anti-static sprays.

  • Page 186: Radio Operation And Mobile Phones

    184 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND MOBILE PHONES General Information Under certain conditions, the mobile phone being on in This device complies with Part 15 of the FCC rules and your vehicle can cause erratic or noisy performance from RSS 210 of Industry Canada.

  • Page 187: Climate Controls

    UNDERSTANDING YOUR INSTRUMENT PANEL 185 CLIMATE CONTROLS The Manual Temperature Controls consist of a series of three outer rotary dials (blower speed, temperature and Manual Heating And Air Conditioning mode) and three inner push buttons (Recirculation, A/C, Rear Window Defroster). Blower Control Rotate this control to regulate the amount of air forced through the ven-...
  • Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Air Conditioning Control Push this button to engage the Air Con- Rotate this control to regulate the tem- ditioning. A light will illuminate when perature of the air inside the passenger the Air Conditioning system is engaged. compartment.
  • Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 • Bi-Level Mode Control (Air Direction) Rotate this control to choose from sev- Air is directed through the panel and floor outlets. eral patterns of air distribution. You can select either a primary mode as NOTE: For all settings, except full cold or full hot, there identified by the symbols on the con- is a difference in temperature between the upper and...
  • Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL • Mix Recirculation Control Air is directed through the floor, defrost, and side Pushing the Recirculation Control button will window demist outlets. This setting works best in put the system in recirculation mode. This can cold or snowy conditions that require extra heat to the be used when outside conditions such as windshield.
  • Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 Recirculated air is not allowed in Defrost modes. If the Rear Window Defrosting Recirculation button is pushed while in Defrost mode, Push the Rear Defrost button to activate heated rear the LED indicator will flash several times then go out. window defrosting.
  • Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL Additional Rear Climate Control — If Equipped This switch, mounted on the instrument panel to the left of the steering column, activates the additional rear heating/air conditioning system vent. NOTE: The switch must be enabled for operation by the Upfitter.

  • Page 193: Uconnect® 5.0 Voice Recognition

    UNDERSTANDING YOUR INSTRUMENT PANEL 191 Uconnect® 5.0 VOICE RECOGNITION QUICK TIPS Introducing Uconnect® Start using Uconnect® Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect® 5.0 system.

  • Page 194: Get Started

    192 UNDERSTANDING YOUR INSTRUMENT PANEL Get Started All you need to control your Uconnect® system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing in- structions.

  • Page 195: Basic Voice Commands

    UNDERSTANDING YOUR INSTRUMENT PANEL 193 Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect® system. Push the VR button . After the beep, say • Cancel to stop a current voice session •...

  • Page 196: Radio

    194 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio® stations you would like to hear. (Sub- scription or included SiriusXM Satellite Radio trial re- quired.) Push the VR button .

  • Page 197: Media

    UNDERSTANDING YOUR INSTRUMENT PANEL 195 Media TIP: Press the “Browse” button on the touchscreen to see all of the music on your iPod® or USB device. Your Voice Uconnect® offers connections via USB, SD, Bluetooth® Command must match exactly how the artist, album, and Auxiliary ports (If Equipped).

  • Page 198: Voice Text Reply

    196 UNDERSTANDING YOUR INSTRUMENT PANEL Voice Text Reply PRE-DEFINED VOICE TEXT REPLY RESPONSES Uconnect® will announce incoming text messages. Push Yes. Stuck in traffic. See you later. the PHONE button and say Listen. (Must have Start without I’ll be late. compatible mobile phone paired to Uconnect®...

  • Page 199: Additional Information

    UNDERSTANDING YOUR INSTRUMENT PANEL 197 Additional Information © 2014 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc.
  • Page 201 STARTING AND OPERATING CONTENTS ▫ Brake/Transmission Shift Interlock System . . .206 STARTING PROCEDURES ....202 ▫ Automatic Transmission — If Equipped ..202 ▫...
  • Page 202 200 STARTING AND OPERATING PARKING BRAKE ..... .221 TIRES — GENERAL INFORMATION ..245 ▫...
  • Page 203 STARTING AND OPERATING 201 ▫ Carbon Monoxide Warnings ... . .269 TIRE ROTATION RECOMMENDATIONS ..259 TIRE PRESSURE MONITORING SYSTEM ADDING FUEL ......270 (TPMS) .

  • Page 204: Starting Procedures

    202 STARTING AND OPERATING STARTING PROCEDURES Automatic Transmission — If Equipped Before starting your vehicle, adjust your seat, adjust both The shift lever must be in the PARK or NEUTRAL inside and outside mirrors, and fasten your seat belts. position before you can start the engine. Depress the brake pedal before shifting to any driving gear.

  • Page 205: Extreme Cold Weather (Below -20°F Or −29°C)

    STARTING AND OPERATING 203 Extreme Cold Weather (Below –20°F Or −29°C) CAUTION! To ensure reliable starting at these temperatures, use of • Do not attempt to push or tow your vehicle to get it an externally powered electric engine block heater (avail- started.

  • Page 206: Engine Block Heater - If Equipped

    204 STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED AUTOMATIC TRANSMISSION The engine block heater warms the engine, and permits WARNING! quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a •...
  • Page 207 STARTING AND OPERATING 205 WARNING! (Continued) CAUTION! Once the key is removed, the transmission is Damage to the transmission may occur if the follow- locked in PARK, securing the vehicle against un- ing precautions are not observed: wanted movement. • Shift into or out of PARK or REVERSE only after •...

  • Page 208: Key Ignition Park Interlock

    206 STARTING AND OPERATING Key Ignition Park Interlock out of PARK, the ignition switch must be turned to the ON/RUN position (engine running or not), and the This vehicle is equipped with a Key Ignition Park Inter- brake pedal must be pressed. lock which requires the transmission to be in PARK NOTE: Swivel seats that are unlocked can also prevent before the ignition switch can be turned to the LOCK/...
  • Page 209 STARTING AND OPERATING 207 self-calibrating; therefore, the first few shifts on a new Only shift from DRIVE to PARK or REVERSE when the vehicle may be somewhat abrupt. This is a normal accelerator pedal is released and the vehicle is stopped. condition, and precision shifts will develop within a few Be sure to keep your foot on the brake pedal when hundred miles (kilometers).
  • Page 210 208 STARTING AND OPERATING NOTE: If the shift lever cannot be moved to the PARK, PARK (P) REVERSE, or NEUTRAL position (when pushed for- This range supplements the parking brake by locking the ward) it is probably in the ERS (+/-) position (beside the transmission.
  • Page 211 STARTING AND OPERATING 209 WARNING! WARNING! (Continued) someone or something. Only shift into gear when • Never use the PARK position as a substitute for the the engine is idling normally and your foot is parking brake. Always apply the parking brake firmly pressing the brake pedal.
  • Page 212 210 STARTING AND OPERATING The following indicators should be used to ensure that WARNING! (Continued) you have engaged the transmission into the PARK posi- • Never leave children alone in a vehicle, or with tion: access to an unlocked vehicle. Allowing children to •...
  • Page 213 STARTING AND OPERATING 211 CAUTION! (Continued) WARNING! • DO NOT race the engine when shifting from Do not coast in NEUTRAL and never turn off the PARK or NEUTRAL into another gear range, as this ignition to coast down a hill. These are unsafe can damage the drivetrain.
  • Page 214 212 STARTING AND OPERATING DRIVE (D) During cold temperatures, transmission operation may be modified depending on engine and transmission This range should be used for most city and highway temperature as well as vehicle speed. This feature im- driving. It provides the smoothest upshifts and down- proves warm up time of the engine and transmission to shifts, and the best fuel economy.
  • Page 215 STARTING AND OPERATING 213 PARK, REVERSE, and NEUTRAL will continue to oper- 6. Shift into the desired gear range. If the problem is no ate. The Malfunction Indicator Light (MIL) may be illu- longer detected, the transmission will return to normal minated.
  • Page 216 214 STARTING AND OPERATING You can switch between DRIVE and ERS mode at any To exit ERS mode, simply return the shift lever to the vehicle speed. When the shift lever is in the DRIVE DRIVE position. position, the transmission will operate automatically, shifting between all available gears.
  • Page 217 STARTING AND OPERATING 215 Overdrive Operation When To Use TOW/HAUL Mode The automatic transmission includes an electronically When driving in hilly areas, towing a trailer, carrying a controlled Overdrive (sixth gear). The transmission will heavy load, etc., and frequent transmission shifting oc- automatically shift into Overdrive if the following con- curs, push the TOW/HAUL switch to activate TOW/ ditions are present:...
  • Page 218 216 STARTING AND OPERATING Torque Converter Clutch seem as if the transmission is not shifting properly when cold. This is normal. Using the Electronic Range A feature designed to improve fuel economy has been Select (ERS) shift control, when the transmission is included in the automatic transmission on your vehicle.

  • Page 219: Driving On Slippery Surfaces

    STARTING AND OPERATING 217 DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.

  • Page 220: Driving Through Water

    218 STARTING AND OPERATING DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Cautions safety and prevent damage to your vehicle.
  • Page 221 STARTING AND OPERATING 219 CAUTION! CAUTION! (Continued) • Driving through standing water may cause damage • Always check the depth of the standing water to your vehicle’s drivetrain components. Always before driving through it. Never drive through inspect your vehicle’s fluids (i.e., engine oil, trans- standing water that is deeper than the bottom of mission, axle, etc.) for signs of contamination (i.e., the tire rims mounted on the vehicle.

  • Page 222: Power Steering

    220 STARTING AND OPERATING POWER STEERING This is due to the cold, thick fluid in the steering system. This noise should be considered normal, and it The standard power steering system will give you good does not in any way damage the steering system. vehicle response and increased ease of maneuverability in tight spaces.

  • Page 223: Parking Brake

    STARTING AND OPERATING 221 If necessary, add fluid to restore to the proper indicated CAUTION! level. With a clean cloth, wipe any spilled fluid from all surfaces. Refer to “Fluids, Lubricants, and Genuine Do not use chemical flushes in your power steering Parts”...
  • Page 224 222 STARTING AND OPERATING When parking on a hill, it is important to turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade. The parking brake should always be applied whenever the driver is not in the vehicle.

  • Page 225: Brake System

    STARTING AND OPERATING 223 WARNING! (Continued) CAUTION! • Do not leave the Key Fob in or near the vehicle or If the Brake Warning Light remains on with the in a location accessible to children. A child could parking brake released, a brake system malfunction operate power windows, other controls, or move is indicated.

  • Page 226: Electronic Brake Control System

    224 STARTING AND OPERATING In the event power assist is lost for any reason (i.e., Four-Wheel Anti-Lock Brake System (ABS) repeated brake applications with the engine off) the The Four-Wheel ABS is designed to aid the driver in brakes will still function. However, the effort required to maintaining vehicle control under adverse braking con- brake the vehicle will be much greater than that required ditions.

  • Page 227: Traction Control System (Tcs)

    STARTING AND OPERATING 225 When you are in a severe braking condition involving the WARNING! use of the ABS, you will experience some pedal drop as • Pumping the Anti-Lock Brakes will diminish their the vehicle comes to a stop. This is the result of the system reverting to the base brake system.

  • Page 228: Brake Assist System (Bas)

    226 STARTING AND OPERATING brake of the spinning wheel. This will allow more engine WARNING! (Continued) torque to be applied to the wheel that is not spinning. • The TCS cannot prevent collisions, including those This feature remains active even if the ESC is in the resulting from excessive speed in turns, or hydro- “Partial Off”...

  • Page 229: Electronic Stability Control (Esc)

    STARTING AND OPERATING 227 the system, you must apply continuous braking pressure Electronic Stability Control (ESC) during the stopping sequence. Do not reduce brake pedal The Electronic Stability Control (ESC) enhances direc- pressure unless braking is no longer desired. Once the tional control and stability of the vehicle under various brake pedal is released, the BAS is deactivated.
  • Page 230 228 STARTING AND OPERATING ESC Operating Modes WARNING! The “ESC Off” switch is located in the center The Electronic Stability Control System (ESC) cannot switch bank, next to the hazard flasher switch. prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions.
  • Page 231 STARTING AND OPERATING 229 Light” will be illuminated. When in the “Partial Off” WARNING! (Continued) mode, ESC will operate without engine torque manage- • Trailer Sway Control (TSC) is disabled when the ment. This mode is intended to be used if the vehicle is in ESC system is in the Partial Off mode.
  • Page 232 230 STARTING AND OPERATING running. If the “ESC Activation/Malfunction Indicator NOTE: Light” comes on continuously with the engine running, a • The “ESC Activation/Malfunction Indicator Light” malfunction has been detected in the ESC system. If this and the “ESC OFF Indicator Light” come on momen- light remains on after several ignition cycles, and the tarily each time the ignition switch is turned ON.

  • Page 233: Trailer Sway Control (Tsc)

    STARTING AND OPERATING 231 Trailer Sway Control (TSC) WARNING! TSC uses sensors in the vehicle to recognize an exces- If TSC activates while driving, slow the vehicle sively swaying trailer and will take the appropriate down, stop at the nearest safe location, and adjust the actions to attempt to stop the sway.
  • Page 234 232 STARTING AND OPERATING HSA Activation Criteria WARNING! The following criteria must be met in order for HSA to There may be situations on minor hills with a loaded activate: vehicle, or while pulling a trailer, when the system • Vehicle must be stopped. will not activate and slight rolling may occur.

  • Page 235: Tire Safety Information

    STARTING AND OPERATING 233 TIRE SAFETY INFORMATION WARNING! (Continued) Tire Markings brake pedal is released, there may not be enough brake pressure to hold the vehicle and trailer on a hill and this could cause a collision with another vehicle or object behind you. In order to avoid rolling down the hill while resuming acceleration, manually activate the trailer brake prior to releas- ing the brake pedal.
  • Page 236 234 STARTING AND OPERATING • Temporary spare tires are designed for temporary NOTE: emergency use only. Temporary high pressure com- • P (Passenger) — Metric tire sizing is based on U.S. pact spare tires have the letter “T” or “S” molded into design standards.
  • Page 237 STARTING AND OPERATING 235 Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or ..blank..= Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
  • Page 238 236 STARTING AND OPERATING EXAMPLE: R = Construction code – R means radial construction, or – D means diagonal or bias construction 15, 16, 18 = Rim diameter in inches (in) Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol –...

  • Page 239: Tire Identification Number (Tin)

    STARTING AND OPERATING 237 EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire: • XL = Extra load (or reinforced) tire, or • LL = Light load tire or •...
  • Page 240 238 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation – This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)

  • Page 241: Tire Terminology And Definitions

    STARTING AND OPERATING 239 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after Cold Tire Inflation Pressure the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.

  • Page 242: Tire Loading And Tire Pressure

    240 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Example Tire Placard Location (B-Pillar) Example Tire Placard Location (Door)
  • Page 243 STARTING AND OPERATING 241 Tire And Loading Information Placard 3. Tire size designed for your vehicle. 4. Cold tire inflation pressures for the front, rear, and spare tires. Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading...
  • Page 244 242 STARTING AND OPERATING To determine the maximum loading conditions of your 3. Subtract the combined weight of the driver and pas- vehicle, locate the statement “The combined weight of sengers from XXX lbs or XXX kg. occupants and cargo should never exceed XXX lbs or 4.
  • Page 245 STARTING AND OPERATING 243 NOTE: • If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. The follow- ing table shows examples on how to calculate total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and num- ber and size of occupants.
  • Page 246 244 STARTING AND OPERATING...

  • Page 247: Tires - General Information

    STARTING AND OPERATING 245 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.

  • Page 248: Tire Inflation Pressures

    246 STARTING AND OPERATING Fuel Economy WARNING! (Continued) Underinflated tires will increase tire rolling resistance • Unequal tire pressures from one side of the vehicle resulting in higher fuel consumption. to the other can cause the vehicle to drift to the right or left.
  • Page 249 STARTING AND OPERATING 247 At least once a month: been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours. • Check and adjust tire pressure with a good quality The cold tire inflation pressure must not exceed the pocket-type pressure gauge.

  • Page 250: Tire Pressures For High Speed Operation

    248 STARTING AND OPERATING Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) WARNING! during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. High speed driving with your vehicle under maxi- mum load is dangerous.

  • Page 251: Tire Types

    STARTING AND OPERATING 249 Tire Repair Tire Types If your tire becomes damaged, it may be repaired if it All Season Tires — If Equipped meets the following criteria: All Season tires provide traction for all seasons (spring, • The tire has not been driven on when flat. summer, fall and winter).
  • Page 252 250 STARTING AND OPERATING Summer tires do not contain the all season designation or If you need snow tires, select tires mountain/snowflake symbol on the tire sidewall. Use equivalent in size and type to the origi- summer tires only in sets of four; failure to do so may nal equipment tires.

  • Page 253: Run Flat Tires - If Equipped

    STARTING AND OPERATING 251 Run Flat Tires — If Equipped Spare Tires — If Equipped Run Flat tires allow you the capability to drive 50 miles NOTE: For vehicles equipped with Tire Service Kit (80 km) at 50 mph (80 km/h) after a rapid loss of inflation instead of a spare tire, please refer to “Tire Service Kit”...
  • Page 254 252 STARTING AND OPERATING rotation for your vehicle. If your vehicle has this option, Do not install a wheel cover or attempt to mount a refer to an authorized tire dealer for the recommended conventional tire on the compact spare wheel, since the tire rotation pattern.
  • Page 255 STARTING AND OPERATING 253 Full Size Spare — If Equipped tire affects vehicle handling. Since it is not the same as your original equipment tire, replace (or repair) the The full size spare is for temporary emergency use only. original equipment tire and reinstall on the vehicle at the This tire may look like the originally equipped tire on the first opportunity.

  • Page 256: Tire Spinning

    254 STARTING AND OPERATING Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires spin your vehicle’s wheels above 30 mph (48 km/h) or to help you in determining when your tires should be for longer than 30 seconds continuously without stop- replaced.

  • Page 257: Life Of Tire

    STARTING AND OPERATING 255 • Distance driven. These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth • Performance tires, tires with a speed rating of V or becomes a 1/16 of an inch (2 mm). When the tread is higher, and summer tires typically have a reduced worn to the tread wear indicators, the tire should be tread life.

  • Page 258: Replacement Tires

    256 STARTING AND OPERATING Replacement Tires affect your vehicle’s handling. If you ever replace a wheel, make sure that the wheel’s specifications match The tires on your new vehicle provide a balance of many those of the original wheels. characteristics. They should be inspected regularly for wear and correct cold tire inflation pressures.

  • Page 259: Tire Chains (Traction Devices)

    STARTING AND OPERATING 257 WARNING! (Continued) CAUTION! braking of your vehicle. This can cause unpredict- Replacing original tires with tires of a different size able handling and stress to steering and suspen- may result in false speedometer and odometer read- sion components.
  • Page 260 258 STARTING AND OPERATING WARNING! CAUTION! (Continued) • Install device as tightly as possible and then re- Using tires of different size and type (M+S, Snow) tighten after driving about ½ mile (0.8 km). between front and rear axles can cause unpredictable •...

  • Page 261: Tire Rotation Recommendations

    STARTING AND OPERATING 259 TIRE ROTATION RECOMMENDATIONS The suggested rotation method is the “rearward cross” shown in the following diagram. This rotation pattern The tires on the front and rear of your vehicle operate at does not apply to some directional tires that must not be different loads and perform different steering, driving, reversed.

  • Page 262: Tire Pressure Monitoring System (Tpms)

    260 STARTING AND OPERATING TIRE PRESSURE MONITORING SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low pressure warning The Tire Pressure Monitor System (TPMS) will warn the limit for any reason, including low temperature effects, or driver of a low tire pressure based on the vehicle recom- natural pressure loss through the tire.
  • Page 263 STARTING AND OPERATING 261 For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) tire pressure • The TPMS has been optimized for the original of 30 psi (207 kPa). If the ambient temperature is 68° F (20°...
  • Page 264 262 STARTING AND OPERATING • Driving on a significantly under-inflated tire causes CAUTION! (Continued) the tire to overheat and can lead to tire failure. • After inspecting or adjusting the tire pressure, Under-inflation also reduces fuel efficiency and tire always reinstall the valve stem cap. This will tread life, and may affect the vehicle’s handling and prevent moisture and dirt from entering the valve stopping ability.

  • Page 265: Base System

    STARTING AND OPERATING 263 Base System Tire Pressure Monitoring Low Pressure Warnings This is the TPMS warning indicator located in the The Tire Pressure Monitoring Telltale Light will illumi- instrument cluster. nate in the instrument cluster, an audible chime will be activated, and the “Check tire pressure”...
  • Page 266 264 STARTING AND OPERATING the “Tire Pressure Monitoring Unavailable” text message NOTE: Your vehicle is equipped with a regular size will display. If the ignition key is cycled, this sequence spare wheel. will repeat providing the system fault still exists. The Tire 1.

  • Page 267: General Information

    STARTING AND OPERATING 265 NOTE: For a correct Tire Pressure Monitoring behavior, FUEL REQUIREMENTS please wait for about 20 minutes in key-off during each 3.6L Engine tire substitution. General Information This engine is designed to meet all emis- This device complies with Part 15 of the FCC rules and sions regulations and provide excellent RSS 210 of Industry Canada.

  • Page 268: Reformulated Gasoline

    266 STARTING AND OPERATING Over 40 auto manufacturers worldwide have issued and Gasoline/Oxygenate Blends endorsed consistent gasoline specifications (the World- Some fuel suppliers blend unleaded gasoline with oxy- wide Fuel Charter, WWFC) which define fuel properties genates such as ethanol. necessary to deliver enhanced emissions, performance, and durability for your vehicle.

  • Page 269: E-85 Usage In Non-Flex Fuel Vehicles

    STARTING AND OPERATING 267 E-85 Usage In Non-Flex Fuel Vehicles MMT In Gasoline Non-Flex Fuel Vehicles (FFV) are compatible with gaso- Methylcyclopentadienyl Manganese Tricarbonyl (MMT) line containing up to 10% ethanol (E10). Gasoline with is a manganese-containing metallic additive that is higher ethanol content may void the New Vehicle Lim- blended into some gasoline to increase octane.

  • Page 270: Materials Added To Fuel

    268 STARTING AND OPERATING Materials Added To Fuel CAUTION! (Continued) All gasoline sold in the United States is required to • An out-of-tune engine or certain fuel or ignition contain effective detergent additives. Use of additional malfunctions can cause the catalytic converter to detergents or other additives is not needed under normal overheat.

  • Page 271: Carbon Monoxide Warnings

    STARTING AND OPERATING 269 NOTE: Intentional tampering with the emissions control WARNING! (Continued) system can result in civil penalties being assessed against a garage, and never sit in a parked vehicle with the you. engine running for an extended period. If the Carbon Monoxide Warnings vehicle is stopped in an open area with the engine running for more than a short period, adjust the...

  • Page 272: Adding Fuel

    270 STARTING AND OPERATING ADDING FUEL CAUTION! Fuel Filler Cap (Gas Cap) • Damage to the fuel system or emissions control The gas cap is located behind the fuel filler door on the system could result from using an improper fuel left side of the vehicle.

  • Page 273: Loose Fuel Filler Cap Message

    STARTING AND OPERATING 271 Loose Fuel Filler Cap Message WARNING! (Continued) If the vehicle diagnostic system determines that the fuel • Never add fuel when the engine is running. This is filler cap is loose, improperly installed, or damaged, a in violation of most state and federal fire regula- “Check fuel cap”...

  • Page 274: Vehicle Loading

    272 STARTING AND OPERATING • Vehicle Identification Number (VIN) VEHICLE LOADING • Type of Vehicle As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label • Month Day and Hour of Manufacture (MDH) affixed to the driver’s side door or B-Pillar. The bar code allows a computer scanner to read the VIN.
  • Page 275 STARTING AND OPERATING 273 Inflation Pressure WARNING! This is the cold tire inflation pressure for your vehicle for Because the front wheels steer the vehicle, it is all loading conditions up to full GAWR. important that you do not exceed the maximum front Curb Weight or rear GAWR.

  • Page 276: Trailer Towing

    274 STARTING AND OPERATING The best way to figure out the total weight of your have exceeded either GAWR, but the total load is within vehicle is to weigh it when it is fully loaded and ready for the specified GVWR, you must redistribute the weight. operation.

  • Page 277: Common Towing Definitions

    STARTING AND OPERATING 275 Common Towing Definitions The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight The following trailer towing related definitions will assist of the trailer must be supported by the scale. you in understanding the following information: Gross Axle Weight Rating (GAWR) Gross Vehicle Weight Rating (GVWR)
  • Page 278 276 STARTING AND OPERATING Tongue Weight (TW) If equipped, the electronic Trailer Sway Control (TSC) recognizes a swaying trailer and automatically applies The tongue weight is the downward force exerted on the individual wheel brakes and/or reduces engine power to hitch ball by the trailer.
  • Page 279 STARTING AND OPERATING 277 tow vehicle’s front axle and the trailer axle(s). When used WARNING! in accordance with the manufacturer’s directions, it pro- • An improperly adjusted Weight Distributing Hitch vides for a more level ride, offering more consistent steering and brake control thereby enhancing towing system may reduce handling, stability, braking safety.
  • Page 280 278 STARTING AND OPERATING Trailer Hitch Classification The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.
  • Page 281 STARTING AND OPERATING 279 Trailer Towing Weights (Maximum Trailer Weight which will cause loss of control of the vehicle and trailer. Ratings) Failure to load trailers heavier in front is the cause of many trailer collisions. NOTE: For additional trailer towing information (maxi- mum trailer weight ratings) refer to the following website Never exceed the maximum tongue weight stamped on addresses:...
  • Page 282 280 STARTING AND OPERATING Consider the following items when computing the Towing Requirements weight on the rear axle of the vehicle: To promote proper break-in of your new vehicle drivetrain • The tongue weight of the trailer. components, the following guidelines are recommended. •...
  • Page 283 STARTING AND OPERATING 281 WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the hook retainers of the vehicle hitch.
  • Page 284 282 STARTING AND OPERATING “Tires – General Information” in “Starting And Oper- WARNING! (Continued) ating” for proper tire inflation procedures. • Total weight must be distributed between the tow • Check the trailer tires for proper tire inflation pres- vehicle and the trailer such that the following four sures before trailer usage.
  • Page 285 STARTING AND OPERATING 283 Towing Requirements — Trailer Brakes WARNING! • Do not interconnect the hydraulic brake system or • Do not connect trailer brakes to your vehicle’s hy- vacuum system of your vehicle with that of the trailer. draulic brake lines. It can overload your brake sys- This could cause inadequate braking and possible tem and cause it to fail.
  • Page 286 284 STARTING AND OPERATING Towing Requirements — Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven- pin wiring harness.
  • Page 287 STARTING AND OPERATING 285 The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 —...

  • Page 288: Towing Tips

    286 STARTING AND OPERATING Towing Tips NOTE: Using a lower gear range while operating the vehicle under heavy loading conditions will improve Before setting out on a trip, practice turning, stopping, performance and extend transmission life by reducing and backing up the trailer in an area located away from excessive shifting and heat build up.
  • Page 289 STARTING AND OPERATING 287 Electronic Speed Control — If Equipped Cooling System • Do not use in hilly terrain or with heavy loads. To reduce potential for engine and transmission over- heating, take the following actions: • When using the speed control, if you experience speed City Driving drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.

  • Page 290: Recreational Towing (Behind Motorhome, Etc.)

    288 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Automatic Transmission Flat Tow NONE NOT ALLOWED Dolly Tow Front Rear NOT ALLOWED On Trailer NOTE: When recreationally towing your vehicle, always follow applicable state and provincial laws.

  • Page 291: Recreational Towing - Automatic Transmission

    STARTING AND OPERATING 289 Recreational Towing — Automatic Transmission CAUTION! Recreational towing is allowed ONLY if the front wheels • DO NOT flat tow this vehicle. Damage to the are OFF the ground. This may be accomplished using a drivetrain will result. If this vehicle requires tow- tow dolly or vehicle trailer.
  • Page 293 WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...293 JACKING AND TIRE CHANGING ..306 ▫ Jack Location......307 IF YOUR ENGINE OVERHEATS .
  • Page 294 292 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE ... . .328 TOWING A DISABLED VEHICLE ...330 ▫ Automatic Transmission ....331 SHIFT LEVER OVERRIDE .

  • Page 295: Hazard Warning Flashers

    WHAT TO DO IN EMERGENCIES 293 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the climate controls. potential for overheating by taking the appropriate action. •...

  • Page 296: Wheel And Tire Torque Specifications

    294 WHAT TO DO IN EMERGENCIES WHEEL AND TIRE TORQUE SPECIFICATIONS CAUTION! Proper lug nut/bolt torque is very important to ensure Driving with a hot cooling system could damage your that the wheel is properly mounted to the vehicle. Any vehicle.
  • Page 297 WHAT TO DO IN EMERGENCIES 295 Inspect the wheel mounting surface prior to mounting Tighten the lug nuts/bolts in a star pattern until each the tire and remove any corrosion or loose particles. nut/bolt has been tightened twice. Wheel Mounting Surface Torque Patterns After 25 miles (40 km) check the lug nut/bolt torque to be sure that all the lug nuts/bolts are properly seated...

  • Page 298: Tire Service Kit - If Equipped

    296 WHAT TO DO IN EMERGENCIES Tire Service Kit Components And Operation WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in personal injury.

  • Page 299: Tire Service Kit Usage Precautions

    WHAT TO DO IN EMERGENCIES 297 Using The Mode Select Knob And Hoses Using The Power Button Your Tire Service Kit is equipped with the following Push and release the Power Button (4) once to symbols to indicate the air or sealant mode. turn On the Tire Service Kit.
  • Page 300 298 WHAT TO DO IN EMERGENCIES from the vehicle or tire and wheel components. Once the sealant dries, it can easily be peeled off and properly discarded. • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the Tire Service Kit.
  • Page 301 WHAT TO DO IN EMERGENCIES 299 WARNING! WARNING! (Continued) • Keep Tire Service Kit away from open flames or • Do not attempt to seal a tire on the side of the heat source. vehicle closest to traffic. Pull far enough off the •...

  • Page 302: Sealing A Tire With Tire Service Kit

    300 WHAT TO DO IN EMERGENCIES on the ground. This will provide the best positioning WARNING! (Continued) of the kit when injecting the sealant into the deflated • Tire Service Kit Sealant solution contains latex. In tire and running the air pump. Move the vehicle as case of an allergic reaction or rash, consult a phy- necessary to place the valve stem in this position sician immediately.
  • Page 303 WHAT TO DO IN EMERGENCIES 301 4. Remove the cap from the valve stem and then screw NOTE: Sealant may leak out through the puncture in the the fitting at the end of the Sealant Hose (6) onto the tire. valve stem.
  • Page 304 302 WHAT TO DO IN EMERGENCIES NOTE: If the Mode Select Knob (5) is on Air Mode and If the tire does not inflate to at least 26 psi (1.8 Bar) the pump is operating, air will dispense from the Air pressure within 15 minutes: Pump Hose (7) only, not the Sealant Hose (6).
  • Page 305 WHAT TO DO IN EMERGENCIES 303 3. Immediately disconnect the Sealant Hose (6) from the (D) Drive Vehicle: valve stem, reinstall the cap on the fitting at the end of Immediately after injecting sealant and inflating the tire, the hose, and place the Tire Service Kit in the vehicle drive the vehicle 5 miles (8 km) or 10 minutes to ensure storage location.
  • Page 306 304 WHAT TO DO IN EMERGENCIES (E) After Driving: If the tire pressure is 19 psi (1.3 Bar) or higher: Pull over to a safe location. Refer to “Whenever You Stop 1. Push the Power Button (4) to turn on Tire Service Kit to Use Tire Service Kit”...
  • Page 307 WHAT TO DO IN EMERGENCIES 305 5. Remove the Speed Limit sticker from the instrument 4. Clean any remaining sealant from the Tire Service Kit panel after the tire has been repaired. housing. 6. Replace the Sealant Bottle (1) and Sealant Hose (6) 5.

  • Page 308: Jacking And Tire Changing

    306 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! (Continued) • Never start or run the engine while the vehicle is WARNING! on a jack. • Do not attempt to change a tire on the side of the •...

  • Page 309: Jack Location

    WHAT TO DO IN EMERGENCIES 307 Jack Location Removing The Spare Tire 1. Remove the spare tire before attempting to jack up the The jack and jack tools are stored under the front passenger vehicle. Attach the lug bolt adapter to the winch seat.
  • Page 310 308 WHAT TO DO IN EMERGENCIES Winch Location Winch Extension The winch mechanism is located under the rear of the 2. Rotate the wheel wrench handle counterclockwise vehicle to the right of the spare tire. until the spare tire is on the ground with enough cable slack to allow you to pull it out from under the vehicle.
  • Page 311 WHAT TO DO IN EMERGENCIES 309 NOTE: The winch mechanism is designed for use with 3. Pull the spare tire out from under the vehicle to gain the winch extension tube only. Use of an air wrench or access to the spare tire retainer. other power tools is not recommended and can damage the winch.
  • Page 312 310 WHAT TO DO IN EMERGENCIES 4. Remove the retainer nut prior to removing the retainer 5. Lift the spare tire with one hand to give clearance to from the wheel. tilt the retainer at the end of the cable. Retainer Nut Lifting Spare Tire...

  • Page 313: Preparations

    WHAT TO DO IN EMERGENCIES 311 6. Pull the retainer through the center of the wheel. Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic, pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 314: Jacking Instructions

    312 WHAT TO DO IN EMERGENCIES 5. Turn the ignition OFF. Jacking Instructions Block the front and rear of the wheel diagonally WARNING! opposite of the jacking position. For Carefully follow these tire changing warnings to help example, if changing the right front prevent personal injury or damage to your vehicle: tire, block the left rear wheel.
  • Page 315 WHAT TO DO IN EMERGENCIES 313 WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
  • Page 316 314 WHAT TO DO IN EMERGENCIES Assembled Jack Jacking Engagement Locations 1. Loosen (but do not remove) the wheel lug bolts by CAUTION! turning them to the left one turn while the wheel is still on the ground. Do not attempt to raise the vehicle by jacking on locations other than those indicated.
  • Page 317 WHAT TO DO IN EMERGENCIES 315 NOTE: The rear jacking location is located in front of the rear tire and in front of the leaf spring mount. Front Jacking Location WARNING! Rear Jacking Location NOTE: The front jacking location is located behind the Being under a jacked-up vehicle is dangerous.
  • Page 318 316 WHAT TO DO IN EMERGENCIES WARNING! (Continued) WARNING! under a vehicle that is on a jack. If you need to get Raising the vehicle higher than necessary can make under a raised vehicle, take it to a service center the vehicle less stable.
  • Page 319 WHAT TO DO IN EMERGENCIES 317 NOTE: Do not install the wheel cover on the spare tire. 7. Lower the vehicle by turning the jack screw to the left. 8. Refer to “Torque Specifications” in this section for proper wheel lug bolt torque. 9.
  • Page 320 318 WHAT TO DO IN EMERGENCIES Winch Mechanism Properly Engaged (Yellow DOT Will Winch Mechanism NOT Properly Engaged Appear In The Winch Indication Window) (Black Window Will Appear)
  • Page 321 WHAT TO DO IN EMERGENCIES 319 CAUTION! WARNING! In the case that the yellow dot does not appear in the A loose tire or jack thrown forward in a collision or winch mechanism window refer to step 11 above, the hard stop could endanger the occupants of the ve- operator should repeat the spare tire instillation hicle.
  • Page 322 320 WHAT TO DO IN EMERGENCIES For vehicles with aluminum wheels: 3. Tighten the knob on the bolt to secure it to the bracket. 1. Remove the adapter bracket and bolts from the storage bag in the glove compartment. 2. Take the retainer and position it inside the circular bracket.
  • Page 323 WHAT TO DO IN EMERGENCIES 321 Alloy Wheel Mounting Wheel/Bolts Attaching To Mounting Bracket 4. Position the tire vertically and lay the mounted 5. Follow the steps above for proper spare tire stowage. adapter on the inner part of the rim, using the sup- plied bolts fasten the wheel to the adapter using the bolt install wrench.

  • Page 324: Wheel Covers

    322 WHAT TO DO IN EMERGENCIES Wheel Covers NOTE: When using a portable battery booster pack follow the manufacturer’s operating instructions and precautions. CAUTION! Use a back-and-forth motion to remove the hub cap. CAUTION! Do not use a twisting motion when removing the hub cap, damage to the hub cap finish may occur.

  • Page 325: Preparations For Jump-Start

    WHAT TO DO IN EMERGENCIES 323 Preparations For Jump-Start The vehicle’s jump starting remote posts are located under the hood, in the engine compartment on the driver’s side. The Remote Positive (+) Post is covered with a protective cap located on the side of the Front Power Distribution Center.

  • Page 326: Jump-Starting Procedure

    324 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
  • Page 327 WHAT TO DO IN EMERGENCIES 325 4. Connect the opposite end of the negative (-) jumper CAUTION! cable to the remote negative (-) post of the discharged vehicle. Failure to follow these procedures could result in damage to the charging system of the booster vehicle NOTE: The remote negative (-) post is located in the or the discharged vehicle.
  • Page 328 326 WHAT TO DO IN EMERGENCIES 6. Once the engine is started, disconnect the jumper If frequent jump-starting is required to start your vehicle cables in the reverse sequence: you should have the battery and charging system in- spected at your authorized dealer. Disconnecting The Jumper Cables 1.

  • Page 329: Battery Location

    WHAT TO DO IN EMERGENCIES 327 Battery Location There are two remote jump starting posts under the hood which is the recommended jump start location. If access to the battery is needed, an access panel on the driver’s side floor will allow for battery access. Battery Location Access Panel...
  • Page 330 328 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE NOTE: Push the ESC Off switch, to place the Electronic Stability Control (ESC) system in Partial Off mode, If your vehicle becomes stuck in mud, sand, or snow, it before rocking the vehicle. Refer to “Electronic Brake can often be moved using a rocking motion.

  • Page 331: Shift Lever Override

    WHAT TO DO IN EMERGENCIES 329 3. Using a small screwdriver or similar tool, remove the WARNING! shift lever override access cover which is located Fast spinning tires can be dangerous. Forces gener- below the shift lever. ated by excessive wheel speeds may cause damage, or 4.

  • Page 332: Towing A Disabled Vehicle

    330 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF the ALL Models Ground Flat Tow NONE If transmission is operable: • Transmission in NEUTRAL Wheel Lift or Rear •...

  • Page 333: Automatic Transmission

    WHAT TO DO IN EMERGENCIES 331 If you must use the accessories (wipers, defrosters, etc.) Automatic Transmission while being towed, the ignition must be in the ON/RUN The manufacturer recommends towing your vehicle with position. all four wheels OFF the ground using a flatbed. If the key fob is unavailable or the vehicle’s battery is If flatbed equipment is not available, and the transmis- discharged, see “Shift Lever Override”...
  • Page 334 332 WHAT TO DO IN EMERGENCIES CAUTION! • Towing faster than 25 mph (40 km/h) or farther than 15 mi (24 km) with front wheels on the ground can cause severe transmission damage. Damage from improper towing is not covered under the New Vehicle Limited Warranty.
  • Page 335 MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Air Cleaner Filter ....343 ENGINE COMPARTMENT — 3.6L ..335 ▫ Exhaust System ..... .344 ONBOARD DIAGNOSTIC SYSTEM —...
  • Page 336 334 MAINTAINING YOUR VEHICLE ▫ Appearance Care And Protection From ▫ Daytime Running Lamp (DRL)/Front Side Corrosion ......362 Marker Lamp .

  • Page 337: Engine Compartment - 3.6L

    MAINTAINING YOUR VEHICLE 335 ENGINE COMPARTMENT — 3.6L 1 — Washer Solvent Reservoir 5 — Power Distribution Center (Fuses) 2 — Engine Oil Fill 6 — Coolant Reservoir 3 — Engine Oil Dipstick 7 — Power Steering Reservoir 4 — Brake Fluid Reservoir...

  • Page 338: Onboard Diagnostic System - Obd Ii

    336 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated Onboard • Prolonged driving with the MIL on could cause Diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.

  • Page 339: Loose Fuel Filler Cap Message

    MAINTAINING YOUR VEHICLE 337 Loose Fuel Filler Cap Message EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a In some localities, it may be a legal requirement to pass “Check fuel cap”...
  • Page 340 338 MAINTAINING YOUR VEHICLE • The MIL will not flash at all and will remain fully Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check if illuminated until you place the ignition in the off your vehicle’s OBD II system is ready, you must do the position or start the engine.

  • Page 341: Replacement Parts

    MAINTAINING YOUR VEHICLE 339 REPLACEMENT PARTS WARNING! Use of genuine MOPAR® parts for normal/scheduled You can be badly injured working on or around a maintenance and repairs is highly recommended to en- motor vehicle. Only do service work for which you sure the designed performance.

  • Page 342: Engine Oil

    340 MAINTAINING YOUR VEHICLE Engine Oil CAUTION! Checking Oil Level • Failure to properly maintain your vehicle or perform To assure proper engine lubrication, the engine oil must repairs and service when necessary could result in be maintained at the correct level. Check the oil level at more costly repairs, damage to other components or regular intervals, such as every fuel stop.
  • Page 343 MAINTAINING YOUR VEHICLE 341 Change Engine Oil American Petroleum Institute (API) Engine Oil Identification Symbol The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Refer to the “Maintenance Schedule” for further informa- This symbol means that the oil has tion.
  • Page 344 342 MAINTAINING YOUR VEHICLE Engine Oil Viscosity — 3.6L Engine Synthetic Engine Oils MOPAR® SAE 5W-20 engine oil approved to Chrysler You may use synthetic engine oils provided the recom- Material Standard MS-6395 such as Pennzoil®, Shell mended oil quality requirements are met, and the recom- Helix®...

  • Page 345: Engine Oil Filter

    MAINTAINING YOUR VEHICLE 343 station or governmental agency for advice on how and WARNING! where used oil and oil filters can be safely discarded in your area. The air induction system (air cleaner, hoses, etc.) can provide a measure of protection in the case of engine Engine Oil Filter backfire.

  • Page 346: Exhaust System

    344 MAINTAINING YOUR VEHICLE Exhaust System WARNING! The best protection against carbon monoxide entry into • Exhaust gases can injure or kill. They contain the vehicle body is a properly maintained engine exhaust carbon monoxide (CO), which is colorless and system.
  • Page 347 MAINTAINING YOUR VEHICLE 345 Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.

  • Page 348: Maintenance-Free Battery

    346 MAINTAINING YOUR VEHICLE To minimize the possibility of catalytic converter damage: WARNING! • Do not shut off the engine or interrupt the ignition, • Battery fluid is a corrosive acid solution and can when the transmission is in gear and the vehicle is in burn or even blind you.

  • Page 349: Air Conditioner Maintenance

    MAINTAINING YOUR VEHICLE 347 Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner should • It is essential when replacing the cables on the be checked and serviced by an authorized dealer at the battery that the positive cable is attached to the start of each warm season.
  • Page 350 348 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling WARNING! (Continued) R-134a Air Conditioning Refrigerant is a hydrofluoro- • The air conditioning system contains refrigerant carbon (HFC) that is endorsed by the Environmental under high pressure. To avoid risk of personal Protection Agency and is an ozone-saving product.
  • Page 351 MAINTAINING YOUR VEHICLE 349 The A/C air filter is located in the fresh air inlet in the 2. Remove and replace the A/C air filter from the filter engine compartment. Perform the following procedure to retainer. replace the filter: 1. Remove the two screws that secure the filter retainer to the fresh air inlet, and remove the filter retainer.

  • Page 352: Body Lubrication

    350 MAINTAINING YOUR VEHICLE 3. Install the A/C air filter/filter retainer back into the Particular attention should also be given to hood latching fresh air inlet. When installing the filter retainer make components to ensure proper function. When performing sure the retainer is fully engaged. other underhood services, the hood latch, release mecha- nism and safety catch should be cleaned and lubricated.
  • Page 353 MAINTAINING YOUR VEHICLE 351 Avoid using the wiper blades to remove frost or ice from The washer fluid reservoir will hold a full gallon of fluid the windshield. Keep the blade rubber out of contact with when the Low Washer Fluid Light illuminates. petroleum products such as engine oil, gasoline, etc.

  • Page 354: Cooling System

    352 MAINTAINING YOUR VEHICLE Cooling System Coolant Checks Check the engine coolant (antifreeze) protection every WARNING! 12 months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty, the • When working near the radiator cooling fan, system should be drained, flushed, and refilled with disconnect the fan motor lead or turn the ignition fresh OAT coolant (conforming to MS-12106) only by an...
  • Page 355 MAINTAINING YOUR VEHICLE 353 If the engine coolant (antifreeze) is dirty or contains CAUTION! visible sediment, have an authorized dealer clean and • Mixing of engine coolant (antifreeze) other than flush with OAT coolant (antifreeze) (conforming to MS.90032). specified Organic Additive Technology (OAT) en- gine coolant (antifreeze), may result in engine Refer to the “Maintenance Schedule”...
  • Page 356 354 MAINTAINING YOUR VEHICLE coolant (antifreeze) can be used up to ten years or CAUTION! (Continued) 150,000 miles (240,000 km) before replacement. To pre- • Do not use water alone or alcohol-based engine vent reducing this extended maintenance period, it is coolant (antifreeze) products.
  • Page 357 MAINTAINING YOUR VEHICLE 355 • Mix a minimum solution of 50% OAT engine coolant NOTE: that meets the requirements of Chrysler Material Stan- • Some vehicles require special tools to add coolant dard MS.90032 and distilled water. Use higher concen- properly.
  • Page 358 356 MAINTAINING YOUR VEHICLE Cooling System Pressure Cap WARNING! (Continued) The cap must be fully tightened to prevent loss of engine • Do not use a pressure cap other than the one coolant (antifreeze), and to ensure that engine coolant specified for your vehicle.
  • Page 359 MAINTAINING YOUR VEHICLE 357 Coolant Level If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be The coolant expansion bottle provides a quick visual safely driven. The vapor will soon dissipate. method for determining that the coolant level is ad- •...

  • Page 360: Brake System

    358 MAINTAINING YOUR VEHICLE • Make sure that the coolant expansion bottle overflow WARNING! hoses are not kinked or obstructed. Riding the brakes can lead to brake failure and • Keep the front of the radiator clean. If your vehicle is possibly a collision.
  • Page 361 MAINTAINING YOUR VEHICLE 359 Overfilling of fluid is not recommended because it may WARNING! (Continued) cause leaking in the system. Using the wrong type of brake fluid can severely Add enough fluid to bring the level up to the require- damage your brake system and/or impair its perfor- ments described on the brake fluid reservoir.

  • Page 362: Automatic Transmission (3.6L Gasoline Engine Only)

    360 MAINTAINING YOUR VEHICLE Refer to “Fluids, Lubricants, and Genuine Parts” in this WARNING! (Continued) section for fluid specifications. It is important to maintain • Overfilling the brake fluid reservoir can result in the transmission fluid at the correct level using the spilling brake fluid on hot engine parts, causing recommended fluid.
  • Page 363 MAINTAINING YOUR VEHICLE 361 Special Additives Fluid Level Check The manufacturer strongly recommends against using The fluid level is preset at the factory and does not any special additives in the transmission. require adjustment under normal operating conditions. Routine fluid level checks are not required, therefore the Automatic Transmission Fluid (ATF) is an engineered transmission filler tube is capped and no dipstick is product and its performance may be impaired by supple-...

  • Page 364: Appearance Care And Protection From

    362 MAINTAINING YOUR VEHICLE Fluid And Filter Changes The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion Refer to the “Maintenance Schedule” for the proper resistance built into your vehicle. maintenance intervals. What Causes Corrosion? In addition, change the fluid and filter if the fluid becomes contaminated (with water, etc.), or if the transmission is Corrosion is the result of deterioration or removal of...
  • Page 365 MAINTAINING YOUR VEHICLE 363 Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR® Car Wash, or a mild such as steel wool or scouring powder that will car wash soap, and rinse the panels completely with scratch metal and painted surfaces.
  • Page 366 364 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is All wheels and wheel trim, especially aluminum and considered the responsibility of the owner. chrome plated wheels, should be cleaned regularly with •...
  • Page 367 MAINTAINING YOUR VEHICLE 365 • For tough stains, apply MOPAR® Total Clean, or a CAUTION! (Continued) mild soap solution to a clean, damp cloth and remove products may damage the wheel’s protective finish. stain. Use a fresh, damp towel to remove soap residue. Avoid automatic car washes that use acidic solutions •...
  • Page 368 366 MAINTAINING YOUR VEHICLE Cleaning Interior Trim liquid. Please do not use polishes, oils, cleaning fluids, solvents, detergents, or ammonia-based cleaners to clean Interior trim should be cleaned starting with a damp your leather upholstery. Application of a leather condi- cloth, a damp cloth with MOPAR®...
  • Page 369 MAINTAINING YOUR VEHICLE 367 Plastic is not as scratch resistant as glass and therefore When cleaning the rear view mirror, spray cleaner on the different lens cleaning procedures must be followed. towel or rag that you are using. Do not spray cleaner directly on the mirror.

  • Page 370: Cleaning The Instrument Panel Cupholders

    368 MAINTAINING YOUR VEHICLE If the belts need cleaning, use MOPAR® Total Clean, a Cleaning The Instrument Panel Cupholders mild soap solution, or lukewarm water. Do not remove Removal the belts from the vehicle to wash them. Dry with a soft Pull the flexible liner from the cupholder drawer starting cloth.

  • Page 371: Fuses

    MAINTAINING YOUR VEHICLE 369 Installation WARNING! (Continued) Place the liner into the cupholder drawer and press the • Before replacing a fuse, make sure that the ignition liner into place so that the retention tabs seat into the is off and that all the other services are switched off corresponding openings in the drawer.

  • Page 372: Underhood Fuses

    370 MAINTAINING YOUR VEHICLE Underhood Fuses The ID number of the electrical component correspond- ing to each fuse can be found on the back of the cover. The Front Power Distribution Center is located on the driver’s side of the engine compartment. To access the fuses, remove the cover.
  • Page 373 MAINTAINING YOUR VEHICLE 371 Cavity Maxi Fuse Mini Fuse Description 40 Amp Orange Electronic Stability Control (ESC) Pump 20 Amp Yellow Starter Relay 3.6L (3.6 Gasoline Engine) (3.6 Gasoline Engine) 50 Amp Red Glow Plug Unit (3.0 Diesel Engine) (3.0 Diesel Engine) 50 Amp Red Secondary Power Distribution Center (PDC) (Trans (3.6 Gasoline Engine)
  • Page 374 372 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 50 Amp Red (non A/C) Engine Cooling Fan - 1st Speed 60 Amp Blue (A/C) 40 Amp Orange Passenger Compartment Blower 15 Amp Blue Rear Power Outlet 15 Amp Blue Horn 15 Amp Blue Fuel Pressure Regulator (MPROP)-DRV (3.0 Diesel...
  • Page 375 MAINTAINING YOUR VEHICLE 373 Cavity Maxi Fuse Mini Fuse Description 20 Amp Yellow Secondary Loads, Engine Control Module (ECM) (3.0 Diesel Engine) 7.5 Amp Brown KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.6 Gasoline Engine) 7.5 Amp Brown KL30 Manual Transmission Automated (MTA), KL30 Engine Control Module (ECM), KL30 Main Relay Coil (3.0 Diesel Engine)
  • Page 376 374 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 7.5 Amp Brown KL15 Vacuum pump relay coil (3.6 Gasoline Engine) — If Equipped 15 Amp Blue Heated Mirrors Front PDC Additional Fuses The additional fuse box is located inside the front PDC Box.
  • Page 377 MAINTAINING YOUR VEHICLE 375 Cavity Mini Fuse Description 20 Amp Yellow Vacuum Pump (3.6 Gasoline Engine) — If Equipped 30 Amp Green Transmission Power RELE (3.6 Gasoline Engine) — If Equipped 7.5 Amp Brown Urea Pump (3.0 Diesel Engine) — If Equipped 25 Amp White Urea NOX Sensor 1–2 —...

  • Page 378: Interior Fuses

    376 MAINTAINING YOUR VEHICLE Interior Fuses The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver’s side under the instrument panel. Fuse Panel...
  • Page 379 MAINTAINING YOUR VEHICLE 377 Fuse Panel Cavity Locations...
  • Page 380 378 MAINTAINING YOUR VEHICLE Cavity Mini Fuse Description 10 Amp Red Right Low Beam 10 Amp Red Left Low Beam 5 Amp Beige INT/A 10 Amp Red SBMT 7.5 Amp Brown Clearance Lights 15 Amp Blue +30 (ACM – TPCU – RRM – DLC) 5 Amp Beige INT (BRAKE NO –...
  • Page 381 MAINTAINING YOUR VEHICLE 379 Cavity Mini Fuse Description 7.5 Amp Brown INT (ORC) 5 Amp Beige INT (REAR CAMERA-AUX) 5 Amp Beige +30 (IPC) 7.5 Amp Brown Left High Beam 7.5 Amp Brown Right High Beam 7.5 Amp Brown Left Fog Lamp 7.5 Amp Brown Right Fog Lamp...

  • Page 382: Right Central Pillar Fuses

    380 MAINTAINING YOUR VEHICLE Right Central Pillar Fuses The right central pillar fuse panel is located on the interior side at the base of the passenger side B pillar. Fuse Panel Fuse Panel Location...

  • Page 383: Vehicle Storage

    MAINTAINING YOUR VEHICLE 381 Cavity Mini Fuse Description 7.5 Amp Brown Seat Heater 20 Amp Yellow Rear Left Windows Heater 20 Amp Yellow Rear Right Windows Heater VEHICLE STORAGE in the fresh air and high blower setting. This will ensure adequate system lubrication to minimize the If you are leaving your vehicle dormant for more than 21 possibility of compressor damage when the system is days, you may want to take these steps to protect your...

  • Page 384: Replacement Bulbs

    382 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Bulb Number Daytime Running Lamps 7440 Interior Bulbs (If Equipped) Bulb Number Front Side Marker Lamps WY5W Overhead Lamp Rear Tail/Stop Lamps 7443 Sun Visors Rear Turn Signal Lamps 7440NA Courtesy Lamp FF500 Rear Backup Lamps Glove Compartment Rear Side Marker Lamps Rear Courtesy Lamp...

  • Page 385: Bulb Replacement

    MAINTAINING YOUR VEHICLE 383 BULB REPLACEMENT 6. Remove appropriate plastic cap from the back of the headlamp housing. NOTE: Lens fogging can occur under certain atmo- spheric conditions. This will usually clear as atmospheric 7. Push down on the upper portion of the socket. conditions change to allow the condensation to change 8.

  • Page 386: Front Turn Signal/Parking Lamps

    384 MAINTAINING YOUR VEHICLE 16. Carefully reinstall screw (1) on lower headlamp filler 6. Rotate the bulb counter clockwise and remove. panel. 7. Install the bulb into socket, and rotate bulb/socket 17. Carefully reinstall screws (2) on upper headlamp clockwise into lamp locking it in place. filler panel.

  • Page 387: Daytime Running Lamp (Drl)/Front Side Marker Lamp

    MAINTAINING YOUR VEHICLE 385 Daytime Running Lamp (DRL)/Front Side Marker 9. Carefully reinstall headlamp in the same position on Lamp the vehicle, so as not to affect headlamp aiming. NOTE: Passenger side headlamp must be removed for 10. Install upper screw (1) on headlamp housing. bulb replacement, for driver side headlamp go to step 6 11.

  • Page 388: Front, Rear Roof Lamps

    386 MAINTAINING YOUR VEHICLE 4. Connect the wire and rotate bulb/socket clockwise Rear Tail, Stop, Backup, Turn Signal And Rear into lamp locking it in place. Side Marker Lamps 5. Reinstall the plastic cap and close the cover on the 1.

  • Page 389: Fluid Capacities

    MAINTAINING YOUR VEHICLE 387 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 24 Gallons 90 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters Cooling System * 3.6L Engine (MOPAR® Antifreeze/Engine 10.5 Quarts 10 Liters Coolant 10 Year/150,000 Mile Formula or equivalent)

  • Page 390: Fluids, Lubricants And Genuine Parts

    388 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of Chrysler Material Standard MS.90032. Engine Oil We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the require- ments of Chrysler Material Standard MS-6395 such as MOPAR®, Pennzoil®, and...
  • Page 391 MAINTAINING YOUR VEHICLE 389 CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine • Mixing of engine coolant (antifreeze) other than coolant (antifreeze) products. Do not use additional specified Organic Additive Technology (OAT) en- rust inhibitors or antirust products, as they may not gine coolant (antifreeze), may result in engine be compatible with the radiator engine coolant and damage and may decrease corrosion protection.

  • Page 392: Chassis

    390 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission – 3.6L Gasoline Engine Only Use Only ATF+4® Automatic Transmission Fluid. Fail- ure to use ATF+4® fluid may affect the function or performance of your transmission. We recommend MOPAR®...
  • Page 393 MAINTENANCE SCHEDULES CONTENTS ▫ Maintenance Chart ....394 MAINTENANCE SCHEDULE ... . .392...
  • Page 394 392 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other indicator system.
  • Page 395 MAINTENANCE SCHEDULES 393 Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil • Check engine oil level Change Indicator System: • Change oil and filter. • Check windshield washer fluid level • Rotate the tires. Rotate at the first sign of irregu- •...
  • Page 396 394 MAINTENANCE SCHEDULES Maintenance Chart Refer to the Maintenance Schedules on the following pages for the required maintenance intervals. Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary.
  • Page 397 MAINTENANCE SCHEDULES 395 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air filter. Replace cabin/air conditioning filter. Replace Brake Fluid every two years Replace spark plugs (3.6L engine). ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first.
  • Page 398 396 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change automatic transmission fluid and filter. Inspect and replace PCV valve if necessary. ** The spark plug change interval is mileage based only, yearly intervals do not apply.
  • Page 399 MAINTENANCE SCHEDULES 397 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
  • Page 401 IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ....401 Speech Impaired (TDD/TTY) ... . .403 ▫...
  • Page 402 400 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... . .408 PUBLICATION ORDER FORMS ... .406 ▫...

  • Page 403: Suggestions For Obtaining Service For Your Vehicle

    IF YOU NEED CONSUMER ASSISTANCE 401 SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.

  • Page 404: Fca Usa Llc Customer Center

    402 IF YOU NEED CONSUMER ASSISTANCE are most concerned that you get prompt and high quality Any communication to the manufacturer’s customer center service. The manufacturer’s authorized dealer have the should include the following information: facilities, factory-trained technicians, special tools, and •...

  • Page 405: Chrysler Canada Inc. Customer Center

    IF YOU NEED CONSUMER ASSISTANCE 403 Chrysler Canada Inc. Customer Center Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) P.O. Box 1621 To assist customers who have hearing difficulties, the Windsor, Ontario N9A 4H6 manufacturer has installed special TDD (Telecommuni- Phone: (800) 465-2001 English / (800) 387-9983 French cation Devices for the Deaf) equipment at its customer center.

  • Page 406: Service Contract

    404 IF YOU NEED CONSUMER ASSISTANCE Service Contract New Vehicle Limited Warranty expires, please refer to the contract documents, and contact the person listed in You may have purchased a service contract for a vehicle those documents. to help protect you from the high cost of unexpected repairs after the manufacturer’s New Vehicle Limited We appreciate that you have made a major investment Warranty expires.

  • Page 407: Warranty Information

    IF YOU NEED CONSUMER ASSISTANCE 405 REPORTING SAFETY DEFECTS WARNING! (Continued) In The 50 United States And Washington, D.C. contained in vehicles and certain products of compo- nent wear contain, or emit, chemicals known to the If you believe that your vehicle has a defect that could State of California to cause cancer and birth defects, cause a crash or cause injury or death, you should or other reproductive harm.

  • Page 408: In Canada

    406 IF YOU NEED CONSUMER ASSISTANCE You can also obtain other information about motor NOTE: A street address is required when ordering manu- vehicle safety from http://www.safercar.gov. als (no P.O. Boxes). In Canada Service Manuals If you believe that your vehicle has a safety defect, you These comprehensive Service Manuals provide the infor- should contact the Customer Service Department imme- mation that students and professional technicians need...

  • Page 409: Department Of Transportation Uniform Tire Quality Grades

    IF YOU NEED CONSUMER ASSISTANCE 407 problems the first time, using step-by-step troubleshoot- DEPARTMENT OF TRANSPORTATION UNIFORM ing and drivability procedures, proven diagnostic tests TIRE QUALITY GRADES and a complete list of all tools and equipment. The following tire grading categories were established by the National Highway Traffic Safety Administration.

  • Page 410: Traction Grades

    408 IF YOU NEED CONSUMER ASSISTANCE significantly from the norm due to variations in driving Temperature Grades habits, service practices, and differences in road charac- The temperature grades are A (the highest), B, and C, teristics and climate. representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under Traction Grades controlled conditions on a specified indoor laboratory...
  • Page 411 IF YOU NEED CONSUMER ASSISTANCE 409 WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, under-inflation, or excessive load- ing, either separately or in combination, can cause heat buildup and possible tire failure.
  • Page 413 INDEX...
  • Page 414 412 INDEX Adding Engine Coolant (Antifreeze) ... .354 Air Bag Maintenance ..... . .50 Adding Fuel .
  • Page 415 INDEX 413 Audio Systems (Radio) .....180 Brake Assist System ..... . .226 Auto Down Power Windows .
  • Page 416 414 INDEX Carbon Monoxide Warning ....64 Manual ......185 Cargo Light .
  • Page 417 INDEX 415 Cruise Light ......128 Door Locks, Automatic ..... .22 Cupholders.
  • Page 418 416 INDEX Emission Control System Maintenance ..337 Overheating ......293 Engine Starting .
  • Page 419 INDEX 417 Flashers Ethanol ......266 Hazard Warning ......293 Filler Cap (Gas Cap) .
  • Page 420 418 INDEX Odometer ......128 High Beam ......95 Speedometer .
  • Page 421 INDEX 419 Immobilizer (Sentry Key) ....13 Latches ....... . .67 Inside Rearview Mirror .
  • Page 422 420 INDEX Hazard Warning Flasher ....293 Tires ....... .240 Headlights .
  • Page 423 INDEX 421 Outside .......72 Checking ......340 Rearview .
  • Page 424 422 INDEX ParkSense® System, Rear....105 Rearview Mirrors ......72 Passing Light .
  • Page 425 INDEX 423 Safety Checks Inside Vehicle ....65 Seat Belt Reminder ......26 Safety Checks Outside Vehicle .
  • Page 426 424 INDEX SENTRY KEY® Engine Fails To Start .....203 FCC General Information ....14 Steering Sentry Key (Immobilizer) .
  • Page 427 INDEX 425 Air Pressure ......245 Tread Wear Indicators ....254 Chains .
  • Page 428 426 INDEX Tips ....... . .286 Untwisting Procedure, Seat Belt ....32 Trailer And Tongue Weight .
  • Page 429 INDEX 427 Wind Buffeting......23 Windows ....... .22 Power .
  • Page 430 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 431 Chrysler Group LLC 15VF-126-AC Third Edition Printed in U.S.A. 15DD43-126-AA FIRST Edition Printed in U.S.A.

Table of Contents
