Instructions - Parts List

Fire-Ball

Motor Muffler Kit

For professional use only.

Part No. 222559

Important Safety Instructions

Read all warnings and instructions in this

manual and in the Fire-Ball 300 Pumps man-

ual, included with your unit. Save all instruc-

tions.

NOTICE

You cannot order parts or request service and war-

ranty information for the complete pump without the

information on the serial label.

Record all information from the serial label in the

space provided below. Keep this manual in a safe

place as an extra precaution.

GRACO PUMP

PART NO.

SERIAL

MAX AIR WPR

MAX FLUID WPR

300 Air

SERIES

MPA

bar

MPA

bar

psi

307942E

Need help?

Do you have a question about the Fire-Ball 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco Fire-Ball 300

Page 1 For professional use only. Part No. 222559 Important Safety Instructions Read all warnings and instructions in this manual and in the Fire-Ball 300 Pumps man- ual, included with your unit. Save all instruc- tions. NOTICE You cannot order parts or request service and war- ranty information for the complete pump without the information on the serial label.
Page 2 Service Service Pressure Relief Procedure Replace the Muffler Plates Follow the Pressure Relief Procedure whenever NOTE: You cannot order parts or request service or you see this symbol. warranty information without the serial label information. Record the serial label (A) information on the front of this manual as an added precaution.
Page 3 Parts Parts Ref. Part Description Qty. 234577 MUFFLER, identification and serial plate side 234578 MUFFLER, warning plate side 100078 SCREWS, plate retaining No. 8-32 x 0.375 inch LABEL, serial 307942E...
Page 4 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
