- Page 3 M66291GP Utility Board M3A-0032 Instruction Manual 2007-03-13 Rev.1.03 2007.3...
- Page 4 Please be sure to implement safety measures to guard against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other applicable measures.
-
Page 5: Table Of Contents
Model Name Contents Quantity M3A-0032 M66291GP Utility Board REJ11F0006 M3A-0032 Instruction Manual (English) This product is thus complied with European RoHS Directive. # The restriction of the use of certain Hazardous Substances in electrical and electronic equipment. -
Page 6: Chapter 1. Summary
16-bit, 8-bit, and 16-bit write formats. Figure 2 shows the connection direction for the M3A-0033 board. Chapter 2. Outline Figure 1 shows the top view of M3A-0032 board. The actual dimension is shown in Figure 3 and 4. Connectors CN2, CN3: Test Pin::... -
Page 7: Chapter 3. Specifications
Chapter 3. Specifications Board Size: 70mm X 70mm Supply Power: COREVcc --- 3.3V +/- 0.3V, IOVcc – 5V +/- 0.5V (5.0V type) or 3.3V + 0.3V – 0.5V (3.0V type) Interface: 26-pin Connector X 2 (2.54 mm pitch, dual straight header, male type), USB Connecter (B-type) Connector Definition Connectors CN2 and CN3 provide all bus interface pins of the chip such as processor bus interface and... -
Page 8: Chapter 4. Jumper Settings
Chapter 4. Jumper Settings JP NO Function EXIOVCC JP1(IOVCC) Supplies MCU supply power Supply 3.3V to IOVcc (3.3V or 5.0V) to IOVcc JP NO Function 16-bit 8-bit JP2(BYTE/HWR) 16 bits Bus 8 bits Bus 16-bit write-type of M66290 JP NO Function 16 bit 8 bit... - Page 9 M3A-0032 M66291GP Target Board Figure 2 Target Board Connection Direction 2.54mm Figure 3 Pin Pitch of Connectors CN2 and CN3 70mm 58.42mm pin 1 pin 1 pin 25 26 pin 25 USB Connector Figure 4 Pin Direction of Connector CN2 and CN3 (Bottom View)
- Page 10 EMI FILTER L1,L2 BLM21P 221SG Murata Not Mounted Note-1 EMI FILTER BLM21A 121SPT Murata Not Mounted Note-1 Ju mper Socket JS-1 MAC8 Notes Note-1: Only printed pattern is available. No part is installed. M66291GP (USB ASSP) Utility Board TYTLE DRAWING PPL-M3A-0032...
- Page 11 Voltage Supply Following devices are not mounted. C11, C12, C13, C14, D1, D2, D3, L1, L2, L3, L4, JP4, JP5, X2 Note: 1) The land patterns of L1 are shorted. Please cut the shorted pattern, when you mount L1. 2) The land patterns of L2 are shorted. Please cut the shorted pattern, when you mount L2.
- Page 12 Revision History M3A-0032 Instruction Manual Description Rev. Date Page Summary 1.00 Oct.02.02 — First edition issued Change of the company name. 1.01 Jul.01.03 Change Part list 1.02 Dec.01.04 Addition: This product is thus complied with European RoHS Directive. 1.03 Mar.13.07...
- Page 13 M66291GP Utility Board M3A-0032 Instruction Manual Mar.13.‘07 © 2007. Renesas Technology Corp. and Renesas Solutions Corp., All right reserved. Printed in Japan. No reproduction without permission. Reproduction or publication of part of or entire content of this document in any...
