INSTALLATION MANUAL
DESIGNED AND
MADE IN BRITAIN
4G LTE RANGE OF
INTERCOMS
Raising Standards
Safety Assured

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Optimus E1

  • Page 1 4G LTE RANGE OF INTERCOMS INSTALLATION MANUAL DESIGNED AND Raising Standards MADE IN BRITAIN Safety Assured...
  • Page 2: Table Of Contents

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS CONTENTS INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS Applicable Products GENERAL Overview How it works Product Description and Dimensions 04 – 05 INSTALLATION AND CONNECTION Special Tools and Materials needed What’s Inside The Box...
  • Page 3: Applicable Products

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS APPLICABLE PRODUCTS APPLICABLE PRODUCTS The Commtel 4G PRO PCB is used in the following products: OPTIMUS 4G LTE RANGE OF INTERCOMS This Installation manual applies to these products.
  • Page 4: General

    GENERAL OVERVIEW The Optimus 4G intercoms are entry systems which are suitable for any door, gate or barrier requiring communication and control over access. They can be used in any environment, internally or externally, including Domestic, Commercial and Public sectors.
  • Page 5: Product Description And Dimensions

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS GENERAL PRODUCT DESCRIPTION AND DIMENSIONS E10K Max. Dimensions: Max. Dimensions: Max. Dimensions: Max. Dimensions: Max. Dimensions: H 224 x W 96 x D 40 H 224 x W 96 x D 40...
  • Page 6: Installation And Connection

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS INSTALLATION AND CONNECTION SPECIAL TOOLS AND MATERIALS NEEDED 4G Analyser. Recommendation: Make ~ CSL Model ~ CS2389 4G/LTE RS Stock No. 176-2538 2.5mm Hex Key. Small Philips 00 Screwdriver. Electronic Grade Silicone Sealant, examples:...
  • Page 7: Positioning And Mounting The Intercom Unit

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS INSTALLATION AND CONNECTION POSITIONING AND MOUNTING THE INTERCOM UNIT The position of the Intercom Unit should maximise the safest and best operational performance and convenience, including: Users considerations, with optimal height recommendations (to centreline of the Intercom): Wheelchair: 750 –...
  • Page 8: Siting Of The Antenna

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS INSTALLATION AND CONNECTION SITING OF THE ANTENNA The supplied 4G antenna is an external item that should be installed in the most suitable position: As high as possible and obtaining the maximum signal strength, checked by a 4G Analyser (please see detailed instructions provided with the Analyser).
  • Page 9: Protective Earth And Bonding Terminals

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS INSTALLATION AND CONNECTION PROTECTIVE EARTH AND BONDING TERMINALS The Intercom must be permanently earthed. The Unit is fitted with an earth stud marked up with an earth label, the stud size is M3 and has a M3 Nyloc nut attached.
  • Page 10: Applications And Connections

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS APPLICATIONS AND CONNECTIONS 4G LTE I/O BOARD CONNECTIONS 4G LTE PCB CONNECTIONS...
  • Page 11: Applications Examples

    Optimus to Gate or Barrier System, where Controller requires both Command and a Simultaneous Hold Open Switch Example 4.0: Optimus to an Electric Lock or Latch Release were the Lock Power Supply Unit requires a Pulse to Release or Unlock Example 5.0:...
  • Page 12 NC if used to break a Closed Safety Circuit or similar. Some Controllers Stay Open status may be NC. The Power Down status of ❚ reprogrammed Optimus Relay will need to be accounted for in the Installation Design. Gate or Barrier Control Board Methods of Relay Operation can include: DTMF Tone / Facia PINS / Authorisation Recognition.
  • Page 13 INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS APPLICATIONS AND CONNECTIONS EXAMPLE 4.0 Application: OPTIMUS TO AN ELECTRIC LOCK OR LATCH RELEASE Condition: THE LOCK POWER SUPPLY UNIT REQUIRES A PULSE TO RELEASE OR UNLOCK RELAY ACTION RESULT RL1 NO...
  • Page 14: Installing Or Replacing The Sim Card

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS APPLICATIONS AND CONNECTIONS EXAMPLE 6.0 Application: ALTERNATIVE EXIT CONTROL USING AUXILIARY INPUT Condition: AUXILIARY INPUT TO ACTIVATE SET RELAY. EXAMPLE: PUSH TO EXIT RELAY ACTION RESULT AUX 1 or 2 Pulse Close >70ms NO...
  • Page 15: Programmable Settings Via 'Commtel Config' App + Additional Manual Sms Commands

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS PROGRAMMABLE SETTINGS ‘COMMTEL CONFIG’ APP + ADDITIONAL MANUAL SMS COMMANDS There are several Factory Default Settings that cannot be changed. CONFIGURABLE SETTINGS These allow local customisation of the Intercom, typically by the Installer: Addition, configuration and alteration of...
  • Page 16: Internal Cell Replacement For Real Time Clock (Rtc)

    Please dispose of or recycle the exhausted cell in a responsible way and according to the Cell manufacturer’s instructions. If storing un-powered 4G PRO boards for an extended time, Optimus recommends that the cell is removed until the board is needed.
  • Page 17: Eu Ce Declaration Of Conformity And Radio Equipment Directive

    INSTALLATION MANUAL FOR OPTIMUS 4G LTE RANGE OF INTERCOMS EU CE DECLARATION OF CONFORMITY AND RADIO EQUIPMENT DIRECTIVE This can be found at www.commtel.io...
  • Page 18 COMMTEL LTD, ORCHARD HOUSE, 39 GATWICK ROAD CRAWLEY, WEST SUSSEX RH10 9RB TELEPHONE: 01306 710120 EMAIL: info@optimus-uk.com www.optimus-uk.com EU CE Declaration of Conformity and Radio Equipment Directive is available at www.commtel-uk.com | GB-RH10 9RB...
