EcoFlow DELTA 2 Manual

Hide thumbs Also See for DELTA 2:
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Overview
FAQ
EcoFlow App
Overview
1
LCD screen
2
Bluetooth pairing indicator
3
USB-A output ports
4
USB-C output ports
5
Main power button
6
USB-A fast charging output ports
After-sales
Community
Policy
10
AC power button
11
DC5521 output ports
12
Car outlet
13
Overload protection switch
14
AC output sockets*
15
12V DC power button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DELTA 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EcoFlow DELTA 2

Summary of Contents for EcoFlow DELTA 2

  • Page 1: Table Of Contents

    Contents Overview LCD Display EcoFlow App After-sales Community Policy Power On/Off Charge Your Devices Charge DELTA 2 Overview X-Boost Care and Maintenance Specifications EcoFlow App What's in the Box Accessories Safety Instructions Certification and Compliance LCD screen AC power button...

  • Page 2: Lcd Display

    To ensure continuous power supply for critical uses, such as storing medicines, vaccines, the perishables, or other valuable items in a refrigerator, set the power station’s AC timeout interval to never in the EcoFlow app. Additionally, regularly check the power station’s battery level. LCD Display...

  • Page 3: Power On/Off

    2 hours, the product will shut off automatically. You can set the standby time in the EcoFlow app. If the product is not used for 5 minutes, it will enter sleep mode with the LCD screen shut off.
  • Page 4 USB Output Press the USB Power Button once to turn on/off the USB output ports. Maximum power of every USB output port: USB-A: 12W/18W (fast charge) USB-C: 100W After the USB Power Button is turned on, the product will not shut off automatically.

  • Page 5: Charge Delta 2

    AC timeout interval to never in the EcoFlow app. Additionally, regularly check the power station’s battery level. 12V DC Output (DC5521 & Car Charging) Press the 12V DC Power Button once to turn on/off the DC output ports.
  • Page 6 60V to avoid product damage. Solar to XT60/XT60i Charging Cable solar panels are not included in the package. 3. When using an EcoFlow solar panel to charge the product, please follow the instructions that come with the solar panel.
  • Page 7 Smart Extra Battery A single DELTA 2 can connect up to 1 Smart Extra Battery for additional capacity. Refer to the user manuals of the DELTA 2 Smart Extra Battery and Smart Generator for detailed instructions.
  • Page 8 1. Turn off both the Smart Extra Battery and DELTA 2 before connecting or disconnecting them. 2. Before using, make sure both DELTA 2 and Smart Extra Battery display the extra battery icon on their screens. 3. Do not directly connect or remove the Smart Extra Battery during charging and discharging processes.

  • Page 9: X-Boost

    1. X-Boost is not available when the AC output is turned on in a recharging state (in bypass mode*). 2. X-Boost is enabled by default. You can adjust it in the EcoFlow App. 3. X-Boost is not available for all electrical appliances; it’s incompatible with appliances with strict voltage requirements.

  • Page 10: Care And Maintenance

    2. We recommend that you only charge one device at a time and avoid using multiple ones at the same time to avoid overload protection. EcoFlow takes no responsibilities for any device failures or data losses caused by failures to follow instructions.
  • Page 11 AC (bypass 100-120V~50/60Hz total 13A (US/CA) mode) 220-240V~50Hz/60Hz total 9A (EU/UK/AU/ZA) Max X-Boost 2200W (US/CA) Output Power 2400W (EU/UK/AU/ZA) USB-A (×2) 5V⎓2.4A, 12W max. per port, total 24W USB-A Fast 5V⎓2.4A, 9V⎓2A, 12V⎓1.5A Charging (×2) 18W max. per port, total 36W 5/9/12/15/20V⎓5A USB-C (x2) 100W max.

  • Page 12: Ecoflow App

    2. Whether the product can be charged or discharged depends on the actual temperature of the battery pack. EcoFlow App Control, monitor and customize your EcoFlow DELTA 2 from afar with the EcoFlow App. How to Connect > What's in the Box 1.

  • Page 13: Faq

    5. Avoid using wires or metal objects that may result in a short circuit. 6. Do not use unofficial components or accessories. If you need to replace any components or accessories, please visit official EcoFlow channels to check relevant information.
  • Page 14 To ensure continuous power supply for critical uses, such as storing medicines, vaccines, the perishables, or other valuable items in a refrigerator, set the power station’s AC timeout interval to never in the EcoFlow app. Additionally, regularly check the power...

  • Page 15: Certification And Compliance

    station’s battery level. Operation of this equipment in a residential environment could cause radio interference. Disposal> 1. If conditions permit, make sure that the battery is fully discharged before disposing it in a designated battery recycling bin. The product contains batteries with potentially dangerous chemicals, so it is strictly prohibited to dispose of it in ordinary trash cans.
  • Page 16 Hereby, EcoFlow Inc. declares that the radio equipment type portable power station is in compliance with Directives 2014/53/EU, 2011/65/EU(RoHS), (EU) 2015/863(RoHS). The full text of the EU declaration of conformity is available at the following Internet address: http://www.ecoflow.com/eu/eu-compliance...
