BIKE TOWER 3100 INSTRUCTION MANUAL

Product overview

Thank you for purchasing the Bike Tower 3100 bicycle display stand.

The Bike Tower 3100 is a compact and lightweight 3 kg (6.6 lb.) bicycle display stand

made out of alloy tubes. It is designed to be portable so that you can set it up wherever

you need to store up to four bicycles. Its Main Pole is adjustable and ﬁts rooms with

ceiling heights of between 160 cm (5'3") and 311 cm (10'2").

Safety information

The Bike Tower 3100 is designed to work with two-wheeled bicycles. Using it to store

other types of bikes, such as motorcycles, tandem bikes, or electric bikes, is dangerous.

Doing so could cause damage to the display stand or your bike. It could also cause

injury. Storing non-approved objects on the display stand voids the warranty.

Carefully read this manual before using the display stand. If you have any questions or

comments about the product, or need help with assembly instructions, please contact

us at biketower@minoura.ca or (555)555-1234.

CAUTION: The Main Pole is not built to withstand a strong earthquake. If an earthquake

occurs and you have bicycles on the display stand, keep at least 3 meters (10 feet)

away from the stand at all times to avoid injury. If possible, leave the room.

Safety warnings

This manual includes important safety tips and warnings so that you can learn how to

safely operate the Bike Tower 3100 to prevent accident or injury. Carefully follow all

assembly and safety instructions.

This manual uses the following symbols to highlight important safety concerns:

DANGER This symbol tells you that an action is prohibited because it can cause

injury or death. Make sure to follow all DANGER symbols.

WARNING This symbol alerts you to potential hazards that can cause injury to you

or to others, or that can cause damage to the display or to your bicycles.

NOTE This symbol indicates additional information regarding assembly,

maintenance, or proper use of the display stand.

Dan Verbin

Need help?

Do you have a question about the BIKE TOWER 3100 and is the answer not in the manual?

Page 1 Thank you for purchasing the Bike Tower 3100 bicycle display stand. The Bike Tower 3100 is a compact and lightweight 3 kg (6.6 lb.) bicycle display stand made out of alloy tubes. It is designed to be portable so that you can set it up wherever you need to store up to four bicycles.
Page 2 TWR2016 S14-Editing II: Homework Assignment 2! Dan Verbin DISCLAIMER: This project was part of a class assignment. Diagrams in Figures 1–5 do not necessarily correspond with instructions but are included as examples of visual aids. Assembly instructions STEP 1 (refer to Figure 1) Attach the Frame Hook Beam to the Alloy Stand.
Page 3 In order to prevent injury or damage to your bicycles, you need to repeat Step 5. Make sure that the Bike Tower 3100 is installed vertically (from the ﬂoor to the ceiling). If the Main Pole is slanted, the display could fall down causing injury.
