Applicable Tire Size Capacity:
any 24-inch – 700 x 40c
(Max Tire Outer Diameter = 712mm)
Main Features
• The combination of the simple & durable mono-leg design frame and the powerful MagteqsTwin resistance unit
• Uses a pair of super-strong Neodymium magnets for providing extremely wide and controllable resistance range
• Compact round-knob design remote shifter enables to choose your desired power from 13 resistance levels easily
• Thick outer edge flywheel design generates more initial inertia through virtual weight of 2.7 kgs
• New double-thread knob type roller pressure system enables quick & easy setup/release operation
• Quick release type hub clamping mechanism
Please Note
Contact
MINOURA North American Tech Center
(for U.S. residents ONLY)
Hayward, California, U.S.A.
Phone: 1-510-538-8599 (8 am - 5 pm, Mon - Fri, PST)
Fax:
1-510-538-5899
Email: support@minourausa.com
indoor bicycle trainer
(ETRTO 42-622)
This trainer must be used with a completely smooth (no knobs or raised tread) tire.
Failure to do so will ruin the mag unit, your tire, and void any possible warranty.
If you need help, please contact the shop first where you originally purchased this product
or call the distributors in your country. The distributors list can be found on our web site.
When you cannot get enough service, you can contact us;
MADE IN JAPAN
instructions manual
MINOURA Japan Headquraters
(for ALL customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131
Fax:
+81-584-27-7505
Email: minoura@minoura.jp
Web: www.minoura.jp
(ver.2.0 2015/7)
Advertisement
Related Manuals for MINOURA LiveRide LR760
Summary of Contents for MINOURA LiveRide LR760
- Page 1 Contact or call the distributors in your country. The distributors list can be found on our web site. When you cannot get enough service, you can contact us; MINOURA North American Tech Center MINOURA Japan Headquraters (for U.S. residents ONLY) (for ALL customers) Hayward, California, U.S.A.
-
Page 2: Important Notes
The kit contains only M5 hex wrench. • Use the supplied rear quick release skewer for maximum stability. The hub clamping parts (couplings) fits the supplied quick release skewer only. Minoura is not responsible for any problem caused from using your own skewer. -
Page 3: Required Tools
How To Install Mag Unit & Roller Adjust Knob Mag Resistance Unit Required Tools: 1 x 5mm Hex Wrench (supplied) 1 x 10mm Spanner (not supplied) Install the Mag resistance unit and Roller Pressure Adjust Knob to the frame. First, attach the Knob, and tighten both brackets together using the pivot bolt and M6 nut. - Page 4 Placing LR760 on Floor Fully open the legs and place on a flat and horizontal floor. (see Fig. D) Make sure to open the legs until the are fully extended. Failure to do so will cause the frame to be unstable. (Fig.
- Page 5 The following steps describe the micro adjustment of the left side coupling. This step is not always required and once fixed in the proper position, you should not need to adjust again. Once adjusted to fit your bike, simply operate the Quick Hub Handle Lever for a proper fit every time.
-
Page 6: Roller Pressure Adjustment
Roller Pressure Adjustment Fully turn the red knob counter-clockwise. (initial position) Turn the silver dial counter-clockwise until the drive roller touches the tire surface. Turn the red knob clockwise to compress the tire by the roller. (required depth = 3 – 4 mm) (Fig. - Page 7 How To Operate Remote Shifter LR760 comes with a convenient remote shifter device. By installing it on your handlebar or stem, you can adjust the resistance level in 13 levels without getting off the bike. The plastic band is soft enough to fit aero-shaped carbon handlebar or round shaped stem as well as the standard round dimension handlebars.
- Page 8 When ordering replacement parts, clearly tell the part number to the shop people LR760 Schematics in order to avoid getting similar but wrong parts. UF-10 Alloy Lock Nut UF-8S Left Side Coupling Bolt (short) UF-6 Right Sude Coupling + Hub Clamp Handle (Red) UF-19 Main Frame UF-7...
