Stern Pinball STRANGER THINGS Service And Operation Manual page 15

SWITCH REFERENCE CONTINUED
ID Name
44 Right Ramp Exit
45 Back Ramp Exit
46
47 Left Pop Bumper
48 Right Pop Bumper
49 Pop Bumper 10 Pt Switch
50 Right Orbit
51
52
53 Drop Target Ball Sense
54
55 Center 4 Bank Drop 1 Left
56 Center 4 Bank Drop 2
57 Center 4 Bank Drop 3
58 Center 4 Bank Drop 4 Right 9
59
60
61
62
63 Left Ramp Enter
64
65 Left Ramp Exit
66
67 Backpanel Lock Top
68 Backpanel Lock Bottom
69
70 Left Lane Target
71
72 Demogorgon Opto
73
74 Center Lane Opto
75 Right Lane Rollover
76
77 Demodog Target 3
78 Demodog Target 4
79
80
81
82 Screen Motor Up
83 Screen Motor Down
84 Screen Ramp Opto
85
86
87
™/© Netflix, Inc. 2019. Used with permission.
Node Node Conn. Input InputWire GND
Ext Pin
9 - CN9 3 LGN ORG
9 - CN9 4 LGN YEL
9 - CN10 2 GRY BLK
9 - CN10 3 GRY BRN
9 - CN10 4 GRY RED
9 - CN10 5 GRY ORG
9 - CN10 6 GRY YEL
9 - CN11 5 TAN YEL
9 - CN11 6 TAN GRN
9 - CN11 7 TAN BLU
- CN11 8 TAN VIO
9 - CN12 2 WHT BRN 10
9 - CN12 4 WHT ORG 10
9 - CN12 5 WHT YEL
9 - CN12 6 WHT GRN 10
9 - CN12 7 WHT BLU
9 - CN12 9 WHT GRY
9 - CN13 2 PNK BRN
9 - CN13 3 PNK RED
9 - CN13 4 PNK ORG
9 - CN13 5 PNK YEL
9 - CN11 2 TAN BLK
9 - CN11 3 TAN RED
9 - CN11 4 TAN ORG
STRANGER THINGS PREMIUM MANUAL 500-55Y2-01
LIGHT,SWITCH,ANDDRIVERREFERENCE
Ground Location Type
Pin Wire
7/8 BLK BLU Playfield Opto
7/8 BLK BLU Playfield Micro
7/8/9 BLK BLU Playfield Leaf
7/8/9 BLK BLU Playfield Leaf
7/8/9 BLK BLU Playfield Leaf
7/8/9 BLK BLU Playfield Rollover
7/8/9 BLK BLU Playfield Opto
11/12 BLK GRY Playfield Opto
11/12 BLK GRY Playfield Opto
11/12 BLK GRY Playfield Opto
11/12 BLK GRY Playfield Opto
BLK WHT Playfield Opto
BLK WHT Playfield Opto
10 BLK WHT Playfield Opto
BLK WHT Playfield Opto
10 BLK WHT Playfield Leaf
10 BLK WHT Playfield Opto
10 BLK BRN Playfield Opto
10 BLK BRN Playfield Rollover
10 BLK BRN Playfield Leaf
10 BLK BRN Playfield Leaf
11/12 BLK GRY Playfield Micro
11/12 BLK GRY Playfield Micro
11/12 BLK GRY Playfield Opto
Address PartNumber
9-SW-24 515-0215-00 tx
515-0215-01 rx
9-SW-25 180-5087-00
9-SW-28 180-5232-00
9-SW-29 180-5232-00
9-SW-30 180-5231-00
9-SW-31 500-9935-04
9-SW-16 515-0215-00 tx
515-0215-01 rx
9-SW-18 520-5252-14
9-SW-19 520-5252-14
9-SW-20 520-5252-14
9-SW-21 520-5252-14
9-SW-8 515-0215-00 tx
515-0215-01 rx
9-SW-10 515-0215-00 tx
515-0215-01 rx
9-SW-11 515-0215-00 tx
515-0215-01 rx
9-SW-12 515-0215-00 tx
515-0215-01 rx
9-SW-13 515-9783-00-00
9-SW-15 520-8115-00 tx
520-8116-00 rx
9-SW-0 515-0215-00 tx
515-0215-01 rx
9-SW-1 500-9935-04
9-SW-2 515-9784-00-00
9-SW-3 515-9784-00-00
9-SW-26 180-5119-02
9-SW-27 180-5119-02
9-SW-17 515-0215-00 tx
515-0215-01 rx
Continued on next page...
