Left Return Ramp Assembly; Right Return Ramp Assembly - Stern Pinball STRANGER THINGS Service And Operation Manual

PARTSREFERENCE
5.36 LEFT RETURN RAMP
ASSEMBLY
500-1180-00
ITEM NO. PART NUMBER
1 545-1117-00 RIGHT RETURN PLASTIC RAMP, GOONIES
13
2 545-5105-00 RUBBER BUMPER
3 254-5000-09 NYLON SPACER - BLACK - 3/8 OD X .175 ID X 1/4"
4 830-8434-17 PLASTIC #17, GOONIES
5 237-5504-00 SCREW, 6-32 X 3/4" PPH MS
6 242-5001-00 #6 WASHER
7 240-5005-00 6-32 NYLON STOP NUT
8 550-5031-02 MINI MARS W/ EARS - RED SB
9 520-7000-00 SINGLE FLASH LED BOARD
10 232-5202-00 SCREW, 6-32 X 1/2" PPH MS SEMS
11 550-5052-01 MINI POST - CLEAR
12 237-5809-00 SCREW, #6 X 1/2" PTH A
99* 036-8068-10 CABLE, GENERIC 2-PIN 10"
11
3
4
2
ID PartNumber Description
1 545-1116-00 LEFT RETURN PLASTIC RAMP, STRANGER
THINGS
2 545-5105-00 RUBBER BUMPER
3 550-5031-02 MINI MARS W/ EARS - RED SB
4 520-7000-00 SINGLE FLASH LED BOARD
5 830-8434-50 PLASTIC #50, STRANGER THINGS
6 254-5000-14 NYLON SPACER - BLACK - 3/8 OD X .175
ID X 5/8"
7 237-5508-00 SCREW, 6-32 X 1-1/4 PPH MS
8 242-5001-00 #6 WASHER
9 240-5005-00 6-32 NYLON STOP NUT
10 254-5000-09 NYLON SPACER - BLACK - 3/8 OD X .175
ID X 1/4"
11 830-8434-16 PLASTIC #16, STRANGER THINGS
12 237-5504-00 SCREW, 6-32 X 3/4" PPH MS
13 232-5202-00 SCREW, 6-32 X 1/2" PPH MS SEMS
99* 036-8068-10 CABLE, GENERIC 2-PIN 10"
54
DESCRIPTION QTY.
1
12
7
1
2
1
8
2
3
3
8
1 5
1
1
1
1
6
1
10
3
4
9
STRANGER THINGS PREMIUM MANUAL 500-55Y2-01
5.37 RIGHT RETURN RAMP
ASSEMBLY
500-1181-00
11
12
1
1
Qty
1
ID PartNumber
1 545-1117-00
1
2
2 545-5105-00
2
3 254-5000-09
1
2
4 830-8434-17
5 237-5504-00
2
6 242-5001-00
5
7 240-5005-00
5
8 550-5031-02
2
9 520-7000-00
10 232-5202-00
1
11 550-5052-01
2
12 237-5809-00
1
99* 036-8068-10
2

RIGHT RETURN RAMP ASSEMBLY

STRANGER THINGS PRO
500-1181-00
10
5
6
4
8
9
7
3
7
Description
RIGHT RETURN PLASTIC RAMP, STRANG-
ER THINGS
RUBBER BUMPER
NYLON SPACER - BLACK - 3/8 OD X .175
ID X 1/4"
PLASTIC #17, STRANGER THINGS
SCREW, 6-32 X 3/4" PPH MS
#6 WASHER
6-32 NYLON STOP NUT
MINI MARS W/ EARS - RED SB
SINGLE FLASH LED BOARD
SCREW, 6-32 X 1/2" PPH MS SEMS
MINI POST - CLEAR
SCREW, #6 X 1/2" PTH A
CABLE, GENERIC 2-PIN 10"
