- Page 1 Installation Manual MANTA Device platform ET-xx7 / MT-xx7 SERIES 400 PANEL PCs SERIES 500 THIN CLIENTs SERIES 600 KVM SYSTEMS Installation Manual version: 01.00.03 Issue: 16.08.2024...
-
Page 2: Disclaimer
The terms and names used in this document are registered trademarks and / or products of the companies in question. Copyright © 2024 by R. STAHL HMI Systems GmbH. Subject to alterations. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024... -
Page 3: Table Of Contents
Step-by-step mounting instructions Elbow mounting with barcode scanner 8.6.1 View 8.6.2 Dimensions 8.6.3 Step-by-step mounting instructions Electrical installation Connection of X10 power supply Stand / elbow earthing R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 3 of 36... - Page 4 Ethernet interface X16 9.3.1 TX or 2TX with SERIES 400 / 500 9.3.2 TX with SERIES 600 9.3.2.1 Data lines Ethernet optical fiber interface Release notes R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 4 of 36...
-
Page 5: Intended Use And Location
Non-compliance results in severe or fatal injuries. WARNING Non-compliance can result in severe or fatal injuries. CAUTION Non-compliance can result in minor injuries. NOTE Non-compliance may result in material damage. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 5 of 36... -
Page 6: Further Documents
Operating Instructions IT-xx7 (OI_IT_xx7) Operating Instructions Keyboard KB2 (OI_Keyboard_KB2) Operating Instructions UB03 (OI_UB03) Operating Instructions Barcode scanner IDM (OI_Scanner_IDM) For documents in other languages, see r-stahl.com. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 6 of 36... -
Page 7: Warning
Non-compliance may result in mechanical damage to the stand / elbow coupling. Only open the enclosure doors for installation purposes ! Do not leave the enclosure doors open permanently ! R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 7 of 36... -
Page 8: Enclosure Types
Left Front Right HSG-xx7-VxA-CFR with front door for cleanroom Left Front Right HSG-xx7-VxA-BD with back door as standard Left Front Right R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 8 of 36... -
Page 9: Mounting
Mounting Installation Manual ET-/MT-xx7 Mounting Mounting types on MPFL stand Wall-mounted, with bracket Mounted upright on elbow Mounted hanging from elbow R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 9 of 36... -
Page 10: Mounting Illustration
Installation Manual ET-/MT-xx7 Mounting Mounting illustration Mounted on stand Ceiling mounted with stand pipe Elbow upright mounting Mounted hanging from elbow Wall mounting R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 10 of 36... -
Page 11: Mounting Accessories
HSG-xx7-VxA-CFR with keyboard Elbow upright Mounted hanging Mounted on stand Wall mounting mounting from elbow Keyboard with UB03 Handheld barcode scanner Bluetooth barcode scanner R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 11 of 36... -
Page 12: Recommended Mounting Type
No restriction with / without external keyboard Mounted on elbow hanging. No restriction with / without external keyboard Wall mounting, No restriction with / without external keyboard R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 12 of 36... -
Page 13: Assembly Notes
The stand / elbow must be mounted with at least 4 fastening points. The type of wall fixing used must be suitable for the wall material. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 13 of 36... -
Page 14: Tools
1x Phillips screwdriver size 2 1x flat-bladed screwdriver 2.5 mm 1x Allen key 5 mm Mounting the stand or wall-mounting will require other tools not specified here. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 14 of 36... -
Page 15: Mechanical Installation
Non-compliance can result in severe injuries and damage to the device. Always have two people mount the devices. Dimensions 8.1.1 Enclosure versions Dimensions in mm. HSG-xx7-VxA-FR and HSG-xx7-VxA-BD HSG-xx7-VxA-CFR R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 15 of 36... - Page 16 Choose suitable mounting screws, rawlplugs and bolts depending on the actual local requirements and possibilities. Mounting tongue dimensions Ø 10.20 Ø10.20 R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 16 of 36...
-
Page 17: Kb2 Keyboard
MPFL Stand Dimensions [mm] 1240 1216 Ø 60.3 Ø 88.9 Ø 200 Ø 18 45° Cable glands M25 x 1.5 M25 x 1.5 M20 x 1.5 R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 17 of 36... -
Page 18: Mpw Elbow
View of enclosure body without front door and Operator interface Designation Number Keyboard M6 x 20 carriage bolt Mounting flange seal Self-locking M6 nut M6 split washer R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 18 of 36... -
Page 19: Mounted On Stand
Step-by-step mounting instructions Choose suitable mounting screws, rawlplugs and bolts depending on the actual local requirements and possibilities ! SW 24 8x M16 See dimensions "Stand" R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 19 of 36... - Page 20 Installation Manual ET-/MT-xx7 Mechanical Installation Earthing stand (see chapter 8.2) Stand / elbow Mounting coupling M6 Allen screw 5 mm R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 20 of 36...
- Page 21 Mechanical Installation Installation Manual ET-/MT-xx7 Mounting holes, for hanging mount Mounting holes, for upright mount Enclosure operating device R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 21 of 36...
- Page 22 Installation Manual ET-/MT-xx7 Mechanical Installation Coupling (pre-mounted) R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 22 of 36...
- Page 23 Mechanical Installation Installation Manual ET-/MT-xx7 Turn entire enclosure ! Tighten all 4 screws with a torque of 10 Nm ! 5 mm R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 23 of 36...
- Page 24 Installation Manual ET-/MT-xx7 Mechanical Installation Connection bolt for equipotential bonding for Operator Stations (OS) are already pre- wired to the multiple connection (*2). R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 24 of 36...
-
Page 25: Mounting On Stand With Barcode Scanner
Mounting on stand with barcode scanner 8.4.1 View FR enclosure with handheld barcode scanner with Bluetooth barcode scanner CFR enclosure with handheld barcode scanner with Bluetooth barcode scanner R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 25 of 36... -
Page 26: Dimensions
Dimensions for mounting on stand with handheld barcode scanner C Max Enclosure A Max B Max Dimensions for mounting on stand with Bluetooth barcode scanner C Max Enclosure A Max B Max R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 26 of 36... -
Page 27: Step-By-Step Mounting Instructions
Holder for Bluetooth barcode scanner M5 x 12 screw M25 nut M25 cable gland The M25 cable gland is usually already installed in the HSG enclosure. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 27 of 36... -
Page 28: Mounted On Elbow
FR enclosure CFR enclosure Dimensions Enclosure B Max C Max The dimensions of the upright or hanging mounting are identical for both of the enclosure versions. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 28 of 36... -
Page 29: Step-By-Step Mounting Instructions
See dimensions "elbow" SW 24 8x M16 Elbow earthing (see chapter 8.2) For all other mounting steps, proceed as described for the stand mounting from step 3 onwards. R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 29 of 36... -
Page 30: Elbow Mounting With Barcode Scanner
Elbow mounting with barcode scanner 8.6.1 View FR enclosure with handheld barcode scanner with Bluetooth barcode scanner CFR enclosure with handheld barcode scanner with Bluetooth barcode scanner R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 30 of 36... -
Page 31: Dimensions
8.6.3 Step-by-step mounting instructions Please refer to the chapters above for all mounting steps. For wall mounting, see chapter 8.5.3 For scanner mounting, see chapter 8.4.3 R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 31 of 36... -
Page 32: Electrical Installation
Only connect AC devices (see device label) to 100 - 240 VAC mains. Stand / elbow earthing Stand mounting plate Washer 2x Toothed washer Hexagon screw M6 x 16 Split washer Cable lug with eyelet R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 32 of 36... -
Page 33: Ethernet Interface X16
Green / white TRD1- Green TRD2+ White / blue TRD2- Blue TRD3+ White / brown TDR3- Brown SHLD Screen Connect shield to shielding bar (see diagram B) R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 33 of 36... -
Page 34: Data Lines
Installation Manual ET-/MT-xx7 Electrical installation 9.3.2.1 Data lines Wrong Correct Ethernet optical fiber interface R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 34 of 36... -
Page 35: 10 Release Notes
Change of keyboards, now KB2 Addition of "Wall mounting types" and "Barcode scanner" Addition of chapter "Further documents" Addition of chapter "Enclosure damage" Layout changes R. STAHL HMI Systems GmbH / IM_ET_MT-xx7_en_V_01_00_03.docx / 16.08.2024 Page 35 of 36... - Page 36 R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Cologne (Sales Support) +49 221 768 06 - 1200 (Technical Support) +49 221 768 06 - 5000 +49 221 768 06 - 4200 (Sales Support) sales.dehm@r-stahl.com (Technical Support) support.dehm@r-stahl.com r-stahl.com...
