Operating Instructions
Device platform MANTA
R. STAHL HMI Systems GmbH
HW-Rev.
HW-Rev.
HW-Rev.
HW-Rev. MT-4x7-*-BT:
HW-Rev. MT-5x7-*-BT:
HW-Rev. MT-5x7-*-P2:
Operating Instructions version:
SERIES 400 Panel PC
SERIES 500 Thin Clients
SERIES 600 KVM Systems
Adolf-Grimme-Allee 8
MT-4x7:
01.01.00
MT-5x7:
01.01.00
MT-6x7:
01.01.00
01.01.03
01.01.03
01.01.04
Doc.No.:
60000189
01.02.14
Issue date:
06.12.2019
MT-xx7
D 50829 Köln
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stahl 500 Series
Summary of Contents for Stahl 500 Series
-
Page 1: Operating Instructions
Operating Instructions Device platform MANTA MT-xx7 SERIES 400 Panel PC SERIES 500 Thin Clients SERIES 600 KVM Systems R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln HW-Rev. MT-4x7: 01.01.00 HW-Rev. MT-5x7: 01.01.00 HW-Rev. MT-6x7: 01.01.00 HW-Rev. MT-4x7-*-BT: 01.01.03 HW-Rev. -
Page 2: Disclaimer
Trademarks The terms and names used in this document are registered trademarks and / or products of the companies in question. Copyright © 2019 by R.STAHL HMI Systems GmbH. Subject to alterations. Page 2 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 3: Specific Markings
(e.g. magnifying glasses, telescopes and microscopes) from a distance of less than 100 mm may damage eyesight. (beam output at the emitting diode (TD-A, TD-B) or the fibre optic end). R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 3 of 44... -
Page 4: Table Of Contents
External, non-intrinsically safe circuits External inherently safe optical interface External intrinsically safe circuits Type code MT-4x7 (Panel PC) MT-4x7-*-BT (Panel PC) MT-5x7 (Thin Client) MT-5x7-*-BT (Thin Client) Page 4 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... - Page 5 Damaged sealing Troubleshooting 15.1 Repairs / hazardous substances Disposal 16.1 RoHS directive 2011/65/EC Mounting inside enclosure with MT-xx7 mounting-set Declaration of EC conformity 18.1 Release notes R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 5 of 44...
-
Page 6: Preface
Processor types All devices of 400 and 500 SERIES are fitted with modern, powerful processors. Depending on the type of application, different processor types are used for the HMI devices (see Technical Data). -
Page 7: Mt-4X7 (Series 400 Panel Pc)
The X13 interface is provided for this purpose. MT-5x7 (SERIES 500 Thin Client) The MT-5x7 devices of the 500 SERIES can be integrated into modern networks as Thin Clients or with a KVM box via KVM-over-IP. Digital Ethernet technology is used for the data transfer between KVM box and Remote System. -
Page 8: Technical Data
Flexible cable up to 2.5 mm² (AWG14) Fixed cable up to 4 mm² (AWG12) Recommended fuses 4 AT Max. operating voltage Um 250 VAC Page 8 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... - Page 9 OS = Operator Station Panel mount device (PM): devices without additional enclosure (HSG) and without additional HMI Types comment accessories Operator Station (OS): devices mounted inside additional enclosure (HSG) R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 9 of 44...
-
Page 10: Additionally For Mt-4X7 (Panel Pc)
Operating system Windows XP Embedded / Windows XP Professional / Windows 7 Ultimate (32 bit) Global language support Via Multi-Language interface of Windows XP Embedded (25 languages) Page 10 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 11: All Devices Starting From Hardware Revision 01.01.01
MT-577 devices starting from hardware revision 01.01.04 Processor type AMD GX-222GC Processor details 2.2 GHz; Dual Core, 10W TDP Graphics controller integrated AMD Radeon R5E graphics R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 11 of 44... -
Page 12: Resolution At Mt-6X7 (Kvm Systems) With Dvi3
1280 x 920 1280 x 800 1280 x 800 1152 x 864 1152 x 864 1024 x 768 1024 x 768 800 x 600 800 x 600 Page 12 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 13: Conformity To Standards
The sealing must be in correct position and must not be damaged. The nuts must be mounted with a torque of 1.0 Nm ... 1.4 Nm. R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 13 of 44... -
Page 14: Certificates
The EAC (TR) certificate is listed under the following certificate number: Certificate number: TC RU C-DE.ГБ04.B00478 CNEX The CNEX certification is listed under the following certificate number: Certificate number: CNEx19.3885X Page 14 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 15: Dnv / Gl
Ex tc ia IIIC [ia op is Da] IP66 T110°C Dc CNEX Ex nA nR [ia op is Ga] IIC T4 Gc Ex tD A22 [iaD op is] IP66 T110°C R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 15 of 44... -
Page 16: Power Supply
100 VDC (±10%) ≤ 250 VAC Max. operating voltage U Copper Ethernet (CAT7 1) (X16): Rated voltage 5 VDC (±10 %) ≤ 250 VAC Max. operating voltage U Page 16 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 17: External Inherently Safe Optical Interface
USB1i (X24): The maximum values are: F F = negligible H = negligible USB2i (X25): The maximum values are: F F = negligible H = negligible R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 17 of 44... -
Page 18: Type Code
MT-4x7-aa-bb-cc-dd-ee-ff-O30-hh Outdoor installation -30 °C * MT-4x7-aa-bb-cc-dd-ee-ff-gg-AL Aluminium front plate MT-4x7-aa-bb-cc-dd-ee-ff-gg-RM Rear mount module NOTICE * The O30 option is only available for AC devices ! Page 18 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 19: Mt-4X7-*-Bt (Panel Pc)
Outdoor installation -30 °C [-22 °F] * MT-4x7-aa-BT-bb-cc-dd-ee-ff-gg-hh-AL Aluminium front plate MT-4x7-aa-BT-bb-cc-dd-ee-ff-gg-hh-RM Rear mount module NOTICE * The O30 option is only available for AC devices ! R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 19 of 44... -
Page 20: Mt-5X7 (Thin Client)
MT-5x7-aa-bb-cc-dd-O30-ff Outdoor installation -30 °C * MT-5x7-aa-bb-cc-dd-ee-AL Aluminium front plate MT-5x7-aa-bb-cc-dd-ee-RM Rear mount module NOTICE * The O30 option is only available for AC devices ! Page 20 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 21: Mt-5X7-*-Bt (Thin Client)
Outdoor installation -30 °C [-22 °F] * MT-5x7-aa-BT-bb-cc-dd-ee-ff-gg-hh-AL Aluminium front plate MT-5x7-aa-BT-bb-cc-dd-ee-ff-gg-hh-RM Rear mount module NOTICE * The O30 option is only available for AC devices ! R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 21 of 44... -
Page 22: Mt-577-*-P2 (Thin Client)
MT-577-aa-P2-bb-cc-dd-128GB-ff-gg-hh-ii 128 GB Solid State Drive MT-577-aa-P2-bb-cc-dd-ee-ff-AC-hh-ii Power supply 100 - 240 VAC, 50 - 60 Hz MT-577-aa-P2-bb-cc-dd-ee-ff-DC-hh-ii Voltage supply 24 VDC MT-577-aa-P2-bb-cc-dd-ee-ff-gg-hh-AL Aluminium front plate Page 22 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 23: Mt-6X7 (Kvm Systems)
The O30 option is only available for AC devices ! NOTICE * The DVI2 KVM solution is only available together with the MT-667 HMI device ! R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 23 of 44... -
Page 24: Safety Information
National safety and accident prevention rules apply. Use the device for its intended purpose only. No changes to the device are permitted. The enclosure may only be opened by R. STAHL HMI Systems GmbH. The first four digits of the serial number on the type plate stand for the year of manufacture. - Page 25 Ex nA connection box close to the associated terminal. At the place of installation voltage must not exceed 250 V and short-circuit current must not exceed 1500 A. R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 25 of 44...
-
Page 26: Only For Hmi Devices With Dvi3
10.2.1 Only for HMI devices with DVI3 The USB interfaces of the MT-6x7-DVI3 devices are only certified for the connection of keyboards and pointer units from R. STAHL HMI Systems GmbH. Page 26 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 27: Tightening Torque
10.4 Special conditions Equipotential bonding must be established for the external intrinsically safe circuits of the accessories to be connected, e.g. display, keyboard or pointer device. R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 27 of 44... -
Page 28: Assembly And Disassembly
Tightening torque The tightening torque of the nuts for the fixing bolts of the NOTICE MT-4x7/5x7/6x7 panel mount devices is 1.2 Nm (+- 0.2 Nm) ! Page 28 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 29: Operation
(2TX not SHLD SHLD Screen Screen 600 SERIES) Optical fibre connection type LC Ethernet optical fibre FO 1 Duplex connector interface * Data Ex op is R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 29 of 44... - Page 30 CH4 / line in right Black 600 SERIES) Black X105 LS1+ Audio sound LS1- Black Ex nA interface LS2+ (optional) LS2- Black not for MT-577-*-P2 Black devices Page 30 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019...
- Page 31 The shrink sleeving / vulcanisation must NOT be light blue. When the data cables are shortened, this must also be kept in mind. R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 31 of 44...
-
Page 32: General Information
For further information regarding this Write Protection (EWF), please refer to the OpenHMI_help_en.chm help file DOCUMENTATION in the "STAHL" folder on the device or on the CD / DVD / USB stick that is included in the delivery. 13.2.2 Windows® 10 IoT Enterprise 2016 LTSB operating system The operating system is based on Windows 10 for PC platforms with 64 bit x86 processors. -
Page 33: Recovery
This requires an active internet connection to a Microsoft server ! 13.2.2.2 Company-specific Windows installations The Windows 10 IoT license key is tied to STAHL images ! The installation of own Windows 10 IoT operating systems requires a NOTICE separate license key ! All necessary drivers are provided by R.STAHL HMI Systems GmbH. -
Page 34: Data Loss
In the case of applications that require constant writing into memory, NOTICE R. STAHL HMI systems recommends you use external storage media (USB sticks, network servers) for these write processes. Try and avoid cyclical writes (log files, databases, etc.) to the SSD ! The endurance of an SSD depends on the number of write cycles (TBW / terabytes written). -
Page 35: Maintenance
– if requested – have been authorized by the manufacturer. 15.1 Repairs / hazardous substances An error description must be enclosed with any units returned to R. STAHL HMI Systems GmbH for repairs. Remove all material residues. Please pay particular attention to the seal grooves and slits where material residues may be lodged. -
Page 36: Disposal
2011/65/EC, extends its area of application to all electric and electronic products. The HMI devices are conform with the requirements from RoHS directive 2011/65/EU, dated 03.01.2013. Page 36 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... -
Page 37: Mounting Inside Enclosure With Mt-Xx7 Mounting-Set
Operating Instructions MT-xx7 Mounting inside enclosure with MT-xx7 mounting-set 17 Mounting inside enclosure with MT-xx7 mounting-set R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 37 of 44... - Page 38 Operating Instructions MT-xx7 Mounting inside enclosure with MT-xx7 mounting-set Page 38 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019...
-
Page 39: Declaration Of Ec Conformity
Operating Instructions MT-xx7 Declaration of EC conformity 18 Declaration of EC conformity R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 39 of 44... -
Page 40: Rcm
Operating Instructions MT-xx7 Declaration of EC conformity 18.1 Page 40 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... - Page 41 Operating Instructions MT-xx7 Declaration of EC conformity R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019 Page 41 of 44...
-
Page 42: Release Notes
"Connections" Formal changes Version 01.02.13 Renew CNEX certification Version 01.02.14 Addition of section "Touch driver" Removal of notice in section "General Information" Page 42 of 44 R. STAHL HMI Systems GmbH / OI_MT_xx7_en_V_01_02_14.docx / 06.12.2019... - Page 44 R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln (switchboard) +49 221 76 806 - 1000 (Hotline) +49 221 76 806 - 5000 +49 221 76 806 - 4100 (switchboard) office@stahl-hmi.de (hotline) support@stahl-hmi.de r-stahl.com stahl-hmi.de...
