  • Page 1 Operating instructions MANTA GMP device platform IT-xx9 SERIES 400 Panel PC SERIES 500 Thin Clients SERIES 700 Direct Monitors R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Cologne HW-Rev. IT-4x9: 01.00.12 HW-Rev. IT-5x9: 01.00.12 HW-Rev. IT-7x9: 01.00.11 Operating Instructions Version: 01.00.07...

  • Page 2: Disclaimer

    The terms and names used in this document are registered trademarks and/or products of the companies in question. Copyright © 2019 by R. STAHL HMI Systems GmbH. Subject to alterations.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019...

  • Page 3: Formatting Conventions

    In ambient temperatures exceeding +45 °C the surface of the HMI devices may heat up. Caution when touching! Caution ! Incorrect replacement of batteries may result in explosion ! Dispose of used batteries as described in instructions.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 3 of 36...

  • Page 4: Table Of Contents

    11.2.3 Windows® 10 IoT Enterprise 2016 LTSB operating system 11.2.3.1 Recovery 11.2.3.2 Company-specific Windows installations 11.2.4 Initial start-up IT-479 (Panel PC) 11.2.5 Recovery Stick 11.2.6 Back-up  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 4 of 36...
  • Page 5 Switching off / closing down 11.2.8 Loss of data Maintenance Troubleshooting 13.1 Repairs / hazardous substances Disposal 14.1 RoHS directive 2011/65/EC Declaration of EC conformity Release notes  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 5 of 36...

  • Page 6: Preface

    Condition Monitoring. Multi-monitoring with several on-site terminals is as easy as the application as Thin Client in a server environment with virtual work stations.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 6 of 36...

  • Page 7: 7X9 (Series 700 Direct Monitors)

    PC via the USB connection at the IT-7x9. The PC in turn provides all software applications and functions without limitation and directly, thus ensuring full functionality in the production facility. Connecting this device series requires no specific IT expertise.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 7 of 36...

  • Page 8: Technical Data

    Real-time clock Real-time clock data buffer Lithium battery and capacitor buffered, maintenance-free Battery type BR2032 Battery buffer > 5 years Capacitor buffer at least 4 days  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 8 of 36...
  • Page 9 Mounting/ Installation Enclosure type Stainless steel enclosure (GMP) Mounting option Stand, mobile stand, wall bracket, dual monitor solution Components Keyboard optional, 107 keys with trackball or touchpad  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 9 of 36...

  • Page 10: Conformity To Standards

    Type designation IT-479-2TX / IT-579-2TX / IT-779-DVI0 CE classification: Power supply HMI devices Supply voltage: 100 - 240 VAC, 50 - 60 Hz max. power consumption:  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 10 of 36...

  • Page 11: Type Code

    GMP enclosure Class C, vertical, V2A IT-479-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G101 stainless steel (SS304), mounted on stand GMP enclosure Class C, inclined, V2A IT-479-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G201 stainless steel (SS304), mounted on stand  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 11 of 36...

  • Page 12: 579-2Tx (Thin Client)

    GMP enclosure Class C, vertical, V2A IT-579-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G101 stainless steel (SS304), mounted on stand GMP enclosure Class C, inclined, V2A IT-579-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G201 stainless steel (SS304), mounted on stand  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 12 of 36...

  • Page 13: 779-Dvi0 (Direct Monitors)

    GMP enclosure Class C, vertical, V2A IT-779-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G101 stainless steel (SS304), mounted on stand GMP enclosure Class C, inclined, V2A IT-779-aa-bb-cc-dd-ee-ff-gg-hh-ii-jj-kk-ll-G201 stainless steel (SS304), mounted on stand  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 13 of 36...

  • Page 14: Safety Information

     National safety and accident prevention rules apply.  Use the device for its intended purpose only.  No changes to the device are permitted. The enclosure may only be opened by R. STAHL HMI Systems GmbH.  The first four digits of the serial number on the type plate stand for the year of manufacture.

  • Page 15: Cable Glands

    (Betriebsicherheitsverodnung - Occupational Health and Safety).  Mounting, connection, commissioning, repair and maintenance may only be carried out by qualified staff specially trained for this purpose.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 15 of 36...
  • Page 16 673 mm 672 mm 736 mm 450 mm Ø 165 mm 174 mm vertical 673 mm 680 mm 736 mm 450 mm Ø 165 mm 174 mm  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 16 of 36...
  • Page 17 676 mm 1713 mm 403 mm 1310 mm 1500 mm 370 mm vertical 673 mm 684 mm 1721 mm 411 mm 1310 mm 1496 mm 373 mm  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 17 of 36...

  • Page 18: Gmp Device With Barcode Scanner

    - the same scanner location and the same additional dimensions (E) for the scanner assembly. Dimensions E fixed cable Bluetooth 85 mm 107 mm  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 18 of 36...
  • Page 19 GMP device GMP devcie with keyboard with keyboard Note without with keyboard and barcode and RFID keyboard scanner reader 730 mm 830 mm 950 mm 950 mm  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 19 of 36...
  • Page 20 The keyboard is always mounted beneath the main monitor of the SERIES 400 / 500 device. This combination can be either on the left NOTICE (as shown at the picture) or on the right hand side.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 20 of 36...
  • Page 21 NOTICE The operating device at the bottom is always the SERIES 400 / 500 main monitor, the top operating device is the SERIES 700 monitor.  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 21 of 36...
  • Page 22 Operating Instructions OS-IT-xx9 Mounting and dismounting 9.2.10 Dual monitor with RFID reader  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 22 of 36...
  • Page 23 Operating Instructions OS-IT-xx9 Mounting and dismounting 9.2.11 Dual monitor with barcode scanner fixed cable Bluetooth fixed cable Bluetooth  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 23 of 36...

  • Page 24: Commissioning

    RJ-45 connector Ethernet interface copper connection 2 (Data) 1……8 COM1 9-pin sub-D plug Serial interface RS-232 (male) (serial) COM2 9-pin sub-D plug Serial interface RS-232 (male) (serial)  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 24 of 36...
  • Page 25 PC (or its function can be defined as such via the system control). The use of a loudspeaker also requires the optional audio amplifier (see type key).  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 25 of 36...

  • Page 26: Series 700

    (T3) (see type code). In this case, the USB connection is used to transmit the touch NOTICE signals to the connected PC. Max. recommended cable length for USB:  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 26 of 36...

  • Page 27: General Information

    For further information on this write protection (EWF), please refer to the OpenHMI_help_en.chm help file in the DOCUMENTATION "STAHL" folder on the HMI device or on the CD / DVD / USB stick that is included in the delivery. 11.2.3 Windows®...

  • Page 28: Recovery

    This requires an active internet connection to a Microsoft server ! 11.2.3.2 Company-specific Windows installations The Windows 10 IoT license key is tied to STAHL images ! The installation of own Windows 10 IoT operating systems requires a NOTICE separate license key ! All necessary drivers are provided by R.STAHL HMI Systems GmbH.

  • Page 29: Switching Off / Closing Down

    In the case of applications that require constant writing into memory, NOTICE R. STAHL HMI Systems GmbH recommends you use external storage media (USB sticks, network servers) for these write processes. Try and avoid cyclical writes (log files, databases, etc.) to the SSD.

  • Page 30: Maintenance

    13 Troubleshooting 13.1 Repairs / hazardous substances An error description must be enclosed with any units returned to R. STAHL HMI Systems GmbH for repairs. Remove all material residues. Please pay particular attention to the seal grooves and slits where material residues may be lodged.

  • Page 31: Declaration Of Ec Conformity

    Operating Instructions OS-IT-xx9 Declaration of EC conformity 15 Declaration of EC conformity  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 31 of 36...

  • Page 32: Release Notes

     Addition of drawings in section "Mounting options / dimensions"  Change to dimension "height"  Formal changes Version 01.00.07  Addition of section "Touch driver"  R. STAHL HMI Systems GmbH / OI_IT_xx9_en_V_01_00_07.docx / 06.12.2019 Page 32 of 36...
