Screen Connection

19. While the receiving card is configured， click the "screen connection" button in the menu
bar of the receiving card configuration interface to enter the screen window interface.
Load：load the saved screen configuration file.
1
Save to file：save the display configuration information to the computer in (.* dcc )
2
format.
Send：send screen configuration information to the sending and receiving cards.
3
Read back：click this button will read back the existed screen connection
4
configuration from the good working receiving card so that can quickly send to the new
receiving card.
Open Box sign：click this button then will auto show the receiving card numbers in
5
correct order in each cabinet.
Receiving card quantity：it will show all receiving cards numbers，there are
6
normally two digits， for example： [1.0] means Ethernet port 1 of sending card has connected
1 receiving card，while Ethernet port 2 of sending card no receiving card.
Notes:
When do the connection operation of the current display. firstly clickthe "refresh" button to
refresh all the receiving card to check whether thechip number (usually receiving card
number) is consistent with the number ofthe connected，if not consistent，please check the
hardware connection ， whenconnecting several sending cards please switch to find the
correspondingsending card for debugging.
