7.
Please enter the correct parameters to the smart setup dialogue box .
Module width/height: Input the actual pixel of the current pixel.
1
Module data group: View the interface definition of module data input port and
2
calculate according to the actual data line number and grouping mode of module.(Generally,
three lines are parallel,so an RGB is a set of data. For example,if a module has two sets of
RGB,then the module data group is 2)
Card type:Type of receiving card currently used for debugging which can directly
3
view according to the identity on the receiving card.
Blanking polarity: Low/high effective,normally use the default one.
4
Contrl system: Please choose T6(D90 series) or FPGA(D80 series) according to your
5
receiver card types.
Drive chip : Select the type of drive chip used in the current module , such as :
6
conventional chip,MBI5153,ICN2053,etc.
Decoding method: "138 decoding","5958 decoding","high direct output" ,
7
etc.
Grouping mode: Viewing the interface definition of the current module data input
8
port, if having R/G/B three colors (red, green and blue) signal data (red, green, and blue lights
on driver chip is separate connection,and no string between them,thus choose "parallel
three line";If there is only one color signal data on the module or only one R data (In addition
to the single color screen , and the chip controlling the red , green and blue LED lights is
connected together),then select "RGB serial".
Double clock : No need to choose when configure normal module. Only need to
9
