Infrared Proximity Sensor
Installation Manual
CS-PD535-TAQ shown
5024193
Conforms to
UL Std. 294
Specifications
Model
Operating voltage
Current draw (max.)
Relay type
Connectors
Response time
Output time
Sensing range
Standby
LED
Indicators
Triggered
Relay
Operating
life
Sensor
Case material
Operating temperature
Dimensions
Destructive attack level
Line security
Endurance level
Standby power
*
Default, reversible by jumper
Installation
1. The sensor is meant to be installed on a rigid thin surface, maximum
thickness
/
" (2mm).
1
16
2. Disassemble the sensor and cut a hole in the mounting surface slightly
smaller than the front sensor plate 1
3. Reassemble as illustrated on pg. 2 except for the back cover.
4. Punch and thread the wires through the wiring grommet. Connect them to the
terminal block. Power must be provided by a low-voltage power-limited/Class
2 power supply and low-voltage field wiring not to exceed 98.5ft (30m).
5. To adjust the sensor's range, turn the trimpot counterclockwise (decrease) or
clockwise (increase) (see Fig. 1).
CS-PD535-TAQ
12~24 VAC/VDC
120mA@12VDC
Form C dry contact, 3A@24VDC
Quick-connect, screwless terminal block
10ms
Adjustable, 0.5~30 sec., toggle, or as long as sensor is
triggered
Adjustable, 2
/
3
8
Red*
Green*
500,000 cycles
100,000 hours
ABS Plastic
-4°~131° F (-20°~55° C)
1
/
"x2
/
"x1
/
" (44x55x37 mm)
3
1
7
4
8
16
Level I
Level I
Level IV
Level I
/
" (35mm) wide and 1
3
8
No-touch operation reduces the risk of spread of
germs, viruses, etc., through cross-contamination
Adjustable sensor range 2
relay, adjustable trigger duration 0.5~30 seconds
or toggle
LED illuminated sensor area for easy identification
Selectable LED colors (CS-PD535-TAQ turns from
red to green or green to red, CS-PD535-TBQ turns
from blue to green or green to blue) when the
sensor is activated
Model
CS-PD535-TAQ
CS-PD535-TBQ
Parts List
1x Proximity sensor
CS-PD535-TBQ
"~8" (6-20 cm)
Blue*
Green*
/
" (45mm) high.
3
4
/
"-8" (6~20 cm), 3A
3
8
LED (standby/triggered)
Green/Red
Green/Blue
1x Manual
Overview
1
/
"
7
16
(37mm)
1
/
"
1
4
(32mm)
/
"
5
16
(8mm)
1
/
"
1
8
(29mm)
1
/
"
3
4
(44mm)
1
/
"
11
16
(43mm)
Fig. 1
LED Color
adjustment jumper
Output duration
potentiometer
Sensor range
potentiometer
Terminal block
+
–
COM NO NC
Power
Relay
Input
output
2
1/
"
8
(55mm)
2"
(50mm)
