SECO-LARM ENFORCER E-931-S45RRQ Installation Manual

Retro-reflective photoelectric beam sensor

Download this manual

Retro-Reflective Photoelectric

Beam Sensor

E-931-S45RRQ

Installation Manual

The ENFORCER E-931-S45RRQ Retro-Reflective Photoelectric Beam Sensor provides reliable

sensing of objects that enter the space between the sensor and reflector, thus breaking the

infrared beam. It is suitable for various types of detection such as sensing approaching vehicles to

open a garage door or outdoor gate, as an entry notification for stores, to assist in measuring

parking distances, or an alarm notification, as well as many other uses.

 Range 45ft (14m)

 Weatherproof (IP66) construction for indoor/outdoor usage

 Pre-wired 6.5ft (2m) cord

 Bracket and mounting hardware included for both sensor and reflector

 Adjustable response time and sensing range

 Compact size

CAUTION

 This sensor was not designed to prevent bodily injury or loss of life.

 This sensor was not designed for use in environments where explosive gases may be present.

 Use of this sensor in certain security applications may be regulated by local laws or codes.

SECO-LARM is not responsible for compliance with such laws or codes.

Need help?

Do you have a question about the ENFORCER E-931-S45RRQ and is the answer not in the manual?

Page 1  This sensor was not designed for use in environments where explosive gases may be present.  Use of this sensor in certain security applications may be regulated by local laws or codes. SECO-LARM is not responsible for compliance with such laws or codes.
Page 2 ″ ″ 2″ (82mm) (63mm) (51mm) ø ″ (ø6mm) ′ (2m) cable ® ″ ″ ″ (4.5mm) thru holes (5mm) (29mm) ″ (9mm) Sample Installations Parking Distance Monitor Main Entrance Door Garage Door Store Entrance Entry Gate SECO-LARM U.S.A., Inc.
Page 3  Correct alignment is reached when the red LED is OFF sensitivity setting. and the yellow LED is ON.  If both LEDs are OFF, the sensor is at the edge of signal range and may not work properly. SECO-LARM U.S.A., Inc.
Page 4 SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
