Computer
AIM-78H Series
Startup Manual
AIM-78H Appearance
Left: Front View Right: Rear View
For more information on this and other
Advantech products, please visit our website
at:
http://www.advantech.com
For technical support and service, please visit
our support website at:
http://support.advantech.com
This manual is for AIM-78H Series
Description of Parts
First Edition
June 2021
A: Front Camera
B: Power LED
C: Light Sensor
D: Speaker
E: micro-SIM & micro-SD Card Door
F: Programmable Key (Default
Barcode scanner)
G: Docking Connector (USB3.0 )
H: USB 2.0 Type A
I: USB 3.0 Type C
J: Power Button
K: Volume Key (Up/Down)
L: Audio Jack (Headset Combo)
M: Extension Module
N: NFC
O: Rear Camera with LED Flash
P: Battery Cover
Q: DC-IN
