AIM8I Computer
User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIM8I and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech AIM8I

  • Page 1 AIM8I Computer User Manual...
  • Page 2 Copyright The documentation and the software included with this product are copyrighted 2017 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 3: Declaration Of Conformity

    Declaration of Conformity CE Conformity Statement Radio products with the CE alert marking comply with the R&TTE Directive (1999/5/EC) issued by the Commission of the European Community. Compliance with this directive implies conformity to the following European Norms (in brackets are the equivalent international standards).
  • Page 4: Fcc Radiation Exposure Statement

    15.21 Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
  • Page 5 IC warning statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
  • Page 6 IC Radiation Exposure Statement This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC RSS-102. This equipment should be installed and operated with minimum distance 0 cm between the radiator & your body. Cet EUT est la conformite avec SAR pour la population generale / les limites d'exposition incontrolees dans IC RSS-102.
  • Page 7: Safety Instructions

    10. If the equipment is not used for long time, disconnect it from the power source to avoid being damaged by transient over-voltage. 11. Never pour any liquid into slots of the AIM8I Series. This could cause fire or electrical shock.
  • Page 8: Battery Safety

    Lithium Ion batteries may be stored at temperatures between -10°C to 60°C, however they may be depleted more rapidly at the high end of this range. It is recommended to store AIM8I within normal room T-W101 User Manual...
  • Page 9: Technical Support And Assistance

    Technical Support and Assistance Visit the Advantech website at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 10: Table Of Contents

    1.3 Package Contents ......................13 1.4 Product Specifications ....................13 1.4.1 Technical Specifications ............13 1.4.2 Product Outlook and Dimensions ..........16 1.5 Exploring the AIM8I....................... 17 1.5.1 Front View ................17 1.5.2 Rear View ................18 1.5.3 Right View................19 1.5.4 Left View ................
  • Page 11 5.2 Cleaning the AIM8I ......................28 5.3 Trouble Shooting ......................28 5.4 ENERGY STAR ....................... 29...
  • Page 12: Chapter 1 Introduction

    This user manual outlines all you need to know to set up and use your AIM8I. If you have any further questions or queries, contact our technical support team via our website: http://support.advantech.com.tw/...
  • Page 13: Product Features

    • Optional dock stations, including VESA/Vehicle dock & multi charger design. 1.3 Package Contents Ensure all the following items are present when you receive your AIM8I. If any of these items are missing, contact your dealer immediately. • AIM8I Computer •...
  • Page 14 Intel Atom x5-Z8350 Computing Max Speed 1.44 GHz System Memory 2GB LPDDR3 Windows 10 IoT Enterprise 64 bit On-board 32GB/64GB ( Default 32GB) Storage eMMC Micro-SD Micro-SD Card Slot for Storage Expansion Display Type 8” TFT IPS LCD Panel WUXGA, 1200x1920, 400 nits Display Resolution Touch Type...
  • Page 15 Operating 0~40 ° C (Charging) Temperature -10~50 ° C (Discharging) Temperature Operating: -10° C ~ +50° C, Storage: -20° C ~ +60° C Operating Environment & Storage 5% ~ 95% @ 40° C (non-condensing) Humidity Vibration Operation: (5-500GHz) 1G, Non-operating: (5-500GHz) 0.04PSD Ingress Dust/ Water IP-65 compliant...
  • Page 16: Product Outlook And Dimensions

    1.4.2 Product Outlook and Dimensions...
  • Page 17: Exploring The Aim8I

    1.5 Exploring the AIM8I 1.5.1 Front View Component Front Camera Power LED Light Sensor Speaker...
  • Page 18: Rear View

    1.5.2 Rear View Component Extension Module Rear Camera with LED Flash Battery Cover...
  • Page 19: Right View

    1.5.3 Right View Component SIM & SD Card Door Programmable Key (Default BCR) Pogo Pin (USB3.0) Micro USB Door...
  • Page 20: Left View

    1.5.4 Left View Component Micro HDMI Door Power Button Volume Key UP/Down 1.5.5 Bottom View Component Audio Jack (Headset Combo)
  • Page 21: Chapter 2 Getting Started

    Chapter 2 Getting Started 2.1 Charge the Computer To charge the embedded battery in AIM8I, connect the Micro USB adaptor on the AIM8I computer. Micro USB Connector Please charge for at least one hour when you use this computer for the first time.
  • Page 22: Turn On The Computer

    2.2 Turn on the Computer Push the Power Button (located at no. 2 of Section 1.5.4 Left View.) for 3 seconds to start the computer. Power Button 2.3 Sleep Mode While the computer is running, push the Power Button for 1 second will move the equipment into sleep mode for power saving.
  • Page 23: Operate The Computer

    2.4 Operate the computer AIM8I is equipped with a 8” Capacitive Touch Panel. Use finger to touch the following Active Area to operate the computer. Active Area 2.5 LED indicator status AIM8I is equipped with one LED indicator for battery status. The following shows LED status for different power states.
  • Page 24 Contact a wireless service provider for more information. Screens used in this manual are for illustrative purposes only. Actual screens may vary depending on your product version and pre-installed Operating System versions. AIM8I system power down when system battery level drops to 7%.
  • Page 25: Windows 10 Iot Enterprise Basic Setups

    3.1 Windows 10 IoT Enterprise Basic Setups Windows 10 IoT Enterprise Home Screen Function Program Launcher Battery Status Connect WLAN Adjust Audio Volume Open the On-screen keyboard...
  • Page 26: Chapter 4 Running Applications

    Chapter 4 Running applications 4.1 Installing applications There are multiple ways to install applications on AIM8I and this section shows the steps to install applications via Micro SD cards. 1. Before installation, please ensure your Micro SD card has been correctly formatted with FAT32 file system.
  • Page 27: Install Applications With Windows 10 Iot Enterprise

    4.1.1 Install applications with Windows 10 IoT Enterprise a) Go to Program Launcher b) Launch File Explorer and will find Secure Digital storage device (D:) c) Tap Secure Digital storage device (D:) to find .exe executable file. d) Tap .exe file to install the application.
  • Page 28: Chapter 5 Maintenance

    3. Power LED does not light up when DC power plug in. 4. System does not respond to touch behaviors. Contact your distributer, sales representative, or Advantech’s customer service center for technical support if you need additional assistance. Please have the following information ready before you call: Product name and serial number.
  • Page 29: Energy Star

    ENERGY STAR, and those that do are now more efficient than ever. It is an honor for Advantech to provide you such products. What is ENERGY STAR? ENERGY STAR is a U.S. Environmental Protection Agency (EPA) voluntary program that helps businesses and individuals save money and protect our climate through superior energy efficiency.
  • Page 30 AIM8I is to enter display sleep mode after 4 minutes and computer sleep mode after 10 minutes in default. To wake it from sleep mode, simply press the power button on the back cover, while under sleep mode it allows the device to save 80% or more energy.
