4. Technical data and characteristics

4.1 Dimensions and connections

Modello BlueHelix THETA 24 C - BlueHelix THETA 28 C
fig. 49- Front view
210
fig. 51- Top view
Key
7 Gas inlet - Ø 3/4"
8 DHW outlet - Ø 1/2"
9 Cold water inlet - Ø 1/2"
10 System flow - Ø 3/4"
11 System return - Ø 3/4"
74 System filling valve
145 Hydrometer
A6 Condensate discharge connection
EN
420
210
cod. 3540000274 - Rev. 01 - 04/2024
250
fig. 50- Side view
74
10 8 7 9
A6
45 65 67 67 65
fig. 52- Bottom view
145
11
80
111
