ASSEMBLE YOUR
SWIVEL BATH SEAT
Item # 9040
Capacity not to exceed 300 lbs
a. (1) Main Frame
b. (1) Backrest
a.
1
Take all components out of the packaging
and place bath seat main frame upside
down on a level surface with the aluminum
components facing upwards.
2
Depress the push button on each leg to
insert into the frame. You should hear
a "click" once the push button is fully
engaged.
PLEASE NOTE: For all push buttons,
you should hear a "click" once the push
button is fully engaged. Do not use
until the push button is fully engage
3
Depress the push buttons on backrest,
and insert into the backrest receivers
located on the bottom of the seat
platform. Ensure push buttons are fully
engaged and check by pulling upward on
the plastic backrest.
HOW TO
b.
WHAT'S INCLUDED
c. (2) Arms
d. (4) Legs
c.
e. (1) Showerhead Holder
d.
e.
Advertisement
Related Manuals for Nova SWIVEL BATH SEAT 9040
Summary of Contents for Nova SWIVEL BATH SEAT 9040
- Page 1 HOW TO ASSEMBLE YOUR SWIVEL BATH SEAT Item # 9040 Capacity not to exceed 300 lbs WHAT’S INCLUDED a. (1) Main Frame c. (2) Arms e. (1) Showerhead Holder b. (1) Backrest d. (4) Legs Take all components out of the packaging and place bath seat main frame upside down on a level surface with the aluminum components facing upwards.
- Page 2 Locate the arm receivers on each side of the frame and depress the push button to insert 1x arm on each side. Stand the unit upright. Use the push buttons on the legs to set the desired height. NOTE: ALL LEGS MUST BE SET TO THE SAME HEIGHT To engage the swivel mechanism, pull the lever away from the chair.
- Page 3 NOVA extends this warranty only to the original purchaser of this product. The warranty does not extend to any subsequent purchaser or owner. The warranty is void upon any sale or transfer of ownership or use by other person. NOVA warrants its...
