Miele PWM 908 DP Installations Plan page 9

PWM 908
Technical data
D r a i n p u m p ( D P )
Hose connection (external diameter)
Max. drainage temperature
On-site hose sleeve (int. diameter x length)
Max. transient flow rate
Max. delivery head (from lower edge of machine)
Drain hose DN 22 with connector (supplied as standard)
Connection hose length
E q u i p o t e n t i a l b o n d i n g ( P A )
Appliance connection (separate kit required)
X C I - B o x / X C I - A D i n t e r f a c e
P e a k l o a d / e n e r g y m a n a g e m e n t ( S L A )
Appliance connection (with XCI-Box)
P a y m e n t s y s t e m c o n n e c t i o n ( K G A )
Connection of payment systems (with XCI-Box / XCI-AD)
C o m m u n i c a t i o n m o d u l e ( X K M )
Communication module XKM 3200 WL PLT
L i q u i d d i s p e n s i n g ( D O S )
Connection for liquid detergents
Max. number of dispenser pumps
XCI-Box interface
I n s t a l l a t i o n o n a p p l i a n c e f e e t ( F )
No. of appliance feet
Appliance foot, height-adjustable with thread
Appliance foot diameter
A n c h o r i n g ( B )
Standard anchoring
Floor anchor kit (for 2 machine feet) with anchors
Wood screws according to DIN 571
Wall plugs (diameter x length)
Anchoring of Miele plinths
Accessory: Miele plinth (fasteners included)
Required anchor points
Wood screws according to DIN 571
Wall plugs (diameter x length)
Plinth floor anchoring (to be provided on site)
Appliance installation on on-site base (concrete or masonry)
Min. plinth installation footprint (W/D)
Wood screws according to DIN 571
Wall plugs (diameter x length)
 = standard,  = optional, + = only on request, - not available
11 284 920/05
PWM 908 DV PWM 908 DP
mm - 22 (DN22)
°C - 90
mm - 22 x 30
l/min - 26
mm - 1000

-
mm - 1500
 
 
 
 
 
 
No. 6 6
 
No. 4 4
mm +8 +8
mm 40 40
 
mm 6 x 50 6 x 50
mm 8 x 40 8 x 40
 
No. 4 4
mm 8 x 65 8 x 65
mm 12 x 60 12 x 60
 
mm 600/650 600/650
mm 6 x 50 6 x 50
mm 8 x 40 8 x 40
en-AU, NZ
9
