Miele PWM 908 DP Installations Plan page 10

PWM 908
Technical data
A p p l i a n c e d a t a
Overall appliance dimensions (H/W/D)
Casing dimensions (H/W/D)
Site-access dimensions (H/W)
Min. site-access opening (excl. packaging)
Installation dimensions
Side gap
Recommended side gap – washer-dryer stack
Recommended distance to opposite wall from appliance front
Weights and floor loads
Appliance weight (net weight)
Max. floor load in operation
Max. floor load, static
Max. floor load, dynamic
Emissions
Sound pressure level (in accordance with EN ISO 11204/11203)
Heat dissipation rate to installation site
 = standard,  = optional, + = only on request, - not available
10
PWM 908 DV PWM 908 DP
mm 850/605/714 850/605/714
mm 850/596/678 850/596/678
mm 900/605 900/605
mm 20 20
mm 300 300
mm 1000 1000
kg 103 103
N 2820 2820
N 1380 1380
N 1365 1365
dB(A) <70 <70
W 250 250
en-AU, NZ
11 284 920/05
