Technical Data - Miele PWM 908 DP Installations Plan

PWM 908

Technical data

Drum volume
Load capacity
Door opening diameter
Max. spin speed
g factor
E l e c t r i c a l c o n n e c t i o n ( E L )
Standard voltage (AU, NZ)
Frequency
Total rated load
Fuse rating
Supply cable min. cross-section
Supply cable with plug
Length of supply cable
Standard voltage (AU, NZ)
Frequency
Total rated load
Fuse rating
Supply cable min. cross-section
Supply cable with plug
Length of supply cable
Non-standard voltages MAR 400/440/480 (Marine)
Frequency
Total rated load
Fuse rating
Supply cable min. cross-section
Supply cable without plug
Length of supply cable
Non-standard voltages MAR 230 (Marine)
Frequency
Total rated load
Fuse rating
Supply cable min. cross-section
Supply cable without plug
Length of supply cable
C o l d w a t e r ( K W )
Permissible water flow pressure
Required flow rate (cold water connection only)
Required flow rate (with additional hot water connection)
Connection to be provided on site, external thread according to AS 3688 (flat seal) Inch
Connection hose ½" with ¾" threaded union
Connection hose length
H o t w a t e r ( W W )
Max. water intake temperature
Permissible water flow pressure
Required flow rate
Connection to be provided on site, external thread according to AS 3688 (flat seal) Inch
Connection hose ½" with ¾" threaded union
Connection hose length
D r a i n v a l v e ( D V )
Connection (ext. diameter)
Max. drainage temperature
Max. transient flow rate
 = standard,  = optional, + = only on request, - not available
8
PWM 908 DV PWM 908 DP
l 73 73
kg 8.0 8.0
mm 300 300
rpm 1600 1600
704 704
1N AC 230 V 1N AC 230 V
Hz 50 50
kW 5.5 5.5
A 1 x 25 1 x 25
mm² 3 x 2.5 3 x 2.5

-
mm 2000 2000
- 1N AC 230 V
Hz - 50
kW - 2.85
A - 1 x 16
mm² - 3 x 1.5

-
mm - 2000
- 3 AC 400/440/480 V
Hz - 50/60
kW - 3.6/4.2/5.0
A - 3 x 16
mm² - 4 x 1.5

-
mm - 2000
- 3 AC 230 V
Hz - 60
kW - 4.4
A - 3 x 16
mm² - 4 x 1.5

-
mm - 2000
kPa 100–1000 100–1000
l/min 11 11
l/min 10 10
¾" ¾"
 
mm 1550 1550
°C 70 70
kPa 100–1000 100–1000
l/min 11 11
¾" ¾"
 
mm 1550 1550
mm 75 (DN70) -
°C 90
l/min 62 -
en-AU, NZ
11 284 920/05
