SYNC FUNCTION

Install a 10k R20 resistor if the board is synchronized from
an external signal generator.
DEMO MANUAL DC1161B

EMI FILTER

Install EMI filters on the backside of the DC1161, however,
a trace cut is required for the insertion of the option circuit.
See Figure 3 for the cut line.
Figure 3. Cut Line for the EMI Filter Installation
CUT HERE
