Summary of Contents for GoPass ANL-901(C)

  • Page 2: Precaution Before Installation

    1. Precaution before Installation Prepare a SIM card for GSM communication. Use some other mobile phone to confirm that the PIN code has not been set, and that it can dial out and receive telephone calls without problem. Before install the SIM card, make sure to cut off power from the AVL unit. The correct installation method is to push the tray completely into the AVL unit, until you feel it is hooked by something.

  • Page 3: Installation

    (1) Unscrew and remove the back cover of your locator. Push the holder top upward to loose it. (2) Insert the SIM card by sliding it into the card holder slot, with the chip module facing to the connectors on PCB, as shown in the picture.

  • Page 4: Operating Instructions

    Slide the Park switch back to the right, the PARK LED will shut off; and Geo-fence (Park) function will be cut off. The accuracy of GPS positioning is liable to be affected by time, weather, & other environmental factors.

  • Page 5: Power Charging

    - make sure GPS has got position fixed, and the Orange LED “flashes once per second” - make a phone call to the AVL unit, and ask it to report its current position Complete the installation, and restore the interior of the car.
  • Page 6 Google Maps (from earth.google.com) (maps.google.com) then you can find the position fix in the map. Please find below the example. Step1. Send a SMS Command Code“111#8888＂to the GPS Tracker. Step2. GPS Tracker will send back the latitude & longitude data.
  • Page 7 (2) FIX IP Address is required for GooTrac Server (the computer to receive the GPS data sent by GPRS from the vehicle trackers); Intranet is not workable for the operation. If you do not have a FIX IP, you can use our FIX IP (59.120.2.234) for the real-time tracking.
  • Page 8 Step1. Set GPRS APN - send SMS command 600# to the tracker. 600#Password #APN#IP#User#APN_Password ex. 600#8888#airtelnet.es#0.0.0.0#vodafone#vodafone (You can find the right command in http://www.gopasstech.com by clicking "send my GPRS APN command".) Step2. Set IP Address - send SMS command 999# to the tracker.
  • Page 9 4. Data Switch -> Client After set up the GPS tracker, please go to "GooTrac” -> Tool" -> "Data Switch" -> "Client" -> "Add" and key-in the columns as follows. Target IP: 59.120.2.234 Target Port: 8088 Username: iptest Password: iptest...
  • Page 10 5. Get GPS data The position GPRMC data will be displayed in GooTrac main screen; you can start to track over Google Earth. - Press down icon will have the GPS position data forwarded to Google Earth. - Pick “...
  • Page 11 GPRS APN set-up. Please make sure the SIM card does support GPRS communication; and the GPRS function has been activated. Please note that WAP and MMS are not workable for real-time tracking; GPRS is a must for the operation. 600#Password#APN#IP#User#APN_Password Please send the SMS command "...
  • Page 12 (Please note that one can link to internet by WAP, or MMS, or GPRS; but only GPRS is good for real-time tracking; WAP & MMS are not workable - i.e. it is not for sure that the SIM Card does work on GPRS, even though you can link to internet with the SIM card.)
  • Page 13 For software update or technique support, please contact your local distributor or contact: http://www.gopasstech.com E-mail: support@gopasstech.com...
