1.2 Connectors and their Pinouts
1.2.4

Optional I/O Connector

The Optional I/O connector ("SAASM" or "FILL/Z") is used in conjunction with
the Option Board that is available for VersaSync. If the unit is not equipped with
an Option Board, this connector is not used.
1.2.5

Coaxial Connectors

VersaSync offers five (5) coaxial connectors. Standard configuration includes the
GNSS antenna input connector and (4) 10 MHz sinewave outputs. (Certain mod-
els may have variation on this setup. Refer to your purchase order for information
on your VersaSync model.)
The coaxial connectors (aside from the GNSS connection) produce a 10MHz out-
put that can be simultaneously disabled through the Web UI.
All coaxial connectors are standard SMA connectors (recommended torque
value: 8-10 in-lbs).
ETHERNET connector wiring:
POWER connector pinout
6
1 through 8: A Ethernet Connect, 4 pairs, 1000bT (in the software, eth0)
9 through 16: B Ethernet Connect, 4 pairs, 1000bT (in the software, eth1)
1: V , 10 to 32 V
Main DC
2: -not used-
3: V , 10 to 32 V
Standby
4: Ground return, standby power
5: Ground return, main power
(Standby Power)
DC
