- Page 1 OPERATING INSTRUCTIONS Original SERIES E ANGLE VALVE Electric Angle Valve...
- Page 2 Dear customer, Thank you for choosing a Pfeiffer Vacuum product. Your new Pfeiffer Vacuum valves should support you in your individual application with full performance and without malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a comprehensive and complete range of top-quality products and first-class service.
-
Page 3: Table Of Contents
Limits of use of the product Proper use Foreseeable misuse Personnel qualification 2.7.1 Ensuring personnel qualification 2.7.2 Personnel qualification for maintenance and repair 2.7.3 Advanced training with Pfeiffer Vacuum Product description Function Scope of delivery Identifying the product 3.3.1 Product types 3.3.2 Product features... - Page 4 List of tables List of tables Tbl. 1: Stickers on product Tbl. 2: Abbreviations used in this document Tbl. 3: Limits of use for Series E electric angle valve Tbl. 4: Product designation of electric angle valve with position indication Tbl.
- Page 5 List of figures List of figures Fig. 1: Series E electric angle valve Fig. 2: Vacuum connection Fig. 3: Connector pin usage Fig. 4: Dimensions of Series E electric angle valves 5/28...
-
Page 6: About This Manual
Keep the manual for future consultation. 1.1 Validity These operating instructions are a customer document of Pfeiffer Vacuum. The operating instructions describe the functions of the named product and provide the most important information for the safe use of the device. The description is written in accordance with the valid directives. The information in these operating instructions refers to the product's current development status. -
Page 7: Pictographs
About this manual 1.3.2 Pictographs Pictographs used in the document indicate useful information. Note 1.3.3 Stickers on product This section describes all the stickers on the product along with their meanings. Rating plate (example) Tbl. 1: Stickers on product 1.3.4 Abbreviations Abbreviation Meaning in this document Direct current Delta P Delta pressure... -
Page 8: Safety
Safety 2 Safety 2.1 General safety information The following 4 risk levels and 1 information level are taken into account in this document. DANGER Immediately pending danger Indicates an immediately pending danger that will result in death or serious injury if not observed. ►... -
Page 9: Safety Precautions
Safety Risks during maintenance, decommissioning and disposal WARNING Health hazard through poisoning from toxic contaminated components or devices Toxic process media result in contamination of devices or parts of them. During maintenance work, there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub- stances causes environmental damage. -
Page 10: Proper Use
The work described in this document may only be carried out by persons who have appropriate profes- sional qualifications and the necessary experience or who have completed the necessary training as provided by Pfeiffer Vacuum. Training people 1. Train the technical personnel on the product. -
Page 11: Personnel Qualification For Maintenance And Repair
─ Customer with Pfeiffer Vacuum service training ─ Pfeiffer Vacuum service technician 2.7.3 Advanced training with Pfeiffer Vacuum For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of courses and technical trainings. For more information, please contact Pfeiffer Vacuum technical training. -
Page 12: Product Description
3.3.1 Product types The product designation of Pfeiffer Vacuum electric angle valves from the Series E is composed of the family name, the size and, if required, an additional feature description. -
Page 13: Product Features
Product description Family Size/model Series E DN 16 to 50 Electric valve with position indicator Tbl. 4: Product designation of electric angle valve with position indication 3.3.2 Product features Feature Description Valve body material Aluminum 6061-T6 or stainless steel Bellows/valve plate Stainless steel 316L Seals FKM elastomer... -
Page 14: Transportation And Storage
► Do not stack the products. ► Wear protective equipment, e.g. safety shoes. We recommend Pfeiffer Vacuum recommends keeping the transport packaging and original protective cov- Instructions for safe transport ► Transport the valve only within the permissible temperature limits. -
Page 15: Installation
Installation 5 Installation 5.1 Preparatory work WARNING Risk of injury due to incorrect installation Dangerous situations may arise from unsafe or incorrect handling ► Do not put hands or any other body part or objects in the valve. General notes for the installation of vacuum components ►... -
Page 16: Power Supply Connection
Installation Fig. 2: Vacuum connection 1 Seal with centering ring KF connection flange 2 Clamp Protective lid Mounting the valve 1. Remove protective lid from the valve. 2. Connect the valve to the vacuum system using the clamp. 5.3 Power supply connection WARNING Risk of electric shock due to non-compliant electrical installations The product is permanently connected to the mains voltage. -
Page 17: Tbl. 7: Connector Pin Definition
Installation Fig. 3: Connector pin usage Label Description Power 24 V DC power input Control Valve control input (5 – 24 V DC) Not used Valve Open signal (max. 48 V AC/DC, 500 mA) Common Common for pins 4 and 6 Valve Closed signal (max. -
Page 18: Operation
Operation 6 Operation Information on operation ● For continued trouble-free operation, keep the valve clean and free of contaminants. ● Use lint-free gloves to avoid contaminating the valve with finger oils. ● Work in a clean environment to avoid other contamination. ●... -
Page 19: Maintenance
Maintenance 7 Maintenance The valve does not require any maintenance on the customer’s premises other than the day-to-day servicing described in this manual. Any other maintenance operation must be carried out by Pfeiffer Vacuum service center. 19/28... -
Page 20: Decommissioning
Decommissioning 8 Decommissioning Required tools and materials ● Lint-free gloves ● Protective covers for the valve flanges Prerequisites ● Vacuum system vented to atmosphere ● Control system turned off ● Valve closed Dismounting the valve 1. Loosen the power supply connector and unplug it. 2. -
Page 21: Recycling And Disposal
● Help to reduce the wastage of natural resources. ● Prevent contamination. 9.1 General disposal information Pfeiffer Vacuum products contain materials that you must recycle. ► Dispose of our products according to the following: – Iron – Aluminium –... -
Page 22: Malfunctions
Malfunctions 10 Malfunctions Please contact your Pfeiffer Vacuum Service team for support, if you experience valve malfunctions that are not listed below. Problem Remedy Blue power light is blinking ● Check if power supply is within operational limits. Error state: power cycle ●... -
Page 23: Service Solutions By Pfeiffer Vacuum
We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality. - Page 24 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 25: Accessories
Accessories 12 Accessories 12.1 Ordering accessories Accessories Accessories number Straight connector 2000209790 Right angle connector 2000209791 Tbl. 10: Accessories for Series E 25/28... -
Page 26: Technical Data And Dimensions
Technical data and dimensions 13 Technical data and dimensions 13.1 General mbar Torr | mm Hg mbar 1 · 10 0.75 1000 1000 1 · 10 0.01 0.01 1 · 10 1 · 10 7.5 · 10 0.75 1 · 10 0.01 1000 Torr | mm Hg 1.33... -
Page 27: Dimensions
Technical data and dimensions 13.3 Dimensions Fig. 4: Dimensions of Series E electric angle valves Connection flange DN 16 ISO-KF DN 25 ISO-KF DN 40 ISO-KF DN 50 ISO-KF 175 mm 180 mm 221 mm 230 mm 128 mm 134 mm 169 mm 178 mm 73 mm... - Page 28 Are you looking for a Pfeiffer Vacuum GmbH perfect vacuum solution? Berliner Strasse 43 Please contact us 35614 Asslar Germany T +49 6441 802-0 info@pfeiffer-vacuum.de...
