- Page 1 ONLINE UPS SYSTEM DN-170093 Rev. 4・DN-170094 Rev. 4 DN-170095 Rev. 4・DN-170096 Rev. 4 Quick Installation Guide...
-
Page 2: Important Safety Warning
1. Important safety warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. -
Page 3: Installation And Setup
1.4 Symbols used in this guide CAUTION! Read this information to avoid equipment damage 2. Installation and setup Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2.1 Unpack checking Don’t lean the UPS when moving it out from the packaging Check the appearance to see if the UPS is damaged or not during the... - Page 4 1.5 kVA: 2 kVA: 3 kVA: (1) Output receptacles (10 A) (6) AC input receptacle (2) Battery terminal (7) Input circuit breaker (3) SNMP intelligent slot (8) EPO (with Jumper cap) (4) RJ45 Surge Protection (9) USB (5) RS-232 communication port (10) Output receptacle (16 A)
- Page 5 2.3 Installing the UPS Rackmount installation The Rackmount cabinet comes with all of the hardware required for installation in a standard EIA or JIS seismic Rackmount configuration with square and round mounting holes. CAUTION The cabinet is heavy. Removing the cabinet from its carton requires a minimum of two people.
- Page 6 Figure 1: Extract the UPS front cover CAUTION A small amount of arcing may occur when connecting the internal batteries. This is normal and will not harm personnel. Connect the cables quickly and firmly. b) Connect the internal battery connector (see Figure 2). Connect red to red, Press the connector tightly together to ensure a proper connection.
-
Page 7: Communication Port
Figure 3 2.4 Setup the UPS Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. For 208/220/230/240VAC models: The power cord is supplied in the UPS package Step 2: UPS output connection ... - Page 8 The UPS is equipped with intelligent slot perfect for either SNMP or Relay card. When installing either SNMP or Relay card in the UPS, it will provide advanced communication and monitoring options. Note: USB port and RS-232 port can't work at the same time. Note: Using the provide USB cable is required.
- Page 9 2.5 Operation and display panel ① ② ③ ① LED (from right to left: “alarm”, “bypass”, “battery”, “inverter”) ② On-Line UPS LCD display ③ Function keys...
- Page 10 LED indicator Indicator Description ON: The UPS has an active alarm or fault The UPS is in Bypass mode. ON: The UPS is operating normally on Yellow bypass during High Efficiency operation. ON: The UPS is in Battery mode. Yellow ON: The UPS is operating normally.
- Page 11 Up key: Press this button to display previous selection in UPS setting mode. Down key: Press this button to display next selection in UPS setting mode. To confirm selectionand exit setting DOWN mode: Press this button to confirm selection and exit setting mode when LCD display the last selection in UPS setting mode.
- Page 12 (2) Turn off the UPS by DC without mains power a) Press and hold the OFF key for more than half a second to turn off the UPS. b) When turning off the UPS, it will do self-testing firstly. The LEDs light and go out circularly and orderly until there is no display on the cover.
