- Page 1 ONLINE UPS SYSTEM 6 kVA / 10 kVA DN-170106 ・DN-170107 Rev. 2 Rev. 2 Quick Installation Guide...
- Page 2 Safety Important safety instructions – Save these instructions There exists dangerous voltage and high temperature inside the UPS. During the installation, operation and maintenance, please abide the local safety instructions and relative laws, otherwise it will result in personnel injury or equipment damage. Safety instructions in this manual act as a supplementary for the local safety instructions.
-
Page 3: Product Introduction
1.2 Symbols used in this guide WARNING! Risk of electric shock CAUTION! Read this information to avoid equipment damage 2．Product Introduction This series UPS is a kind of single phase in single phase out high frequency online UPS, it provides two capacities: The 6kVA and 10kVA. The products are modularized and adopt the N+X redundancy. - Page 4 3.2 UPS Module Outlook Rear View (1) EPO (6) Battery Slot (2) Parallel Port 1 (7) PDU (3) USB (8) COM (RS232) (4) Input breaker (9) Parallel Port 2 (5) Intelligent slot (10) Terminal 3.3 LCD control panel (1) INVERTER LED (2) BATTERY LED (3) BYPASS LED (4) ALARM LED...
-
Page 5: Installation Notes
3.4 Installation notes Please place the UPS in a clean, stable environment, avoid the vibration, dust, humidity, flammable gas and liquid, corrosive objects. To avoid from high room temperature, a system of room extractor fans is recommended to be installed. Optional air filters are available if the UPS operates in a dusty environment. - Page 6 3.5 External Protective Devices For safety reasons, it is necessary to install, external circuit breaker at the input A.C. supply and the battery. This chapter provides guidelines for qualified installers that must have the knowledge of local wiring practices for the equipment to be installed. External Battery The UPS and its associated batteries are protected against the effect of over-current through a DC compatible thermo-magnetic circuit-breaker (or a set of fuses) located...
- Page 7 CAUTION! Protective earth cable: Connect each cabinet to the main ground system. For Grounding connection, follow the shortest route possible. WARNING! Failure to follow adequate earthing procedures may result in electromagnetic interference or in hazards involving electric shock and fire. 3.7 Power cable connect Once the equipment has been finally positioned and secured, connect the power cables as described in the following procedure.
-
Page 8: Battery Connection
3.8 Battery connection The installation between UPS and EBPS shown as following Note: The BAT+ of the UPS connect poles is connected to the anode of the positive battery, the BAT- is connected to the cathode of the positive battery and the anode of the negative battery, the BAT- is connected to the cathode of the negative battery. -
Page 9: Communication Connection
CAUTION! Ensure correct polarity battery string series connection. i.e. inter-tier and inter block connections are from (+) to (-)terminals. Don’t mix batteries with different capacity or different brands, or even mix up new and old batteries, either. WARNING! Ensure correct polarity of string end connections to the Battery Circuit Breaker and from the Battery Circuit Breaker to the UPS terminals i.e. -
Page 10: Operation
4．Operation 4.1 Turn on/off UPS 4.1.1 Connecting with Utility CAUTION! Make sure grounding is properly done! Set the Battery Breaker to the “ON” position according to the user’s • manual. Switch on the UPS • WARNING! Check to see if the load is safely connected with the output of the UPS. If the load is not ready to receive power from the UPS, make sure that it is safely isolated from the UPS output terminals The internal fan of the UPS starts spinning, the UPS is performing self-... - Page 11 4.1.2 Black (Cold) start procedure CAUTION! Follow these procedures when the input AC Utility Failure, but battery is normal Turn on the battery switch. The battery will feed the Auxiliary power board. Press and hold the ON key for more than two seconds to start the UPS. When battery normal, rectifier starts operation, 30s later, inverter starts and operates, INV and output light up.
- Page 12 WARNING! Wait for about 5 minutes for the internal D.C. bus bar capacitors to be completely discharged. 4.3 LCD Display instruction NOTICE! The display provides more functions than those described in this manual. There are 10 interfaces available in the LCD display: Interface ITEM Content Displayed...
- Page 13 (2) Input voltage (3) Output voltage (4) Bat + voltage (Positive) (5) Bat – voltage (Negative) (6) Load (7) PFC/Ambient temperature up, only shows the high temperature Internal temperature (down) (8) Bus voltage (9) Software version More detailed information on operation and device settings can be found in the corresponding user manual.
- Page 14 This is a Class A product. In home environment, this product may cause radio interference. In this case, the user may be required to take appropriate measures. Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the shipping content.
