  • Page 2 ONLINE UPS SYSTEM DN-170093・DN-170094・DN-170095・DN-170096 Manual All rights reserved. The information in this document is subject to change without notice. Publish statement Thank you for purchasing this series UPS. This series UPS is an intelligent, single phase in single phase out, high frequency online UPS designed by our R&D team who is with years of designing experiences on...

  • Page 3: Table Of Contents

    Table of Contents 1. Important Safety Warning..................3 1.1 Transportation ....................3 1.2 Preparation......................3 1.3 Installation ......................3 1.4 Operation ......................4 1.5 Maintenance, service and faults ................ 4 1.6 Symbols used in this guide ................. 5 2. Installation and setup ....................5 2.1 Unpack checking ....................

  • Page 4: Important Safety Warning

    1. Important safety warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.

  • Page 5: Operation

    1.4 Operation • Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads. • The UPS system features its own, internal current source (batteries). The UPS output sockets or output terminals block may be electrically live even if the UPS system is not connected to the building wiring outlet.

  • Page 7: Symbols Used In This Guide

    1.6 Symbols used in this guide WARNING! Risk of electric shock CAUTION! Read this information to avoid equipment damage 2. Installation and setup Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2.1 Unpack checking Don’t lean the UPS when moving it out from the packaging Check the appearance to see if the UPS is damaged or not during the...
  • Page 8 1.5 kVA: 2 kVA: 3 kVA: (1) Output receptacles (10 A) (6) AC input receptacle (2) Battery terminal (7) Input circuit breaker (3) SNMP intelligent slot (8) EPO (4) RJ45 data line Surge Protection (9) USB (5) RS-232 communication port (10) Output receptacle (16 A)

  • Page 9: Installing The Ups

    2.3 Installing the UPS • Rackmount installation The UPS is supplied with 19-inch mounting brackets for installation in the server rack. Mounting rails must be ordered separately (part number DN-170109). The rails are adaptable for installation in 19" server racks with approx. 70~76 cm (27 to 30 inch) depth.
  • Page 10 Figure 2: Fixing the rails e) Repeat Steps 3 and 4 for the other rail assembly. f) Tighten the four butterfly nuts in the middle of each rail assembly. g) If installing optional cabinets, repeat Step 1 through Step 6 for each rail kit. h) Place the UPS on a flat, stable surface with the front of the cabinet facing to you.
  • Page 11 m) Continue to the following section, “Rackmount Wiring Installation. (2) Rackmount wiring installation a) Installing the UPS, including connecting the UPS internal batteries b) Connecting any Optional EBP(S) • How to install the UPS Note: Do not make unauthorized changes to the ups; otherwise, damage may occur to your equipment and void your warranty.
  • Page 13 Figure 6: Connecting the UPS internal batteries d) Replace the UPS front cover To replace the cover, verify that the ribbon cable is protected and (if EBPS are installed) the EBP cable is routed through the knock out on the bottom of the cover.
  • Page 14 • Connecting the EBP(s) (1) To install the optional EBP(s) for a UPS a) Remove the front cover of each EBP and UPS (see Figure 8). It is the same with the installation of the front cover. (Refer” To install the UPS“) Figure 8: Removing the EBP Front Cover b) On the bottom of the UPS front cover, remove the EBP cableknockout (see...
  • Page 15 e) Plug the EBP cable(s) into the battery connector(s) as shown inFigure 10. Up to four EBPS may be connected to the UPS. Connect black to black,. Press the connector tightly together to ensure a proper connection. To connect a second EBP, unclip the EBP connector onthe first EBP and pull gently to extend the wiring to the EBP connector on the second EBP.
  • Page 16 ③ If an EBP is needed to be placed in the middle, the assembly of plastic base is similar (Figure 11). The difference is that two 1U plastic base extended boards are added in the middle. (as the following shows) Figure 12: Increase EBP plasticbase installation...
  • Page 17 (2) Rackmount converted to Tower LCD Display plasticbase installation • The installation between UPS and EBPS can be referred to Figure 14 Figure 14: The installation for UPS and battery boxes...

  • Page 19: Ups Startup And Turn Off

    Figure 15: Long backup external battery connection a) Install the base, then place the RT UPS on the base one by one as Figure 13 shows. b) The cover installation and cable connection of the UPS and EBPS are the same as RT.

  • Page 20: Configuring Battery Settings

    • Turn off operation (1) Turn off the UPS in line mode a) Press and hold the OFF key for more than half a second to turn off the UPS and inverter. b) After the UPS shutdown, the LEDs go out and there is no output. If output is needed, you can set bps “ON”...
  • Page 21 ① ② ③ ① LED (from right to left: “alarm”, “bypass”, “battery”, “inverter”) ② On-Line UPS LCD display ③ Function keys LED indicator Indicator Description ON: The UPS has an active alarm or fault The UPS is in Bypass mode. ON: The UPS is operating normally on Yellow bypass during High Efficiency operation.
  • Page 22 Function Keys Function key Description ESC/OFF To exit setting mode or turn off the UPS To go to previous selection or turn on the UPS DOWN To go to next selection To confirm the selection in setting mode or enter ENTER/ON setting mode LCD Display Icons...
  • Page 23 Icon Function/Description Input source information Indicates the AC input Indicates input voltage, input frequency, PV voltage, battery voltage and temperature Configuration program and fault information Indicates the settings programs Indicates the warning and fault codes Warning: flashing with warning code Fault: flashing with fault code Output information...

  • Page 25: Operations

    Indicates the load level by 0 – 24%, 25 – 49%, 50 – 74%, 75 – 100% 0 – 24 % 25 – 49 % 50 – 74 % 75 – 100 % Mode operation information Indicates unit connects to the mains Indicates load is supplied by utility power Indicates the utility charger circuit is working Indicates the DC/AC inverter circuit is working...

  • Page 26: Setup The Ups

    to exit setting mode when in UPS setting mode,but save nothing. • Up key: Press this button to display previous selection in UPS setting mode. • Down key: Press this button to display next selection in UPS setting mode. • To confirm selectionand exit setting DOWN mode:Press this button to confirm selection and exit setting mode...

  • Page 27: Lcd Display

    schedule UPS shutdown/start-up and monitor UPS status through PC. The UPS is equipped with intelligent slot perfect for either SNMP or Relay card. When installing either SNMP or Relay card in the UPS, it will provide advanced communication and monitoring options. Note: USB port and RS-232 port can't work at the same time.
  • Page 28 Input frequency & output frequency Battery voltage & backuo time & battery capacity Load Environment Temperature UPS model Firmware version...

  • Page 29: Ups Setting

    Alarm code (warning message) All alarm codes are present when abnormal behavior(s) occur(s) 3.4 UPS setting The UPS has setting functions. This user settings can be done under any kind of UPS working mode. The setting will take effect under certain condition. Below table describes how to set the UPS.
  • Page 31 Frequency setting • Press Enter button to change the setting (50 or 60Hz). • Press UP button ▲ to select the previous setting. • Press DOWN button ▼ to select the next setting. Battery capacity setting • Press Enter button to change the setting (Battery capacity range is 1-200Ah).
  • Page 32 Bypass voltage upper limit setting • Press Enter button to change the setting (The bypass voltage upper limit range is 230 – 264Vac). • Press UP button ▲ to select the previous setting. • Press DOWN button ▼ to select the next setting.

  • Page 33: Operational Status And Mode(S)

    3.5 Operational status and mode(s) Item Content Displayed Standby Mode No Output Bypass Mode Utility Mode Battery Mode Battery Self-diagnostics Inverter is starting up ECO Mode EPO Mode Maintenance Bypass Mode Fault Mode Generator Mode 3.6 Alarm or fault reference code Event log UPS Alarm Warning Buzzer...

  • Page 34: Troubleshooting

    Output Short Circuit Beep Continously Fault LED lit Output Over Voltage Beep Continously Fault LED lit Output Svr Over Voltage Beep Continously Fault LED lit Output Low Voltage Beep Continously Fault LED lit +Battery Over Voltage Once per second BATTERY LED blinking +Battery Disconnected Once per 2 Seconds BATTERY LED blinking...
  • Page 35 Alarm code is shown as “45” Low battery voltage or Contact your dealer. and battery led blinking. charger failure Alarm code is shown as “26” Remove excess loads from UPS and INV and BYPASS led UPS is overload output. blinking. Check output wiring and if Alarm code is shown as “32”...
  • Page 37 Check the wire RefeR to Wiring connect refer to Diagram wiring Diagram Check the UPS mode(Input voltage Bat voltage) UPS turn on Check sps +12V & Replace power board Battery mode Bat voltage Replace control panel Fan Run normal& Fan issue Replace fan LCD light? Replace control...

  • Page 38: Storage And Maintenance

    5. Storage and Maintenance • Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or sh to your dealer in the replacement battery packing material •...
  • Page 39 effective monitoring of the real-time status of UPS and timely feedback the status to monitor when abnormal situation occurs (such as UPS failure, mains interruption, UPS bypass and ect.). It is installed in the intelligent slot ofthe UPS. The relaycard includes 6 output ports and one input port.Please refer to the following table for detail.
  • Page 40 Note: Depending on user configuration, the pins must be shorted or opened to keep the UPS running. To restart the UPS, reconnect (re-open) the EPO connector pins and turn on the UPS manually. Maximum resistance in the shorted loop is 10 ohm. Always test the EPO function before applying your critical load to avoid accidental load loss.

  • Page 41: Specification

    7. Specification MODEL 1KVA(S) 1.5KVA(S) 2KVA(S) 3KVA(S) PHASE Single phase with ground 1000 VA / 1500 VA / 2000 VA / 3000 VA / Capacity (VA/Watts) 1000 W 1500 W 2000 W 3000W INPUT Nominal voltage 208/220/230/240VAC 176 Vac ± 5 % @ 100 % - 50 % load; Low line 110 Vac ±...
  • Page 43 Waveform Pure Sinewave AC mode Zero <->Batt. mode Transfer time Inverter <-> 4 ms (Typical) bypass 89 % 89 % 93 % 93 % (AC mode) (AC mode) (AC mode) (AC mode) Efficiency 85 % 85 % 86 % 87 % (DC mode) (DC mode) (DC mode)
  • Page 44 Altitude < 1500m Noise level Less than 55dBA at 1 Meter PHYSICAL 440*325* 440*460* 440*460* 440*600* Dimension W×D×H (mm) 86.5 86.5 86.5 86.5 Net Weight (kg) 11.3 15.5 19.5 STANDARDS Safety IEC/EN62040-1,IEC/EN60950-1 IEC/EN62040-2, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8 * Derate to 80% of capacity when the output voltage is adjusted to 208VAC ** Derate to 75% of capacity when the Input voltage frequency out of range (50/60 ±...
