Summary of Contents for WhisperKool Omega Mini

Page 1 Omega Condenser OWNER’S MANUAL Omega Mini Omega 4000 Omega 8000...
Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Before You Start .
Page 4: Introduction
Thank you for purchasing a WhisperKOOL cooling system . We strive to provide the highest-quality products and the best possible customer service . If you have any questions about your system, please call us at support@WhisperKOOL .com or visit whisperkool .com/ticket .
Page 5: Before You Start
1-800-343-9463 BEFORE YOU START This guide is meant to serve as a quick reference for installation of the WhisperKOOL unit . The remainder of this owner’s manual will provide more detailed information and instructions . Upon receiving the WhisperKOOL condensing unit: 1 .
Page 6: Receiving & Inspecting The System
Allow the condensing unit to sit for 24 hours prior to startup . The condensing unit can be placed in the installation location, piped and evacuated during this time . Note: WhisperKOOL units are manufactured in the USA and tested prior to shipment . •...
Page 7: Quick Reference Guide
Omega Condenser QUICK REFERENCE GUIDE King Valve View Side View www .whisperkool .com | Page 5...
Page 8 OMEGA CONDENSER SPECIFICATIONS Contact our sales team if your cellar incorporates stone, concrete, or glass in its construction. 110624 Omega Page 6 | 1-800-343-9463...
Page 9 Turn the handle of the flaring tool clockwise until the pipe is fully flared . Remove the flaring tool and flare form, then inspect the ends for any cracks and make sure the flaring is even . www .whisperkool .com | Page 7...
Page 10: Torque Requirements
CONNECTING THE LINESET, CONTINUED PIPING EXTENSION BEYOND FLARE FORM A (in.) Outer Diameter of Pipe (in.) Min. Max. 1/4” 0 .0275” 0 .05” 3/8” 0 .04” 0 .063” 1/2” 0 .04” 0 .07” 5/8” 0 .078” 0 .086” 3/4” 0 .078” 0 .094”...
Page 11: Preparing The Condensing Unit
Provide a weatherproof disconnect for the condensing unit if it is located outside . Power surges and spikes can damage sensitive electrical equipment . WhisperKOOL recommends plugging the unit into a surge protector or power conditioner in order to protect your system . As outlined in our terms and conditions, power surges and spikes are not covered under warranty .
Page 12: Installing The Condensing Unit
INSTALLING THE CONDENSING UNIT The condensing unit can be installed inside a well-ventilated area of the home, but is typically installed outside . Exterior applications will require the use of a protective housing . The amount of sun exposure should be considered when selecting the placement of the condensing unit .The Mini and 4000 condensing unit requires a dedicated 15-amp circuit (non-GFI), and 8000 Omega condensing unit requires a dedicated 20-amp circuit (non-GFI) .
Page 13 Omega Condenser INSTALLING THE CONDENSING UNIT www .whisperkool .com | Page 11...
Page 14 INSTALLING THE CONDENSING UNIT Refrigerant Piping Overview • Using the charts and illustrations found above, route the line set between the evaporator unit and condensing unit . Be sure to reference the chart for correct line set sizing . All horizontal suction piping should be pitched toward the condensing unit half an inch for every 10 feet of pipe .
Page 15 A . Energize the solenoid valve on the evaporator unit by plugging the unit in and adjusting the thermostat to call for cooling . WARNING! Allowing your unit to operate in high ambient temperatures for extended periods of time will greatly decrease the life of your unit and void your warranty. www .whisperkool .com | Page 13...
Page 16 Charge Chart & TXV Adjustment Ranges 110624 Omega Page 14 | 1-800-343-9463...
Page 17 Omega Condenser OMEGA CONDENSER DIAGRAM blue black black black black blue white white black black blue white green Condenser green EC Fan green green yellow blue green www .whisperkool .com | Page 15...
Page 18: Component Identification
Component Identification 110624 Omega Page 16 | 1-800-343-9463...
Page 19 Omega Condenser Component Identification www .whisperkool .com | Page 17...
Page 20: Troubleshooting Guide
WHISPERKOOL TROUBLESHOOTING GUIDE Ice forming on evaporator units Possible cause Solution Evaporator filter or coil is dirty Remove the filter and wash it, then clean the coil with a vacuum . If coil is very dirty, use a spray bottle with a small amount of liquid dish detergent or coil cleaner .
Page 21 Compressor and /or starting components faulty Please contact the installing technician to troubleshoot Humidity in cellar too low Possible cause Solution Not enough moisture Purchase and place a humidifier (or a decorative fountain) in cellar www .whisperkool .com | Page 19...
Page 22: Maintenance Schedule
MAINTENANCE SCHEDULE Monthly 1 . Check coils 2 . Check for unusual noise or vibration 3 . Check the drain line to see if it is above the waterline (if draining into a vessel) Quarterly 1 . Use a vacuum with brush attachment to clean coils; be careful not to crush coil fins when cleaning 2 .
Page 23: Technical Assistance
TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a .m . to 4:00 p .m . Pacific Standard Time . The appointed customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •...
Page 24: Warranty Information
WhisperKOOL warrants against defects in material and workmanship as follows: 1 . LABOR — For a period of two (2) years commencing on the date of purchase, WhisperKOOL will, at its option and discretion, reimburse up to $250 to the End User for cost incurred for servicing, repairing, removing or installing warranty parts .
Page 25: Maintenance Requirements
6 . Proof of purchase of the Product in the form of a bill of sale, receipted invoice or serial number, which is evidence that the Product is within the Limited Warranty Period, must be presented by the End User to WhisperKOOL in order to obtain limited warranty service .
Page 26 WhisperKOOL Customer Service to arrange for replacement under the warranty guidelines . When a claim for warranty is submitted for a condenser skid, the End User must purchase a new condenser skid from WhisperKOOL at retail price . Upon installation of the new condenser skid by a certified HVAC/R Technician, the HVAC/R Technician must complete the Installation Checklist and End User must submit the Installation Checklist to WhisperKOOL Customer Service for approval .
Page 27 County of San Joaquin, State of California, and all parties, WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose . No waiver by WhisperKOOL of any breach or default of the contract of sale (including these Terms and Conditions of Sale) concerning a Product will be deemed to be a waiver of any preceding or subsequent breach or default .
Page 28: Additional Considerations
• The customer will be provided a pre-paid return label or freight pickup for the return shipping of the item. If you fail to return the original WhisperKOOL unit or part to the factory within 30 days of issued RMA, or no •...
Page 29 Mail to: Fax to: Scan and email to: WhisperKOOL 209-466-4606 warranty@whisperkool .com ATTN: Warranty Registration 1738 E . Alpine Avenue Stockton, CA 95205-2505 www .whisperkool .com | Page 27...
Page 30 WhisperKOOL 1738 E . Alpine Ave Stockton, CA 95205 1-800-343-9463 www .whisperkool .com...
