Baxton Studio 310C Assembly Instruction

ASSEMBLY INSTRUCTION
Read this instruction carefully. Remove all wrapping material, staples and straps from the
carton. See hardware and furniture part list
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft surface,
such as a carpet or rug, to prevent from being scratched.Follow the figure to start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw untill all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
STEP 1
1
4
2
C
B
STEP 2
5
C
A
C
B
NO PART LIST
A BACK REST
B FRONT LEG
C SIDE RAIL
D CUSHION SEAT
STEP 3
A
C
4
1
5
C
3
QTY NO DESRIPTION
1 PC 1 JCBC SCREW M6 X 50MM
1 PC 2 WOOD DOWEL Ø8 x 30MM
2 PCS
CSK SCREW M4 x 30MM
3
1 PC
4 SPRNG WASHER M6
5 M4 ALLEN KEY
STEP 4
3
D
COMPELETE ASSEMBLE
MODEL : 310C
QTY
6 PCS
4 PCS
3 PCS
6 PCS
1 PC
