Introduction
The Model T34121 Benchtop Machine Cabinet
features solid oak and veneer construction, and 5"
locking swivel casters for easy movement. The cab-
inet measures 56" wide, 25
and includes five felt-lined drawers with ball bearing
slides, four storage shelves, and chrome hardware.
Figure 1. Model T34121 Benchtop Machine
Cabinet.
• To reduce risk of crushing injuries from
cabinet tipping over on you:
— Do not stand on cabinet or in drawers.
— Push cabinet only. Do not pull it.
— Only open one drawer at a time.
— Only move or transport cabinet with all
drawers closed.
• Do not exceed weight capacity:
— Max roller cabinet weight limit (includ-
ing contents) is 300 lbs.
• To prevent accidental rolling, always lock
brakes after moving cabinet.
• Do not allow children to have unsupervised
access to cabinet.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
" deep, and 32" tall,
1
4
COPYRIGHT © MARCH, 2024 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 03/24) #JA23107 PRINTED IN CHINA
***Keep for Future Reference***
MODEL T34121
BENCHTOP MACHINE
CABINET
INSTRUCTIONS
Inventory
Description (Figure 2)
A. Cabinet ....................................................... 1
B. Locking Swivel Casters 5" .......................... 4
C. Flat Head Screws #8-32 x
D. Flat Head Cap Screws
E. Flat Washers
" ....................................... 16
1
4
Folding Extension Tables ........................... 2
F.
C
Figure 2. Inventory.
" .................. 12
1
2
"-20 x
"........... 16
1
3
4
4
A
B
D
E
F
V1.03.24
Qty
