Ultra-tow XTP Series Owner's Manual

Auto locking a-frame trailer coupler 5000 lb. capacity
Hide thumbs Also See for XTP Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Auto Locking A-Frame Trailer Coupler
5000 Lb. Capacity
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #54547
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ultra-tow XTP Series

Summary of Contents for Ultra-tow XTP Series

  • Page 1 Auto Locking A-Frame Trailer Coupler 5000 Lb. Capacity Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #54547 SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing an Ultra-Tow™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Towing ..............................6 Installation Instruction .......................... 6 Before Each Use ............................ 7 Operating Instructions .......................... 7 After Each Use ............................9 Maintenance ............................

  • Page 4: Intended Use

    Intended Use This Ultra-Tow XTP Series Auto Locking A-Frame Trailer Coupler features an auto-locking system with a steel lock assembly. The secondary lock has a safety clip designed to fit an off-the-shelf padlock without an adaptor. This coupler can be used with any 2" ball having a capacity rating equal to or higher than the coupler.
  • Page 5 may put you dangerously close to other cutting tools and rotating parts.  Do not use the coupler where there is a risk of causing a fire or an explosion; e.g., in the presence of flammable liquids, gases, or dust. The product can create sparks, which may ignite the flammable liquids, gases, or dust.

  • Page 6: Specific Operation Warnings

    Specific Operation Warnings ⚠WARNING  Maintain an adequate vertical down (tongue) load to maintain control of the trailer (generally 10%), but without exceeding the specified rated capacities.  Other steps and inspections are also required Consult OSHA, D.O.T. regulations, and the American Trucking Association for complete coupling and uncoupling procedures.

  • Page 7: Before Each Use

    Weld the coupler to the front of the trailer tongue. Care must be taken to get a good penetration without undercutting the coupler or the tongue. (See the illustration below for weld locations.) Before Each Use ⚠WARNING  Inspect for proper operation. ...
  • Page 8 Auto Lock Function Secondary Lock Primary Lock Safety Clip Unlocked Position The illustration shown is in the unlocked position. When the Primary Lock does not show green, the coupler is open. Hitching Up 1. Before operating, inspect for proper operation and worn, damaged, or missing parts. 2.

  • Page 9: After Each Use

    Un-Hitching 1. Unlock by removing the Safety Clip. Top Hole Secondary Lock 2. Flip the Secondary Lock forward until it is pointing up, hold while raising the jack. 3. If both hands are needed, the Secondary Lock can be held by inserting the Safety Clip into the top hole while raising the jack.

  • Page 10: Troubleshooting

    Maintain the coupler hitch by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from oil and grease.

  • Page 11: Parts Diagram

    Parts Diagram Parts List Reference Part Number Item Description Quantity F20050 2" Ball, A-Frame Class 3 Coupler TGB3500J Trailer Guide Bracket PL3500J Primary Lock SL3500J Secondary Lock M10 – 1.5 Steel Locknut M10 -1.5 x 75mm Cap Screw M12 – 1.75 Steel Locknut M12 -1.75 x 75mm Cap Screw HM22 3/8"...

  • Page 12: Replacement Parts

    Reference Part Number Item Description Quantity SP3500-1 Short Spacer WA60 3/8" Standard Flat Washer MI-29 1/8" x 1.0" Large Cotter Pin HM121 3/8" Safety Clip with Chain/Cable Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. ...

  • Page 13: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your'') that the Ultra-Tow product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of three years from date of purchase.
  • Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 14 of 14...
