- Page 1 7In., 2-Channel Backup Camera Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #60725 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ultra-Tow™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 6 Assembly Instructions .......................... 7 Operating Instructions .......................... 8 After Each Use ............................. 10 Maintenance ............................ -
Page 4: Intended Use
Intended Use The Ultra-Tow 7In., 2-Channel Backup Camera includes a crystal-clear 7'' LCD monitor. It’s the perfect addition for any driver who needs assistance backing up. It’s also an LCD monitor which is very light, as well as thin. It has two video inputs allowing for an additional camera to the system (additional camera not included). - Page 5 intended to do. There are certain applications for which this equipment was designed. DO NOT use this equipment for a purpose for which it was not intended. Industrial or commercial applications must follow OSHA requirements. ⚠WARNING WORK AREA SAFETY ...
-
Page 6: Specific Operation Warnings
Check for damaged parts before each use. Carefully check that the product will operate properly and perform its intended function. Replace damaged or worn parts immediately. Never operate the product with a damaged part. Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with the power switch is dangerous and must be repaired by an authorized service representative before using. -
Page 7: Assembly Instructions
Assembly Instructions ⚠WARNING The monitor contains high voltage. It should only be opened by a qualified technician. 1. Connect the monitor wires: a. Connect the wire with the yellow connector to the 20m 4P cable, which will connect to the camera. If you use 2 cameras, the white wire connector will be used to connect the cable to the second camera. -
Page 8: Operating Instructions
Operating Instructions ⚠WARNING Do not rely solely on the camera for obstructions while in reverse. Check your surroundings for safety before driving in reverse. The device may be powered by a 12 ~ 24 volt automotive battery or a vehicle electrical system. ... - Page 9 Pull out Push (1) Video select (2) Decrease button (3) Mode select (4) Power ON/OFF (5) Increase button (6) Menu Page 9 of 12...
-
Page 10: After Each Use
After Each Use ⚠WARNING To avoid property damage, do not expose the monitor to excessive heat or cold. The storage temperature of the camera is -30 to +70°C and the operating temperature is -20 to +50°C. The humidity is Rh90%. Maintenance ⚠WARNING ... -
Page 11: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Ultra-Tow product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of three years from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions. - Page 12 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 12 of 12...
