ING. O. FIORENTINI S.p.A.
INDUSTRIAL CLEANING MACHINES
AUTOSCRUBBER MACHINE
MOD. Giampy
OPERATING INSTRUCTIONS
AND MAINTENANCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Giampy and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FIORENTINI Giampy

Summary of Contents for FIORENTINI Giampy

  • Page 1 ING. O. FIORENTINI S.p.A. INDUSTRIAL CLEANING MACHINES AUTOSCRUBBER MACHINE MOD. Giampy OPERATING INSTRUCTIONS AND MAINTENANCE...

  • Page 2: Table Of Contents

    Congratulations for your choice! FIORENTINI S.p.A. thanking you for the preference to our product, would like to remind you that FIORENTINI’s S.p.A. production covers manufacture and marketing of industrial cleaning machines and is currently a Leading industry in this sector .
  • Page 3 4.7.9. Squeegee blades replacement………………………………………………………. 4.7.10 Adjust brush pressure………………………………………………………………... 4.7.11 Electric cable/battery machine operating…………………………………………… MAINTENANCE 5.1. Maintenance tabel……………....…..…..…………........5.2. Battery maintenance………………………………………………………………………. 5.2.1. Hydrometry……………………………………………………………………………… 5.2.2. Water filling up………………………………………………………………………..5.2.3. Charging limits…………………………………………………………………………. 5.2.4. Off duty or inactive batteries…………………………………………..... 5.2.5. Batteries disposal……………………………………………………………………… 5.3. Maintenance of suction motor…………………………………………………………… 5.4.

  • Page 4: General Information

    We remind to put it in a safe place and keep it for all the machine lifetime. Purchaser is responsible to show it to qualified people. In case of loss ask for a duplicate to FIORENTINI Co..
  • Page 5  Natural calamities. WARRANTY TERMS The Ing.O.Fiorentini S.p.A. general terms conditions also apply to the warranty. The manufacturer cannot be held responsible in any way for damages resulting from unauthorised modifications made to the appliance, from the use of unsuitable brushes and accessories and after use of the device other than that intended.

  • Page 6: Conformity Declaration

    FIORENTINI. Repairing or substituting works under warranty will be, by FIORENTINI’s opinion, made in its own workshop, or by third party on place. Works on place, are supplied with customer’s energy sources and exceptional equipment to repairing if necessary.
  • Page 7 GENERAL INFORMATION GIAMPY 15/02/2012 Rev. 00 Pag. 7/41...

  • Page 8: Support Features And Specifications

    2.2. DESCRIPTION AND COMPONENTS The autoscrubber machine Giampy has been designed for treatment of flat areas through washing and following process of water drying. The power supply is furnished of a series of accumulator batteries, that charge all the engines and the electrical controls.
  • Page 9  driving unit; FIORENTINI Co., taking care of new safety rules in CE community , has manufactured the machine following safety and health rules of the CE normative. High quality material used, high technology and Fiorentini experience allowed to have performing machine .
  • Page 10 NOISE AT DRIVER’S EAR 72 dB The above characteristics are not a must for the manufacturer so they can be changed without any notice .In any case ING.O.FIORENTINI Co. Is always at disposal for any information ( 6.1.). MEASUREMENT UNIT CONVERSION 1 inch = 1”...
  • Page 11 NOISE AT DRIVER’S EAR 72 dB The above characteristics are not a must for the manufacturer so they can be changed without any notice .In any case ING.O.FIORENTINI Co. Is always at disposal for any information ( 6.1.). MEASUREMENT UNIT CONVERSION 1 inch = 1”...
  • Page 12 NOISE AT DRIVER’S EAR 72 dB The above characteristics are not a must for the manufacturer so they can be changed without any notice .In any case ING.O.FIORENTINI Co. Is always at disposal for any information ( 6.1.). MEASUREMENT UNIT CONVERSION 1 inch = 1”...
  • Page 13 NOISE AT DRIVER’S EAR 72 dB The above characteristics are not a must for the manufacturer so they can be changed without any notice .In any case ING.O.FIORENTINI Co. Is always at disposal for any information ( 6.1.). MEASUREMENT UNIT CONVERSION 1 inch = 1”...

  • Page 14: Security

    In order to use in a better way the machine characteristics we suggested to use the original parts and spare parts studied by Fiorentini Co.. In any case the Technical department is at customers disposal in order to satisfy any needs .

  • Page 15: Operators Status

    We recommend to teach the personnel to the use of the machine, above all for that it concerns safety aspects ; particularly operators must read and understand this manual. FIORENTINI decline every responsibility for accidents to persons or things from using the machine by non-authorized or unqualified operators.

  • Page 16: Safety Devices

    3.7. RESIDUAL DANGERS FIORENTINI has analyzed any kind of danger in using the machine to eliminate, or at less to reduce, accidents to operators, since the projecting phase. To reduce these risks we provided to inform the operators through signals and showing means and procedures to be adopted.

  • Page 17: Diagnostic Signaling Of Safety

    FIORENTINI decline every responsibility for accidents to persons or things using the machine on surfaces that can compromise the stability of the same one. The operator has to follow recommendations about areas conditions on which he has to work.
  • Page 18 SAFETY GIAMPY This signal shows explosion dangers due to the hydrogen released in What is it ? charging the accumulators. During the battery charging we recommend to place the machine in a What to do ? suction chimney or in an airy zone, far from heat sources and corrosive environments.

  • Page 19: Istructions For Starting And Use

    INSTRUCTIONS FOR STARTING AND USE GIAMPY INSTRUCTIONS FOR STARTING AND USE 4.1. TRANSPORT AND HANDLING This autoscrubber is delivered to the purchaser in a special package, which features are well showed in picture 4.1, completely assembled. The package shows the barycentre position indicated with a black arrow.

  • Page 20: Storage

    INSTRUCTIONS FOR STARTING AND USE GIAMPY Bands to be used must be suitable for the effective loading. Operations must be executed slowly avoiding oscillations or upsetting. The incorrect way of operatinG can damage the support or expose to dangers. Machine dimensions and mass are explained at point 2.3. We strongly recommend authorized personnel for lifting operations.

  • Page 21: Installation

    INSTRUCTIONS FOR STARTING AND USE GIAMPY 4.5. INSTALLATION The installation must be done by authorized personnel after reading this manual. 4.5.1 BATTERIES INSTALLATION To install the batteries follow the instructions as below :  Raise up the battery-cover chain guard (picture 4.4);...
  • Page 22 INSTRUCTIONS FOR STARTING AND USE GIAMPY To install the battery charger: In the rear part of the machine, there is a room for the battery charger. To reach it, you have to remove the screws which are fixing the cover to the electric system and take it away.

  • Page 23: Control Devices

    CONTROL DEVICES GIAMPY 4.6. CONTROL DEVICES 4.6.1. CONTROL BRIDGE (ELECTRIC VERSION) The control bridge is set up with some interrupters that start/stop every function of the machine. Every interrupters has a pictogram showing, without errors, related functions. In picture 4.6 is showed the control bridge, while the schedule shows every switch functioning.

  • Page 24: Control Bridge Battery Version

    CONTROL DEVICES GIAMPY 4.6.2. CONTROL BRIDGE (BATTERY VERSION) The control bridge is set up with some interrupters that start/stop every function of the machine. Every interrupters has a pictogram showing, without errors, related functions. In picture 4.6.1 is showed the control bridge, while the schedule shows every switch functioning.

  • Page 25: Functionning

    MAINTENANCE GIAMPY 4.7. FUNCTIONING The scrubbing operation is too delicate being necessary, by experience, to value correctly the kind of brush to be used, the necessity or not for a double scrubbing action, the better choice of the detergent. if floors are too dirty, we recommend a double scrubbing action.

  • Page 26: Choise Of Detergent

    50 cc inside the recovery tank before scrubbing. Be sure that detergent is suitable for the surface to clean up. Fiorentini S.r.l. is not responsible for damages caused by detergents too aggressive or anyway unsuitable for all kind of surfaces.

  • Page 27: Rudder Pedal Functions

    MAINTENANCE GIAMPY 4.7.4 RUDDER PEDALS FUNCTIONS This machine is equipped with different levers and pedals:  traction drive lever (part 1 Figure 4.9). The machine has a red switch for forward and reverse lid placed on top of the handle, before you pull the lever to pay attention to the positioning of the switch.

  • Page 28: Regulation Of Detergent Solution

    MAINTENANCE GIAMPY 4.7.5 REGULATION OF THE DETERGENT SOLUTION The quantity of detergent solution during the scrubbing operation can be easily regulated by a lever placed in the back-left side of the machine (picture 4.10 particular 1) PICTURE N° 4.10 N.B.: if it is necessary to set the regulation of water quantity make sure that the ignition key is disconnected to avoid casual starting.

  • Page 29: Water Discharge

    MAINTENANCE GIAMPY 4.7.7 WATER DISCHARGE This autoscrubber machine is equipped with two water discharge pipes (picture 4.15):  solution tank drain hose (particular 1 picture 4.13)  suction pipe (particular 2 picture 4.12). Moreover the machine is complete with a flexible pipe (detail 3 picture 4.13) which sucks the dirty water and a porthole cleaning inspection of the tank solution (detail 4.13).

  • Page 30: Brushes Replacement

    MAINTENANCE GIAMPY 4.7.8 BRUSH REPLACEMENT With one brush version To substitute the brushes do as it follows:  Remove the ignition key to avoid casual starting.  Empty both recoveries of the machine.  Lift up the machine.  Release the brushes pulling them to the bottom.
  • Page 31 MAINTENANCE GIAMPY Cylindrical brushes version The operator has to follow the instructions below to replace the brushes:  Take the ignition key away from the dashboard in order to avoid a casual starting of the machine;  Remove the protective cover (detail 1 in picture 4.17) plate by unscrewing the three screws detail 2 in picture 4.17).

  • Page 32: Squeegee Blades Replacement

    MAINTENANCE GIAMPY BRUSHES BELT REGULATION AND REPLACEMENT  Take the ignition key away from the dashboard in order to avoid a casual starting of the machine;  Uscrew the four screws and remove the plastic case (detail 1 in picture 4.20);...

  • Page 33: Adjust Brush Pressure

    MAINTENANCE GIAMPY 4.7.10 BRUSH PRESSURE REGULATION When the machine is scrubbing, it is possible to adjust the brush height from the ground, in order to vary its pressure on the floor. Rotating the knob anti-clockwise (particular 1 fig. 4.22) the pressure increases. Rotating it clockwise the pressure decreases.

  • Page 34: Maintenance

     Authorized personnel only can service this machine, particularly for electrical and electromechanical parts using suitable tools and equipment for every intervention  For assistance and spare parts address exclusively to Fiorentini S.r.l. OPERATIONS TO BE MADE INTERVENTION MODALITY...

  • Page 35: Hydrometry

    MAINTENANCE GIAMPY 5.2.1 HYDROMETRY Hydrometry can be made with batteries under charge with a densimeter. Do as it follows :  Put the gun densimeter and take a quantity of electrolyte sufficient to push up the floating;  Keep care the top of it doesn’t touch the rubber or the glass walls.

  • Page 36: Maintenance Of Suction Motor

    MAINTENANCE GIAMPY MAINTENANCE OF SUCTION MOTOR The suction motor must be efficient and cleaned. Every six months check the brushes and if necessary replace them . Maintenance of suction motor needs the following operations :  eeeping away the key from the dashboard release the motor hooks and disconnect the plug.

  • Page 37: Electrical Equipment Checking

    All intervention on the electrical system must be done by a technician. All maintenance or repair out of the ordinary maintenance must be done with personnel authorized only by FIORENTINI. TABLE ABOUT TESTS TO BE CARRIED OUT RECURRENCE...

  • Page 38: Maintenance Register

    GIAMPY MAINTENANCE 5.6. MAINTENANCE REGISTER DATE MAINTENANCE KIND OF INTERVENTION/MARKS SIGNATURE 22/05/08 Rev. 00 Pag. 38/41...

  • Page 39: Technical Assistence

    VERBAL CLAIM Fiorentini S.p.A, has a big consideration of customer needing, that’s why we think we can always get precious information to improve our products, placing at customer’s disposal a statement to point out possible defects using our autoscrubber Giampy.
  • Page 40  Electrical system failure  Engine failure  Missing component  Excessive noisness  Water leakage  Other Customer’s notes: Please point out notes and/or suggestions on products / services of Ing. O. Fiorentini S.p.A. 05/07/04 Rev. 00 Pag. 40/41...
  • Page 41 Nr. de serie Data di spedizione Date of shipment _____________________ Date de spedition Distributed by: ING. O. FIORENTINI S.p.A. “T ” HE BEST IN FLOOR MACHINES FILIALI: 20132 MILANO – Fax. 02/2592779 Via Palmanova 211/a – Tel. 02/27207783 - 2564810 00012 Guidonia Montecelio (ROMA) –...
