FIORENTINI I26PF Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNICAL DESCRIPTION
SPARE PARTS
INTRODUCTION
pag. 3
3
4
5
5
5
6
6
6
6
7
7
7
8
9
9
10
10
10
10
11
12
13
14
17
17
18
19
21
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I26PF and is the answer not in the manual?

Questions and answers

Related Manuals for FIORENTINI I26PF

Summary of Contents for FIORENTINI I26PF

  • Page 1: Table Of Contents

    INTRODUCTION RECEIPT OF THE MACHINE pag. 3 INTRODUCTION TECHNICAL DESCRIPTION INTRODUCTION GENERAL INFORMATION MANUFACTURER RESPONSABILITY INTERVENT REQUEST TRANSPORTATION UNPACKING THE MACHINE HANDLING OF PACKED MACHINE HANDLING OF UNPACKED MACHINE OPERATORING CONTROLS DASHBOARD CONTROLS ALARM REPORTING DASHBOARD SYMBOLS USE OF THE MACHINE SAFETY SYSTEM BRAKE INSTALLING THE BATTERY CHARGER...

  • Page 2: Receipt Of The Machine Pag

    In case of goods to be returned for warranty replacement, it is necessary to have a written acceptance from FIORENTINI technical department before sending them. All defective parts must be carefully packed in order to avoid further damages during transport.
  • Page 3 TECNICAL DESCRIPTION I-21PF I26PF DIMENSIONAL CHARACTERISTICS LENGHT 1280 mm 1280 mm WIDTH BRUSH COVER 650 mm 810 mm HEIGHT 1010 mm 1010 mm N° BRUSHES ∅280 mm ∅330 mm BRUSHES SIZE WORK WIDTH 525 mm 650 mm SQUEEGEE WIDTH 750 mm...

  • Page 4: General Information Introduction

    (or non-fulfilment) of the prescriptions contained in this manual .The same applies to change’s execution, modifications, and/or to the installation of accessory not preliminarily authorized. In particular the firm ING FIORENTINI SRL is not responsible for any damages caused by: • Natural calamity • Erroneous operations •...

  • Page 5: Transportation

    TRANSPORTATION HANDLING OF PACKED MACHINE The machine is supplied packed on pallet, closet in a box made of plywood or paper board. The weight and sizes are showed in the normal characteristics. The barycentre position is indicated by black arrow on the box. The forks of the lift truck or the transpallet should be placed so that the black arrow indicated on the packing is about in the centre of the forks.

  • Page 6: Operatoring Controls

    OPERATING CONTROLS DASHBOARD CONTROLS 1. Main Key Swich; 2. General Lamp; 3. Vacuum Motor Switch; 4. Brushes Motor Switch; ALARM REPORTING 1 FLASH Fail of microswitch correct start sequence. This generally happens if at start (key inserted) one of the direction microswitch is already closed. 2 FLASHES Battery is undervoltage or discharged.

  • Page 7: Dashboard Symbols

    DASHBOARD SYMBOLS Close(off) On(first function) Key Switch Scrubbing Brush Vacuum by Squeegee Squeegee Lowering Brush lifting Squeegee Lifting Brush lowering Reverse Increase by Traslation Forward General stop...

  • Page 8: Use Of The Machine

    USE OF THE MACHINE SAFETY SYSTEM The machine is equipped with double safety system for emergency stop: • Mushroom push button . In emergency case press down this button. • Socket (fig. 3), the same is also used to charge the battery. In emergency case, the socket must be pull out from the plug using its handle (fig 4).

  • Page 9: Brake

    REVERSE SPEED SAFETY To avoid operator crushing when machine run in reverse speed, there is a safety (fig.5), that is a great surface lever. When it touch the operator it disconnect immediately the reverse speed and insert forward speed. In this way we reduce at the minimum the shock or the operator crushing, caused by a wrong manoeuvre.

  • Page 10: Installing The Battery Charger

    INSTALLING THE BATTERY CHARGER • Install the battery charger in a ventilated and dry place, far from heat sources and corrosive environments. • Protect the mains with a delayed switch or with a load fuse higher than the max. power consumption of the battery charger.

  • Page 11: Squeegee Adjustment

    Fig.6 Fig.7 1. Emergency stop switch; 1. Squeegee lifting pedal; 2. Advancement speed adjustment 2. Brushes lifting pedal; throttle lever; 3. Handle position adjustment knob; SQUEEGEE ADJUSTMENT The squeegee must be perfectly adjusted to get a perfect floor drying ( fig. 8). The main caracteristic of this type of squeegee is to pick-up the water from the floor and convey to the vacuum hose, but it must be paralle to the floor.To rightly adjust the squeegee operate as follow: •...

  • Page 12: Brushes Replacement

    BRUSHES REPLACEMENT Before replacing the brushes, extract the key from the control dashboard, this avoiding that any accidental ignition of some motors could cause damages • First of all remove the knobs (fig.) by unscrewing them, then extract the brush covering carter •...

  • Page 13: General Safety Rules

    SAFETY, MAINTENANCE AND INSPECTION GENERAL SAFETY RULES Before using the machine ,instruct all operators to read carefully the charter ”SAFETY STANDARDS “WARNING. • The manufacturer can make any changes to the machine, for constructive or commercial reasons, without being obliged to change the instruction manual at the right time according to these modifications.
  • Page 14 can compromise the stability of the machine. Never pass through slopes in trasversal direction; when going through a downhill road, always adjust the speed to the environment conditions. Do not turn the machine at excessive speeds, particularly if the floor is not flat. CAUTION: DANGER Never operate the machine when stopped for special operations (setting up, maintenance, etc.).
  • Page 15 All six month, check the efficiency of the safety devices, the inspection should be performed by qualified personnel of FIORENTINI s.r.l. or authorized by it. To grant the efficiency of the safety devices, the machine should be overhauled by a technician of FIORENTINI every 5 months.

  • Page 16: Maintenance Operations

    During the cleaning and the maintenance of the machine remove the key. DAILY • Clean the recovery tank and the filter of the vacuum motors. WEEKLY • Check for the cleaning of the suction pipes and of the squeegee • Check the state of the rubber squeegee blades •...

  • Page 17: Squeegee Blades Replacement

    The squeegee blades should be replaced when the contact edge becomes worn; the perfection of the edge is essential for a perfect drying. To replace the blades • The squeegee should be demounted from the machine and placed on the desk. •...

  • Page 18: Vacuum Motor Maintenance

    Fig. 12 1. Accelerator Motor; 2. Vac Motor; CAUTION Each maintenance and repair operation not described under the “ordinary maintenance” should be performed by qualified personnel authorized by FIORENTINI s.r.l. only.

This manual is also suitable for:

I-21pf
