ARGON I500 Elegance,
ARGON I500 Panoramic,
INSTALLATION AND OPERATING INSTRUCTIONS
PLEASE RETAIN
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
To ensure safety, satisfaction and reliable service, this appliance must be installed by a suitably qual-
ified and component person.
Advertisement
Table of Contents
Related Manuals for Stanley ARGON I500 Elegance
Summary of Contents for Stanley ARGON I500 Elegance
- Page 1 ARGON I500 Elegance, ARGON I500 Panoramic, INSTALLATION AND OPERATING INSTRUCTIONS PLEASE RETAIN This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
-
Page 2: Table Of Contents
Stanley Stove Warranty ........ - Page 3 TABLE OF CONTENTS PAGE NO. 40. Wi-Fi Operation ..............26 41.
-
Page 4: Stanley Stove Warranty
CONDITIONS OF WARRANTY Your Stanley Stove is guaranteed against any part that fails (under normal operating conditions) as detailed in the fol- lowing table with timelines specified from the date of installation of the appliance. If the unit is not installed within six months of date of purchase, the warranty will commence six months from the date of purchase. -
Page 5: Important Operation/ Maintenance Notes
IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Stove is installed and no doubt you are looking forward to the many comforts it will pro- vide, we would like to give you some tips on how to get the best results from your unit. -
Page 6: Commissioning Checklist
COMMISSIONING CHECK LIST FLUE SYSTEM PASS FAIL 1. Flue Routing in compliance with Guidelines (see Flue Installation) 2. Waterford Stanley Flue Pipes & Fittings Used. 3. Flue Terminal positioned correctly & clear of obstructions. LOCATION PASS FAIL 1.Clearance to combustible materials must be adhered to (see Clearance to Combustible section). -
Page 7: Installation & Operating Instructions
RGI Registered Installer (ROI) or a Gas Safe Installer (NI or UK) or equivalent. Your Stanley Gas stove is supplied with the following items: It is important to note that once a type of gas has •... -
Page 8: Appliance Fireplace Installation
Appliance Fireplace Installation Installation steps. Determine the position required for the appli- ance. Select a suitable location, taking into Create a gas connection for the appliance in account , flueing, clearances to approximately the correct location for the gas combustibles and gas supply, size of the controls. -
Page 9: Clearance To Combustibles
Clearance to combustibles As this is a room sealed appliance and The appliance should be fitted with a minimum the appliance stands on appropriate legs, clearance of 150mm from any combustible a hearth is not required for this appliance. objects or materials; this includes any com- The Fireplace should be ventilated with bustible materials used for the fireplace con- convection ducts into the room from the... -
Page 10: Gas Pipes & Fittings
NOTE: Only flue approved by Waterford tap. Stanley for this appliance may be used. GAS CONNECTION When installing the flue system the following must The stove has a ø8mm gas inlet connection located... - Page 11 Flue Height Flue Restrictor Plate Fig.5 0 -2 metres None 2 - 4 metres 35mm Restrictor Plate 4 -6 metres 40mm Restrictor Plate 6 - 8 metres 30mm Restrictor Plate 8 - 15 metres None Note: House position & wind direction can cause variances in the above guide lines and if the glass starts to blacken, soot forms on the logs or the flame pattern is...
-
Page 12: Flue Options
Length of Vertical flue rise must be twice the 45200173 30-45 DEGREE TILE FLASHING KIT length of Horizontal flue run/offset. 17100160 Protection basket STANLEY FLUE FITTINGS 37130530 Ventilated fire stop The table across details the list of Waterford Stanley Approved Flue Fittings for this stove. -
Page 13: Fuel Bed Arrangement
FUEL BED ARRANGEMENT Fuel Bed Arrangements. NOTE: When arranging the Media into the When arranging the Media (Fuel Effect) into Firebed, it is important that the Pilot Area the Firebed, it is important that the Pilot area is & the second thermocouple is kept clear kept clear and that no Media enters the Pilot and that no Media enters the Pilot Shield shield. - Page 14 Scatter the Bags of Embers over the top of the burners as shown, keeping the pilot area clear. Position the 11 logs as shown. Lay the glow strands amongst the logs in the flames to create an enhanced Glow.
-
Page 15: Stove Dimensions
STOVE DIMENSIONS ARGON I500 Panoramic Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. - Page 16 ARGON I500 Elegegance...
-
Page 17: Technical Data
TECHNICAL DATA Nat. Gas G30/G31 Gas type Supply mbar 20/25 30/50 28-30/37 37/50 Pressure Nominal Heat Input Gross 11.6 11.6 11.6 10.3 (Hs) Nominal Heat 10.7 10.7 10.7 Input Nett (Hi) Consumption m³/hr 0.938 0.938/1.1 0.336 0.336 0.425 0.378 Burner mbar 11.9 11.9\17.1... -
Page 18: Countries Of Use
COUNTRIES OF USE Country Natural Gas L.P.G. AT - Austria I2H, G20 at 20 mbar NOT APPROVED BE - Belgium NOT APPROVED I3+,G31/G31 at 28/37 mbar; I3P(37),G31 at 37 mbar BG - Bulgaria I2H, G20 at 20 mbar NOT APPROVED CH - Switzerland I2H, G20 at 20 mbar I3+,G31/G31 at 28/37 mbar;... -
Page 19: Commissioning The Stove
COMMISSIONING THE STOVE The Appliance Commissioning Checklist (see Page Fig.24 6) must be filled out in conjunction with conducting the following checks: Pilot Ignition Check Ignite the pilot light as described in the Remote Control Operation Section. Check that the pilot light flame stays light. Extinguish the pilot light. -
Page 20: First Time Operation
FIRST TIME OPERATION Before lighting the stove check with the installer that the installation work and commissioning checks described previously have been carried out correctly. Ensure that all packaging, safety stickers & any protective wrapping have been removed and that the glass has been cleaned including all fingerprints on the glass. As part of the stove’s commissioning and handover the installer should demonstrate how to operate the stove correctly. -
Page 21: Manual Mode
MANUAL MODE Fig.27 To allow for remote control operation, make sure that the Manual Knob on the gas valve is in the ON (Full counterclockwise position) and the ON/OFF switch is in the I (ON) position - refer to Fig 26. Press &... -
Page 22: Setting Celsius Or Fahrenheit
Fig.32 Fig.31 Fig.33 SETTING CELSIUS OR FAHRENHEIT The remote control comes preset to show the tem- perature in Fahrenheit and it can be changed to Celsius by pressing & holding the Power Button & Timer Button simultaneously - see Fig 32. NOTE: Choosing Fahrenheit results in a 12 hour clock being displayed and... -
Page 23: Automatic Operation
AUTOMATIC OPERATION Fig.36 The stove has three automatic operation modes: Thermostatic Mode - The room temperature is compared to the set temperature and the flame height is automatically adjusted until the set temperature is reached. Program Mode - The stove operates for a set period of time (Two ON/OFF periods per day). -
Page 24: Eco Mode
The program mode can be set to operate as follows: Fig.40 ALL - The same programme every day SA:SU - The same programme for weekdays & a different setting for Saturday & Sunday 1,2,3,4,5,6,7. - Different setting for each day. Having confirmed the temperature setting, the Program Mode symbol &... -
Page 25: Additional Operational Features
ADDITIONAL OPERATIONAL FEATURES Fig.44 The remote control Stove has three standard addi- tional operational features: Child Lock Countdown Timer Rear Burner Operation Child Lock To activate the Child Lock and disable the remote control (with the exception of the OFF function), press the Power Button and Down Arrow Button simultaneously until the Child Lock Symbol is displayed - see Fig 44. -
Page 26: Wi-Fi Operation
WI-FI OPERATION Fig.47 The stove can be operated remotely using the myfire app by connecting the optional myfire Wi-Fi Box (Part Code: B6R-W) and connecting same to a Home Network (Wi-Fi Router). The myfire Wi-Fi Box will operate for a short period of time using batteries but if mains power is lost for a period of time, it is recommended to disconnect the Wi-Fi Box from the Gas Valve Control Box. -
Page 27: Battery Replacement
WARNING NOTE: Fig.48 Properly installed, operated and maintained this stove will not emit fumes into the dwelling. In the event of a gas escape or if you can smell gas then the following immediate action should be taken: (a) Immediately turn off the gas supply at the meter/emergency control valve. -
Page 28: Wiring Diagram
WIRING DIAGRAM Note: Mains Adapter must be used when Wi-fi Box connected. -
Page 29: Spare Parts
SPARE PARTS LIST Window Panel Main 2B01027 Window Panel Corner (& Bay) Side 2B01127 Ceramic Log Pack 2B01_LOGS Ember Pack 2B01_EMBR Pilot Assembly Natural G30-ZP2-312 Pilot Assembly LPG G30-ZP2-271 Electrode G30-SPK1 Electrode Lead G60-ZKIS1/1500 Thermocouple CG30182 Injector Natural EG05177 (x3) Injector LPG EG02177 (x3) Burner Top Assembly... -
Page 30: Service Records
SERVICE RECORDS 1ST SERVICE 2ND SERVICE Date of Service:............Date of Service:............Next Service Due:............. Next Service Due:............. Signed: ..............Signed: ..............RGI/Gas Safe Registration No/Stamp: RGI/Gas Safe Registration No/Stamp: 3RD SERVICE 4TH SERVICE Date of Service:............Date of Service:............Next Service Due:............. -
Page 31: Fault Finding- General
FAULT FINDING - GENERAL ISSUE POSSIBLE CAUSE SOLUTION Remote Control Batteries Low. Replace Batteries (See Battery Replacement Section) Gas Control Valve Batteries Low. Replace Batteries (See Battery Replacement Section) Optional Mains Adapter not operat- Check Mains Adapter. Remote Control ing correctly. not working Check link between remote &... -
Page 32: Fault Codes - Remote Control
Bad Connection between Remote responding intermittently. Control & Burner. Battery Low on Gas Control Valve (See Battery Replacement Section) Supplied by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 N00825AXX Rev: 002...
