Argon Arranmore/Bailey
INSTALLATION AND OPERATING INSTRUCTIONS
The complete installation must be done in accordance with current Standards and Local Codes. The
instructions in this manual must be followed to ensure safe operation of the appliance. It should be
noted that the requirements and this publication may be superseded during the life of the stove.
AFFIX SERIAL
NO. LABEL
The serial number above must be retained and will be required when
registering the product guarantee or making a warranty claim.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stanley Argon Arranmore
Summary of Contents for Stanley Argon Arranmore
- Page 1 PLEASE RETAIN Argon Arranmore/Bailey INSTALLATION AND OPERATING INSTRUCTIONS The complete installation must be done in accordance with current Standards and Local Codes. The instructions in this manual must be followed to ensure safe operation of the appliance. It should be noted that the requirements and this publication may be superseded during the life of the stove.
-
Page 2: Table Of Contents
Stanley Appliance Warranty ........ -
Page 3: Stanley Appliance Warranty
CONDITIONS OF WARRANTY Your Stanley Appliance is guaranteed against any part that fails (under normal operating conditions) for a two year peri- od from the date of installation of the appliance. If the unit is not installed within six months of date of purchase, the warranty will commence six months from the date of purchase. -
Page 4: Important Operation/ Maintenance Notes
IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Appliance is installed and no doubt you are looking forward to the many comforts it will provide, we would like to give you some tips on how to get the best results from your unit. -
Page 5: Installation & Operating Instructions
13 amp grounded socket. Your Stanley Appliance is supplied with the following items: • Remote Control (CR2025 Battery included) -
Page 6: Product Dimensions
PRODUCT DIMENSIONS Fig 2 Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. TECHNICAL DATA Voltage 240V AC 50-60 Hz Max Power 2050W No Heater Motor Heater Gross Weight (kgs): 15 Kg Efficiency Rating: COMMISSIONING AND HANDOVER On completion of the installation:... -
Page 7: Operation
OPERATION The unit can be operated either by the switches located on the RHS of the unit or using the remote control sup- plied. For the unit to operate, the ON/OFF switch, located on the underside of the canopy must be switched to the “I”... -
Page 8: Remote Control Operation
REMOTE CONTROL OPERATION Heater Operation Flame Operation Press the Power button to start the flame Press the Power button to start the flame picture and the current room temperature will picture and the current room temperature will be shown on the display. By pressing the Flame be shown on the display. -
Page 9: Setting The Time & Day (24 Hour Clock)
Setting the Time & Day (24 Hour Clock) Fig 6 Press the Power button to turn the unit on. Press & hold the Time Setting button for two seconds to display the time & day - see Fig 6 ( no numbers shown as time not set). Press the Time Setting button &... -
Page 10: Cleaning
CLEANING NOTE: Allow the product to completely cool before handling or cleaning it. Switch off and unplug from the power supply before cleaning. Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface of the product. Do not allow water or other liquids to run into the interior of the product, as this could create a fire and/or electrical hazard. -
Page 11: Exploded View
EXPLODED VIEW DESCRIPTION PART NUMBER TRIM TOP F01347AXX BLOWER ASSEMBLY G00530AXX HEATING ELEMENT G00531AXX TRIM LH F01348AXX FRONT LOG V01083AXX FRET F01349AXX LOG LED G00532AXX MAIN SWITCH G00533AXX LED BOARD G00534AXX 10 CONTROL BOARD G00535AXX GEAR MOTOR G00536AXX 12 TRIM RH F01350AXX 13 PLUG G00537AXX... -
Page 12: Wiring Diagram
WIRING DIAGRAM Supplied by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 N00786AXX Rev: 001 SG 040518...
