Introduction

Specifications


Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.

CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
1 - 2 Specifications
Processor Options
Intel® Core™ i7 Processor
i7-10700 (2.90GHz)
16MB Smart Cache, 14nm, DDR4-2933MHz, TDP 65W
Intel® Core™ i5 Processor
i5-10600 (3.30GHz)
12MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
i5-10500 (3.10GHz)
12MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
i5-10400 (2.90GHz)
12MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
Intel® Core™ i3 Processor
i3-10320 (3.80GHz)
8MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
i3-10300 (3.70GHz)
8MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
i3-10100 (3.60GHz)
6MB Smart Cache, 14nm, DDR4-2666MHz , TDP 65W
Intel® Pentium® Processor
Gold G6600 (4.20GHz)
4MB Smart Cache, 14nm, DDR4-2666MHz, TDP 58W
Intel® Celeron Processor
Celeron G5920 (3.50GHz)
2MB Smart Cache, 14nm, DDR4-2666MHz, TDP 58W
Core Logic
Mobile Intel® H410 Express Chipset
BIOS
128Mb SPI Flash ROM
INSYDE BIOS
LCD Options
15.6" (39.62cm), 16:9, FHD (1920x1080)
Memory
Dual Channel DDR4
Two 260 Pin SO-DIMM Sockets
Supporting up to 3200MHz DDR4 Memory
Memory Expandable up to 32GB
Compatible with 4GB, 8GB or 16GB Modules
(The real memory operating frequency depends on the FSB
of the processor.)
Video Adapter
Intel® Integrated GPU and NVIDIA® Discrete GPU
Supports Microsoft Hybrid Graphics
Intel Integrated GPU
Intel® UHD Graphics 630 (i7-10700, i5-10600, i5-10500, i5-
10400, i3-10320, i3-10300, i3-10100, G6600)
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Intel® UHD Graphics 610 (G5920)
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Storage
One Changeable 2.5" 7mm (h) SATA HDD/SSD
(Factory Option) One M.2 2280 PCIe Gen3 x4 Solid State
Drive (SSD)
Audio
High Definition Audio Compliant Interface
Built-In Microphone
(Factory Option) Built-In Array Microphone
Two Speakers
