Specifications - Clevo NJ70PU Service Manual

Introduction

Specifications


Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
Note that this computer model series may sup-
port a range of CPUs and/or video adapters.
To find out which CPU is installed on your sys-
tem go to the Start menu and select Settings,
and then select System and click About. This
will also provide information on the amount of
Installed RAM etc.
To get information on your system's video
adapter go to the Start menu and select Set-
tings, and then select System and click Dis-
play > Advanced display settings > Display
adapter properties.

CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
1 - 2 Specifications
Processor Options
Intel® Core™ i7 Processor
i7-1255U (1.70GHz)
Intel® Core™ i5 Processor
i5-1235U (1.30GHz)
Intel® Core™ i3 Processor
i3-1215U (1.20GHz)
BIOS
Insyde BIOS (256Mb SPI Flash ROM)
Memory
Dual Channel DDR4
Two 260 Pin SO-DIMM Sockets Supporting DDR4 3200MHz
Memory
Memory Expandable up to 64GB
Compatible with 8GB, 16GB or 32GB Modules
(The real memory operating frequency depends on the FSB of
the processor.)
LCD Options
LCD, 17.3" (43.94cm), 16:9, FHD (1920x1080)
Storage
One Changeable 2.5" 7mm (h) SATA HDD/SSD
One M.2 PCIe Gen4 x4 Solid State Drive (SSD)
(Factory Option) One 9.0/9.5mm(h) Optical Device Type
Drive (DVD Writer)
Or
(Factory Option) Dummy ODD
Or
(Factory Option) 7mm (h) 2nd HDD/SSD Caddy
Video Adapter
Intel Iris Xe Graphics ( i7-1255U, i5-1235U)
HDR Support
Rec. 2020 (Wide Color Gamut)
Microsoft DirectX® 12 Compatible
Intel UHD Graphics (i3-1215U)
HDR Support
Rec. 2020 (Wide Color Gamut)
Microsoft DirectX® 12 Compatible
Pointing Device
Built-in Touchpad (with Microsoft PTP Multi Gesture & Scroll-
ing Functionality)
Keyboard
Full-size Keyboard (with Numeric Keypad)
Or
(Option) Full-size Multi-Color LED Keyboard (with Numeric
Keypad)
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Array Microphone
Sound Blaster Cinema 6+
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel PTT for Systems Without TPM Hardware
(Factory Option) TPM 2.0
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for PCIe Gen4 x4 SSD
(Factory Option) Slot 3 for 4G Module
