  • Page 1 N650DU...
  • Page 3 Preface Notebook Computer N650DU Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N650DU se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Part Lists ..........A-1 Overview ..................1-1 Part List Illustration Location ............A-2 Specifications ..................1-2 Top ....................A-3 External Locator - Top View with LCD Panel Open ......1-4 Bottom ................... A-4 External Locator - Front & Right Side Views .........1-5 LCD ....................
  • Page 12 Preface Skylake-H 7/9 ................B-21 Restart the computer (booting from the HDD) .......C-2 Skylake-H 8/9 ................B-22 Skylake-H 9/9 ................B-23 M.2 WLAN, 3G ................B-24 M.2 SSD, CCD, Fan, Audio, LED ..........B-25 ASM1142 ..................B-26 USB ....................B-27 HDD, PWR LED, LID ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N650DU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel GPU (CPU integrated) i7-6700 (3.40GHz) Intel HD Graphics 530 (Core i7/i5/i3/Pentium CPU 8MB Smart Cache, 14nm, DDR4-2133MHz, TDP 65W  Integrated) Intel® Core™ i5 Processor Dynamic Frequency (Intel Dynamic Video Memory Technol- Latest Specification Information i5-6500 (3.20GHz) ogy)
  • Page 15 Introduction Security Interface Environmental Spec Security (Kensington® Type) Lock Slot One USB 2.0 Port Temperature ° ° BIOS Password Operating: 5 C - 35 Two USB 3.0 (USB 3.1 Gen 1) Type A Ports (Factory Option) TPM v2.0 Non-Operating: -20°C - 60°C Intel PTT for systems without hardware TPM Relative Humidity (Factory Option) One USB 3.1 Gen 2 Type A Port and one...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. Multi-in-1 Card Reader 2. LED Indicator FRONT VIEW Figure 3 Right Side View 1. S/PDIF-Out Jack RIGHT SIDE VIEW 2. Microphone Jack 3. Headphone Jack 4. USB 2.0 Ports 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. HDMI-Out Port 3. RJ-45 LAN Port LEFT SIDE VIEW 4. External Monitor Port 5. Vent 6. USB 3.0/3.1 Port (Type C) 7.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Component Bay Cover 4. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. PCH 2. CPU 3. Memory Slots DDR4 SO-DIMM 4. CMOS Battery Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. RJ-45 LAN Port 3. External Monitor Port 4. USB Ports 3.0/3.1 (Type C) 5. USB Ports 3.0/3.1 (Type A) 6. SIM Card Reader 7. Keyboard Cable Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CCD Connector 2. 3G/4G Card Connectort 3. ODD Connector 4. HDD Connector 5. Speaker Connector 6. Multi-in-1 CardReader 7. SSD Card Connector 8. LCD Cable Connector 9. WLAN Connector 10.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N650DU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the 3G Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7.0mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 5. Remove the screw from the hard disk assembly (Figure 3d Figure 3 6. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 3e HDD Assembly 7. Lift the hard disk assembly out of the bay (Figure 3f Removal (cont’d.) 8.
  • Page 32 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. For more information contact your distributor/supplier, and bear in mind your warranty terms.

  • Page 33: Removing The Caddy/2Nd Hdd

    Disassembly Removing the Caddy/2nd HDD Figure 5 Caddy/2nd HDD 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Removal 2. Remove the screw at point , and use a screwdriver to carefully push out the caddy at point 3.

  • Page 34: Removing The Optical Device

    Disassembly Removing the Optical Device Figure 6 ODD Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point a.

  • Page 35: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 7 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1066/1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR3L Modules.
  • Page 36 Disassembly 4. Pull the latches to release the second module if necessary. Figure 8 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. RAM Module 6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot Assembly as it will go.

  • Page 37: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 9 Processor Removal Procedure Processor Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5), component bay cover (page 2 - 6) and a. The CPU heat sink will (page 2 - 11).
  • Page 38 Disassembly 5. Press down and hold the latch (with the latch held down you will be able to release it). Figure 10 6. Move the latch and bracket fully in the direction indicated to unlock the CPU(Figure 10c). Processor Removal 7.
  • Page 39 Disassembly Processor Installation Procedure Figure 11 Processor 1. Insert the CPU (Figure 11a), pay careful attention to the pin alignment, it will fit only one way (DO NOT Installation FORCE IT!) (Figure 11a). 2. Move the bracket and latch fully in the direction indicated to lock the CPU. 3.

  • Page 40: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Remove screws from the bottom case (Figure 12a). a. Remove the screws. 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- b.
  • Page 41 Disassembly 6. Connect the keyboard ribbon cable to the locking collar socket , and be careful not to bend the keyboard ribbon Figure 13 cable (Figure 13d). Keyboard Assembly 7. Insert the keyboard at point and then slide the keyboard in at point (Figure 13e).

  • Page 42: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 14 3G Module Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 2. The 3G module will be visible at point on the mainboard (Figure 14a).

  • Page 43: Removing The Wlan Module

    Disassembly Removing the WLAN Module Figure 15 WLAN Module 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Removal 2. The WLAN module will be visible at point on the mainboard (Figure 14a).

  • Page 44: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 45: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 16 M.2 SSD Module 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Removal 2. The M.2 SSD module will be visible at point on the mainboard (Figure 16a).

  • Page 46: Removing The Ccd

    Disassembly Removing the CCD Figure 17 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Run your fingers around the inner frame of the LCD panel at the points as indicated by the arrows (Figure a.
  • Page 47 Disassembly 5. Disconnect the cable Figur 6. Remove the CCD module (Figure 18f). CCD Re 7. Reverse the process to install a new CCD module. (con d. Disconnect e. Remove the ule.  7. CCD Modu Removing the CCD 2 - 23...
  • Page 48 Disassembly 2 - 24 Removing the CCD...

  • Page 49: Part Lists

    Appendix A:Part Lists This appendix breaks down the N650DU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 50: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W950LU Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 page A - 8 2ND HDD...

  • Page 51: Top

    Figure A - 1 Top A - 3...

  • Page 52: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 53: Lcd

    Figure A - 3 LCD A - 5...

  • Page 54: Dvd

    Figure A - 4 A - 6 DVD...

  • Page 55: Hdd

    Figure A - 5 HDD A - 7...

  • Page 56: 2Nd Hdd

    2nd HDD Figure A - 6 2nd HDD A - 8 2nd HDD...
  • Page 57 Figure A - 7 MB A - 9...
  • Page 58 A - 10...

  • Page 59: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N650DU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 System Block Diagram - Page B - 2 Skylake-H 3/9 - Page B - 17 KBC-ITE IT8587 - Page B - 32...

  • Page 60: System Block Diagram

    Schematic Diagrams System Block Diagram 5IN1 N650DU N650DU System Block Diagram 5V,3V,5VS,3VS 6-7P-N6505-004 SHEET 33 N650DU MAIN BOARD PANEL Connector SHEET 1~40 SHEET 12 VCORE,VCCGT PCB:6-71-N6500-D03 SHEET 34,35,36 w/eDP, w/USB3.1, w/TPM, w/LTE LVDS*2 SKYLAKE-S BOM:6-77-N650DU00-D03 1 vias <5" w/eDP, w/USB3.1, w/o TPM, w/o LTE VCCSA EDP*2 PROCESSOR...

  • Page 61: Processor 1/7

    Schematic Diagrams Processor 1/7 SKYLAKE-S Processor 1/7 ( DMI,FDI,PEG ) SKL_S_CPU *H6_0D3_7 *H6_0D4_0 *H6_0D4_0 LGA1151 PEG_RXP[0] PEG_TXP[0] PEG_RXN[0] PEG_TXN[0] PEG_RXP[1] PEG_TXP[1] PEG_RXN[1] PEG_TXN[1] *H8_0B7_5D5_5 *H8_0B7_5D5_5 *H8_0B7_5D5_5 *H8_0B7_5D5_5 PEG_RXP[2] PEG_TXP[2] PEG_RXN[2] PEG_TXN[2] PEG_RXP[3] PEG_TXP[3] PEG_RXN[3] PEG_TXN[3] PEG_RXP[4] PEG_TXP[4] PEG_RXN[4] PEG_TXN[4] PEG_RXP[5] PEG_TXP[5] PEG_RXN[5] PEG_TXN[5]...

  • Page 62: Processor 2/7

    Schematic Diagrams Processor 2/7 SKYLAKE-S Processor 2/7 (JTAG,CLK,CFG ) VCCST_VCCPLL DESIGN NOTE: DESIGN NOTE: CFG[4] H_VIDALERT_N_VR 1:Disabled - No Physical Display Port 56.2_1%_04 CFG[6:5] attached to Embedded DisplayPort*. H_VIDSOUT 00 = 1x8, 2x4 PCI Express* 01 = reserved 100_1%_04 No connect for disable. 10 = 2x8 PCI Express* 11 = 1x16 PCI Express* 75_1%_04 H_PROCHOT_N...

  • Page 63: Processor 3/7

    Schematic Diagrams Processor 3/7 SKYLAKE-S Processor 3/7 ( DDR4 ) SKL_S_CPU SKL_S_CPU M_A_DQ[63:0] M_B_DQ[63:0] LGA1151 LGA1151 M_A_DQ0 AE38 AW18 M_B_DQ0 AD34 AM20 M_A_CLK_DDR0_P M_B_CLK_DDR0_P DDR0_DQ[0] DDR0_CKP[0] DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_A_DQ1 AE37 AV18 M_B_DQ1 AD35 AM21 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR0_N DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] M_B_CLK_DDR0_N M_A_DQ2 AG38 AW17...

  • Page 64: Processor 4/7

    Schematic Diagrams Processor 4/7 SKYLAKE-S Processor 4/7 ( DISPLAY ) SKL_S_CPU LGA1151 VGA_D1_TX0_P EDP_TX0_P 11 DDI1_TXP[0] EDP_TXP[0] VGA_D1_TX0_N EDP_TX0_N DDI1_TXN[0] EDP_TXN[0] DDI TO VGA PORT LVDS & EDP PORT VGA_D1_TX1_P DDI1_TXP[1] EDP_TXP[1] EDP_TX1_P 11 VGA_D1_TX1_N EDP_TX1_N DDI1_TXN[1] EDP_TXN[1] DDI1_TXP[2] EDP_TXN[2] DDI1_TXN[2] EDP_TXP[2] DDI1_TXP[3]...

  • Page 65: Processor 5/7

    Schematic Diagrams Processor 5/7 SKYLAKE-S Processor 5/7 ( POWER ) DESIGN NOTE: VCCCORE PLACE CAPS IN SOCKET EDGE BOTTOM/TOP VCCCORE VCCCORE C128 C109 C115 C455 C446 C423 SKL_S_CPU 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 LGA1151 DESIGN NOTE: C418 C451 C454 C444 C105 C101...

  • Page 66: Processor 6/7

    Schematic Diagrams Processor 6/7 SKYLAKE-S Processor 6/7 ( GND ) DESIGN NOTE: SKL_S_CPU SKL_S_CPU SKL_S_CPU VCCGT SKL_S_CPU LGA1151 DESIGN NOTE: VCCGT AK29 AC33 AA34 VCCGTX VCCGT VCCGTX AK30 AB39 VSS_NCTF AA35 PLACE CAPS IN SOCKET EDGE BOTTOM/TOP VCCGT VCCGTX AK36 AA36 C107 C430...

  • Page 67: Processor 7/7

    Schematic Diagrams Processor 7/7 SKYLAKE-S Processor 7/7 ( RESERVED ) SKL_S_CPU LGA1151 RSVD_TP RSVD_TP RSVD_TP RSVD_TP RSVD_TP AW38 RSVD_TP RSVD_TP AV39 RSVD_TP RSVD_TP AU39 RSVD_TP RSVD AU40 RSVD AT15 RSVD AR23 RSVD Sheet 8 of 44 AR22 RSVD Processor 7/7 RSVD RSVD RSVD...

  • Page 68: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 JDIMM1A Channel A SO-DIMM 0[RAM1] M_A_DQ[63:0] M_A_DQ0 M_A_CLK_DDR0_P CK0_T M_A_DQ1 M_A_CLK_DDR0_N CK0_C M_A_DQ2 M_A_CLK_DDR1_P CK1_T M_A_DQ3 M_A_CLK_DDR1_N REV TYPE H=9.2mm CK1_C M_A_DQ4 M_A_DQ5 M_A_CKE0 CKE0 M_A_DQ6 M_A_CKE1 CKE1 M_A_DQ7 M_A_DQ8 JDIMM1 = CHA DIMM0 000 M_A_CS0_N JDIMM1B VDDQ...

  • Page 69: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 JDIMM2A Channel B SO-DIMM 0[RAM2] M_B_DQ[63:0] M_B_DQ0 M_B_CLK_DDR0_P CK0_T M_B_DQ1 M_B_CLK_DDR0_N CK0_C M_B_DQ2 M_B_CLK_DDR1_P CK1_T M_B_DQ3 M_B_CLK_DDR1_N REV TYPE H=5.2mm CK1_C M_B_DQ4 M_B_DQ5 M_B_CKE0 CKE0 M_B_DQ6 M_B_CKE1 CKE1 M_B_DQ7 M_B_DQ8 M_B_CS0_N JDIMM2B M_B_DQ9 VDDQ VDDQ_VT M_B_CS1_N M_B_DQ10 DQ10...

  • Page 70: Ps8625

    Schematic Diagrams PS8625 PS8625(EDP TO LVDS) DESIGN NOTE: 30mil 3.3VS 3.3VS PS8625_VDDIO LVDS_VDDEN LVDS_VDDEN *HCB1005KF-121T20 *HCB1005KF-121T20 *BCNR3010C-2R2M *HCB1005KF-121T20 PS8625_VDDIOX PS8625_SW _OUT PS8625_VDD12 PS8625_VDDRX LVDS_BKLTEN LVDS_BKLTEN LVDS LVDS LVDS LVDS PS8625_EDP_PANEL_PW M EDP_LVDS_PANEL_PW M R466 0_04 EDP_LVDS_PANEL_PW M C384 C388 LVDS *22u_6.3V_X5R_08 *0.47u_10V_Y5V_04 *1u_6.3V_X5R_04...

  • Page 71: Panel,Inverter

    Schematic Diagrams Panel, Inverter PANEL,INVERTER PANEL PLVDD POWER PANEL CONNECTOR (For coaxial cable) PLVDD PN:G5243A--6-02-05243-9C0 PLVDD 3.3VS J_LCD1 VOUT NEAR PIN4,5 C373 C372 R444 C374 C380 3.3VS 1u_6.3V_X5R_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 *100K_04 1u_6.3V_X5R_04 PANEL_EN up7553 >100 mil R442 0_04 FOR EDP EDP_VDDEN LVDS-U0N LVDS-U0P...

  • Page 72: Crt

    Schematic Diagrams CRT PORT 0.1u_16V_Y5V_04 R120 *4.7K_04 3.3VS 5VS_CRT POWER Rb R1497 pull down VCCK_V12 from external R124 4.7K_04 2.2u_6.3V_X5R_04 4.7K_04 Ra R1496 pull up VCCK_V12 from LDO enable 3.3VS 6-01-74112-280 3.3VS 0.1u_16V_Y5V_04 RTD2168_AVCC_33 RTD2168_VGA_VS RTD2168_VGA_VS_R RTD2168_1.2V_LDO_EN FCM1005MF-600T01 RTD2168_1.2V_LDO_EN R121 *4.7K_04 R126 4.7K_04...

  • Page 73: Skylake

    Schematic Diagrams Skylake-H 1/9 DESIGN NOTE: SKY LAKE - S (SATA,PCIE,CLINK) 3.3VS SV ADVANCE MENU JUMPER R199 10K_04 PCH_SATA_LED_N SV ADVANCE MENU TABLE SKL_PCH_H BOARD STYLE M.2_CLINK_CLK_W LAN NORMAL MENU (DEFAULT) M.2" HDD1 CL_CLK PCIE9_RXN/SATA0A_RXN M.2_SSD_P0_RX_DN M.2_CLINK_DATA_W LAN 3.3VA M.2_SSD_P0_RX_DP CL_DATA PCIE9_RXP/SATA0A_RXP M.2_CLINK_RST_W LAN_N...

  • Page 74: Skylake-H 2/9

    Schematic Diagrams Skylake-H 2/9 SKY LAKE - S (SPI,GSX,GPP) DESIGN NOTE: DESIGN NOTE: 3.3V V3P3A_V1P8A_PCH_SPI WIGIG GPIO JTAG ODT IS DISABLED IF LOW PCH HAS INTERNAL WEAK PU V3P3A_V1P8A_PCH M.2_W IGIG_W GPIO R164 *10K_04 SPI_MISO R395 *20K_04 R165 *1K_04 R400 *4.7K_04 R641 10K_04...

  • Page 75: Skylake-H 3/9

    Schematic Diagrams Skylake-H 3/9 VDD3 10K_8P4R_04 ACPRESENT BATLOW _N SLP_W LAN_N LANW AKE_SMC_W AKE_SCI_N R636 4.7K_04 SKY LAKE - S (HDA,SMB,JTAG) PCH_W AKE_N R637 1K_04 PW R_BTN_N R282 3K_1%_04 LAN_DISABLE_N R281 *10K_04 1.0VA 3.3VS SKL_PCH_H R604 1K_04 ITP_PMODE TPM_CLKRUN_N R652 8.2K_1%_04 R258 100K_04...

  • Page 76: Skylake-H 4/9

    Schematic Diagrams Skylake-H 4/9 3.3VS 2.2K_8P4R_04 VGA_B_DATA SKY LAKE - S (HPD,DDP,GPP) VGA_B_CLK HDMI_C_DATA HDMI_C_CLK SKL_PCH_H VGA_OUT PORT B HDMI_C_CLK HDMI_OUT PORT C GPP_I7/DDPC_CTRLCLK HDMI_C_CLK VGA_HPD HDMI_C_DATA HDMI_C_DATA VGA_HPD GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA HDMI_C_HPD VGA_B_CLK HDMI_OUT PORT C VGA_OUT PORT B HDMI_C_HPD GPP_I1/DDPC_HPD1 GPP_I5/DDPB_CTRLCLK DP_HPD...

  • Page 77: Skylake-H 5/9

    Schematic Diagrams Skylake-H 5/9 SKY LAKE - S (CLKOUT,CLKREQ) DESIGN NOTE: DESIGN NOTE: SKL_PCH_H C489 10p_50V_NPO_04 TP_CLKOUT_48 AR17 GPP_A16/CLKOUT_48 CLKOUT_ITPXDP PCH_CPU_NSSC_CLK_DP CLKOUT_CPUNSSC_P CLKOUT_ITPXDP_P PCH_CPU_NSSC_CLK_DN PCH_CPU_PCIBCLK_DN CLKOUT_CPUNSSC CLKOUT_CPUPCIBCLK R533 PCH_CPU_PCIBCLK_DP CLKOUT_CPUPCIBCLK_P PCH_CPU_BCLK_DP CLKOUT_CPUBCLK_P FSX3M_24MHZ 1M_04 PCH_CPU_BCLK_DN CLKOUT_CPUBCLK CLKOUT_PCIE_N0 XTAL_24M_PCH_OUT R534 *10mil_short Sheet 18 of 44 XTAL24_OUT CLKOUT_PCIE_P0...

  • Page 78: Skylake-H 6/9

    Schematic Diagrams Skylake-H 6/9 3.3VA USB PORT Function PORT USB 2.0 PORT 1 M/B PORT 1 USB_OC0_R_N USB_OC4_R_N USB_OC1_R_N USB 2.0 PORT 2 M/B PORT 2 USB_OC2_R_N USB 2.0 PORT 3 M/B PORT 3 SKY LAKE - S (DMI,USB) 10K_8P4R_04 USB 2.0 PORT 4 USB_OC5_R_N...
  • Page 79 Schematic Diagrams Skylake-H 7/9 DESIGN NOTE: DESIGN NOTE: PLACE HOLDER FOR VCCAUSB_1P0 AND VCCAAZPLL_1P0 FILTER EDGE CAP FOR VCCMPHY_1P0 AND VCCDUSB_1P0 V1P0A_VCCAPLL 1.0VA 1.0VA C210 R189 *15mil_short_06 C227 1u_6.3V_X6S_04 *22u_6.3V_X5R_08 SKY LAKE - S (POWER,RTC) DESIGN NOTE: BOARD CAP FOR VCCPRTCPRIM_3P3 DESIGN NOTE: V3P3A_V1P8A_PCH PLACE HOLDER FOR VCCMPHYPLL_1P0 FILTER...

  • Page 80: Skylake-H 8/9

    Schematic Diagrams Skylake-H 8/9 3.3VS LPC_SIRQ R279 10K_04 R303 10K_04 KBRST_N PCH_SMI_N R540 10K_04 PCH_SMI_N R541 *10K_04 SKY LAKE - S (SSIC,USB3,LPC) M/B USB3.0 PORT1 SKL_PCH_H USB3_TX1_N USB3_1_TXN AT22 USB3_TX1_P USB3_1_TXP GPP_A1/LAD0/ESPI_IO0 LPC_AD0 27,31 AV22 USB3_RX1_N USB3_1_RXN GPP_A2/LAD1/ESPI_IO1 LPC_AD1 27,31 AT19 USB3_RX1_P USB3_1_RXP...

  • Page 81: Skylake-H 9/9

    Schematic Diagrams Skylake-H 9/9 SKY LAKE - S (UR,RSVD,GND) 3.3VS DESIGN NOTE: DESIGN NOTE: NO REBOOT IF SAMPLED HIGH PCH HAS INTERNAL WEAK PD SKL_PCH_H SKL_PCH_H R349 *4.7K_04 SKL_PCH_H AB11 AC18 LPSS_GSPI1_MOSI AT29 LPSS_GSPI0_MOSI GPP_B22/GSPI1_MOSI TBTA_ACE_GPIO2 AB14 AN10 AR29 AL44 GPP_B21/GSPI1_MISO GPP_D9 AB31...

  • Page 82: M.2 Wlan, 3G

    Schematic Diagrams M.2 WLAN, 3G UIM_PW R_R UIM_DATA *4.7K_04 M2. 3G NGFF B KEY SIM CONN 3G_3.3V 80 mils MSATA function C428 220u_6.3V_6.3*6.3*4.2 J_SIM1 *10mil_short (TOP VIEW) J_3G1 0.1u_16V_Y5V_04 DETECT_SW 1K_04 DETECT_SW UIM_MCMD UIM_DATA NFSB0-S6701-TP40 UIM_DATA UIM_I/O 3G_CONFIG2 UIM_CLK *10mil_short UIM_C UIM_VPP CONFIG_2...

  • Page 83: M.2 Ssd, Ccd, Fan, Audio, Led

    Schematic Diagrams M.2 SSD, CCD, Fan, Audio, LED LED CONN CPU FAN CONTROL CCD+ DIGITAL MIC J_LED1 LED_HDD_N 3.3VS 48 mil CCD_3.3VS AIRPLAN_LED# LED_BAT_FULL VOUT LED_BAT_CHG FAN_CPU_5VS VOUT C286 C402 C400 LED_PW R VSET LED_ACIN 0.1u_16V_Y5V_04 NCT3940S-A 1u_6.3V_X5R_04 2.2u_6.3V_X5R_04 CPU_FAN up7553 3.3VS CCD_EN...

  • Page 84: Asm1142

    Schematic Diagrams ASM1142 C1737 USB3.1 10u_6.3V_X5R_06 Pin 38 C1743 USB3.1 0.1u_16V_Y5V_04 Pin 35 ASM1142 USB3.1 HW STRAP 3.3VS_ASM1142 1.2VS C1736 USB3.1 10u_6.3V_X5R_06 Pin 44 C1740 USB3.1 10u_6.3V_X5R_06 Pin 47 C1739 USB3.1 0.1u_16V_Y5V_04 Pin 55 C1741 USB3.1 10u_6.3V_X5R_06 Pin 52 ASM1142_UART_TX 4.7K_04 Pin 62 USB3.1...

  • Page 85: Usb

    Schematic Diagrams USB3.0./3.1 PORT2 (TYPE C) D187 TEA10402V15A0 D186 TEA10402V15A0 A_URXN_SW 2 R1797 0_04 A_URXN_SW 2_J USBVCC3.1_1 5V_MUX A_URXP_SW 2 A_URXP_SW 2_J R1796 0_04 100 MIL 5V_MUX A_UTXN_SW 2 C1657 0.22u_10V_X5R_04 A_UTXN_SW 2_J VIN1 VOUT1 C1666 C1756 C1757 A_UTXP_SW 2 C1658 0.22u_10V_X5R_04 A_UTXP_SW 2_J...

  • Page 86: Hdd, Pwr Led, Lid

    Schematic Diagrams HDD, PWR LED, LID HDD CONNECT LID SWITCH TPM 2.0 SLB9665TT & NPCT650 COLAY OQDU761 R693 *0_04 3.3V R692 0_04 3.3VS J_HDD1 C590 C594 TMC:766! 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 HDD_SATA_TX_2_P HDD_SATA_TX_2_N 21,31 LPC_AD0 LAD0 PIN5 PIN5 21,31 LPC_AD1 LAD1 NC_2 C566 0.01u_50V_X7R_04 HDD_SATA_RX_2_N...

  • Page 87: Hdmi

    Schematic Diagrams HDMI HDMI_5VS HDMI CONNECTOR RB751S-40C2 BAV99H BAV99H BAV99H R441 R440 2.2K_04 2.2K_04 HDMI_SCL-C HDMI_5VS HDMI_SDA-C HDMI_HPD-C J_HDMI1 VOUT 32,37 SUSB 22u_6.3V_X5R_08 22u_6.3V_X5R_08 R447 HDMI_HPD-C UP7549UMA5-20 HOT PLUG DETECT 20K_04 DDC/CEC GND HDMI_SDA-C HDMI_SCL-C RESERVED TMDS_CLOCK_J_N TMDS CLOCK- CLK SHIELD TMDS_CLOCK_J_P TMDS CLOCK+ TMDS_DATA0_J_N...

  • Page 88: Lan, Card Reader

    Schematic Diagrams LAN, Card Reader AVDD33 (W>60mil LDO Mode LAN (RTL8111G) VDD10 L<200mil) R484 *15mil_short VDD3 REGOUT *15mil_short VDD10 2.49K_1%_04 (>60mil) R482 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *1K_04 *15mil_short PIN11 PIN32 0.1u_16V_Y5V_04 VDDREG/VDD33 LED1/GPO 60 mil LED2 FOR S5 WAKE UP ON LAN E_PAD R496 10K_04...

  • Page 89: Audio Codec

    Schematic Diagrams Audio Codec EMI Require AUDIO CODEC (ALC269 VC2) R683 *15mil_short_06 R714 *15mil_short_06 PVDD1_2 HCB1005KF-121T20 C578 0.1u_16V_Y5V_04 DVDD_IO C603 C593 C619 0.1u_16V_Y5V_04 R425 *20mil_short_04 10u_6.3V_X5R_06 0.1u_10V_X7R_04 3.3VS_AUD C367 C368 AUDG 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 C602 C604 10u_6.3V_X5R_06 0.1u_10V_X7R_04 ANALOG DIGITAL 3.3VS_AUD 5VS_AUD HCB1005KF-121T20 HCB1005KF-121T20...

  • Page 90: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD HCB1005KF-121T20 VDD3 VDD3 C247 C307 C308 C281 C220 C258 VDD3 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 C279 KBC_AGND R329 U18B 10K_04 0.1u_16V_Y5V_04 EC_VCC 3.3VS SUS_PW R_ACK GPJ0/TACH2 5VT/SSCE0#/GPG2 CHG_JAP GPJ4/DAC4/DCD0# HCB1005KF-121T20 KBLIGHT_ADJ GPJ5/DAC5/RIG0# J_KB1 J_KB1 U18A 85208-24051 ME_W E GPJ2/DAC2//TACH0B...

  • Page 91: 5V, 5Vs, 3.3V, 3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3VS, 3.3VA VIN1 DD_ON R707 100K_04 R706 10K_04 For USB CHARGE VIN1 R708 1_1%_06 R709 *100K_04 VDD5 VDD5 DD_ON_LATCH USB_CHARGE_EN 31,38 R710 10K_04 W USB CHANGE C352 EM5209 C356 M_BTN# M_BTN# PWR_SW# R713 *100K_04 R711 10K_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04...

  • Page 92: Vcore, Vccgt

    Schematic Diagrams VCORE, VCCGT ,QWHO 6.</$.( ,093 32:(5 9&25(  3+$6( PROG PR187 CONFIGURATION 3.3VS 3.3VS VCCST_VCCPLL 10K_1%_04 PR85 PR81 PR185 PR78 PC124 10K_04 10K_04 2.2_06 PR75 PR76 PR197 1K_1%_04 1u_6.3V_X5R_04 PC37 PC38 PC118 *0.1u_10V_X7R_04 0.01u_50V_X7R_04 PUT CLOSE 4.7u_6.3V_X5R_06 TO PWM VBOOT/ADDR DEFAULT PJ43...

  • Page 93: Vcore Output Stage

    Schematic Diagrams VCORE Output Stage VCORE OUTPUT STAGE PC100 PC99 PC120 PC686 1u_25V_X5R_06 4.7u_25V_X5R_08 *4.7u_25V_X5R_08 *4.7u_25V_X5R_08 EMC5 EMC9 EMC7 EMC6 PR167 PR162 PC86 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.01u_50V_X7R_04 2.2_06 2.2_06 0.22u_16V_X7R_06 NCP81151MNTBG INS298791805 INS298792227 PR171 2.2_06 MLP08 MLP08 0.9m ohm COMMON COMMON OS-CON CMME063T-R15MS0R907...

  • Page 94: Vccgt Output Stage, Vccsa

    Schematic Diagrams VCCGT Output Stage, VCCSA VCCGT OUTPUT STAGE PC15 PC13 PC90 PC89 1u_25V_X5R_06 4.7u_25V_X5R_08 *4.7u_25V_X5R_08 100u_25V_6.3*6.3*5.9 100u_25V_6.3*6.3*5.9 SCAR250-1 SCAR250-1 PC95 PR179 PR176 2.2_06 2.2_06 0.22u_16V_X7R_06 MDU1516 MDU1516 ULTRASO-8 ULTRASO-8 PQ22 PQ29 NCP81151MNTBG PR165 2.2_06 OS-CON CMME063T-R15MS0R907 PWM1A PR166 *10K_1%_06 VCCGT 33,34 DRVON...

  • Page 95: 1.0Va, Vccio

    Schematic Diagrams 1.0VA, VCCIO VCCIO VCCIO_PWRGD VCCST_VCCPLL 3.3VS 3.3V PR117 PR113 100K_04 PJ52 100K_04 VCCIO_PW RGD 15,33,35 1.0VA VCCIO VOUT C473 C476 *3mm PR114 PJ46 VOUT DEFAULT 1K_04 PQ11 1.0VA VCCST_VCCPLL VOUT C469 C463 R529 C437 C438 VCCIO VOUT 2SK3018S3 *2mm VOUT DEFAULT...

  • Page 96: Ddr 1.2V, 0.6Vs, 2.5V

    Schematic Diagrams DDR 1.2V, 0.6VS, 2.5V VDDQ_VT/0.6V VDDQ/1.2V PD14 PQ38 MDU1516 ULTRASO-8 PC166 PC165 PC164 up6163 RB0540S2 C579 VDDQ_R 10u_6.3V_X5R_06 DEFAULT PC73 0.1u_10V_X7R_04 VLDOIN VBST SHORT PJ33 PR147 VDDQ_R DEFAULT VDDQ_VT DRVH SHORT 0_06 *2mm PC66 1.0UH_10*10*4.5 PJ22 VTTGND VDDQ PCB Footprint = TMPC1004H 22u_6.3V_X5R_08 PR139...

  • Page 97: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR224 0_04 PC167 1u_6.3V_X5R_04 PR222 PR225 PC168 EN_3V EN_5V 1000p_50V_X7R_04 130K_1%_04 130K_1%_04 PC78 PC172 PC171 PC170 1000p_50V_X7R_04 PU12 VREG3 PC179 PC174 PC176 PC83 PC82 PC169 VCC_3P3DSW _PW RGD 1u_6.3V_X5R_04 PR226 *10K_04 VDD3 SYS3V VDD5 LDO3 PQ46 PC175 PC173...

  • Page 98: Ac_In, Charger

    Schematic Diagrams AC_In, Charger PC11 SMART CHARGER 0.1u_50V_Y5V_06 V_BAT PC106 PC101 PQ24 1500p_50V_04 PR41 0.1u_50V_Y5V_06 EMB20P03V 20K_04 MAIN 6-43-W65R0-030 J_DC_JACK1 VJACK 50310-00441 PQ21 EMB20P03V PRS1 0.01_1%_32 *RB0540S2 BCIHP-0730 8R2M EML10 Z4104 PRS2 0.01_1%_32 HCB2012KF-800T80 PR198 PC88 PC184 PC185 EMPC1769 PC85 PC84 PC91 EMPC1770...

  • Page 99: Front Led Board

    Schematic Diagrams Front LED Board *0_04 *0_04 6-71-N6504-D02 *0_04 *0_04 *0_04 *0_04 LED BOARD AIRPLANE HDD LED L_3.3VS L_3.3VS LD_ACIN1 Sheet 40 of 44 L_LED_ACIN 330_04 Front LED Board L_LED_PWR 330_04 330_04 330_04 RY-SP155HYYG4-1 LGND LD_AIR1 LD_HDD1 AC IN/POWER ON LED RY-SP190YG34-5M RY-SP190YG34-5M 6-52-57301-023...

  • Page 100: Audio Board

    Schematic Diagrams Audio Board USB2.0 PORT(PORT5) *0_04 *0_04 6-71-N6508-D02 *0_04 *0_04 *0_04 *0_04 USB POWER SWITCH AUSBVCC2.0_1 150 mil 150 mil VOUT AUDIO BOARD CONN 10u_6.3V_X5R_06 *0.1u_10V_X7R_04 UP7549UMA5-20 AGND AJ_AUD1 AGND AGND PCB Footprint = M-SOT23-5A 22u_6.3V_X5R_08 AGND 22u_6.3V_X5R_08 0.1u_16V_Y5V_04 AUSBVCC2.0_1 AGND AUSB_PP5...

  • Page 101: Click Board

    Schematic Diagrams Click Board *0_04 *0_04 6-71-N6502-D02A *0_04 *0_04 *0_04 *0_04 Sheet 42 of 44 Click Board CJ_TP1 CTPBUTTON_L CTPBUTTON_R FP226H-004S10M CGND CGND MAIN 6-20-94A40-004 CSW2 CSW1 T4BJB10-Q-T/R T4BJB10-Q-T/R CTPBUTTON_R CTPBUTTON_L 6-53-31500-B40 6-53-31500-B40 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 CGND CGND CGND CGND CH36 CH38 CH35 CH37...

  • Page 102: Odd To Hdd Board

    Schematic Diagrams ODD to HDD Board *0_04 *0_04 6-71-N650N-D02 *0_04 *0_04 *0_04 *0_04 Sheet 43 of 44 ODD to HDD Board ODD TO HDD BOARD VOUT=1.25(1+R1/R2) IF USE NCT3705U-33 LDO, mount C, dismount R1, R2. DJ_ODD1 DJ_HDD1 DSATA_TXP0 DSATA_TXN0 DSATA_RXN0 DSATA_RXP0 Closed TO REDRIVER IC D_5VS...

  • Page 103: Power Sequence

    Schematic Diagrams Power Sequence N650DU PWR SEQ N650DU Power On Sequence N650DU Power Down Sequence 2 RTCVCC t=Min 9mS VDDQ RTCRST# t=1.9774mS VDDQ_VT VDD3 t=1.9mS t=29uS BATLOW_N VCCST_VCCPLL t=1.5867mS 97.9mS 599mS ACPRESENT 2.5V t=336uS 518.8mS EC_SLP_SUS_N 3.3VS t=2.9267mS 521.3mS VCC_3P3A_PWRGD VCCIO t=3.2972mS 521.2mS...
  • Page 104 Schematic Diagrams B - 46...

  • Page 105: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 106: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
