  • Page 1 NP50HP / NP55HP-HM...
  • Page 3 Preface Notebook Computer NP50HP / NP55HP-HM Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the NP50HP / NP55HP-HM series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD (NP50HP) ................A-7 LCD (NP55HP-HM) ..............A-8 Overview ..................1-1 Schematic Diagrams......... B-1 Specifications ..................1-2 External Locator - Top View with LCD Panel Open ......1-4 System Block Diagram ..............B-2 External Locator - Front & Right Side Views .........1-5 Processor 1/6 ...................B-3...
  • Page 12 Preface mDP ....................B-29 Charger ..................B-61 Panel, Inverter ................B-30 NVVDD1 ..................B-62 HDMI ................... B-31 NVVDD2 ..................B-63 PCH 1/8 ..................B-32 PEX_VDD ..................B-64 PCH 2/8 ..................B-33 FBVDDQ ..................B-65 PCH 3/8 ..................B-34 1V8_AON, NV3V3, 3.3VA ............B-66 PCH 4/8 ..................B-35 Audio Board + Redriver ...............B-67 PCH 5/8 ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the NP50HP / NP55HP-HM series notebook com- puter. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. In- formation about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Security i7-11800H (2.30GHz), TDP 45W Security (Kensington® Type) Lock Slot i7-11600H (2.90GHz), TDP 45W BIOS Password i5-11400H (2.70GHz), TDP 45W Intel® PTT for Systems Without TPM Hardware  i5-11260H (2.60GHz), TDP 45W (Factory Option) TPM 2.0 Latest Specification Information Core Logic Video Adapter Options...
  • Page 15 Introduction Communication Environmental Spec Built-In 10/100/1000Mb Base-TX Ethernet LAN Temperature ° ° 1.0M HD Webcam Operating: 5 C - 35 Non-Operating: -20°C - 60°C WLAN/ Bluetooth M.2 Modules: Relative Humidity (Factory Option) Intel® Dual Band Wi-Fi 6 AX200, 2x2 AX Operating: 20% - 80% Wireless LAN + Bluetooth Non-Operating: 10% - 90%...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Webcam 2. *Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. Display 5. Power Button 6.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. Speaker 2. MicroSD Card Reader 3. USB 3.2 Gen 2 RIGHT SIDE VIEW Type-C Port 4. RJ-45 LAN Jack 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. Vent 3. USB 3.2 Gen 1 LEFT SIDE VIEW Type-A Ports 4. USB 2.0 Port 5. Microphone-In Jack 6. 2-In-1 Audio Jack (Headphone and Microphone) 7.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. RJ-45 LAN Jack 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (M.2 SSD Module) 2. Mini-Card Connector (WLAN Module) 3. PCH 4. GPU 5. CPU 6. Memory Slots DDR4 SO-DIMM 7. KBC-ITE IT5570 Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. Mini Display Port 3. HDMI Port 4. Keyboard Cable Connector 5. LED KB Connector 6. MicroSD Card Reader 7. USB 3.2 Gen 2 Type-C Port 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. RJ-45 LAN Jack 2. LED Connector 3. Clickpad Cable Connector 4. Audio Connector 5. Battery Connector 6. LCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the NP50HP / NP55HP-HM series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the Keyboard: 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Remove screws (Figure 1a). a. Remove the screws. 3. Carefully lift the bottom case up in the direction of the arrow at point and remove it (Figure 1b b.
  • Page 30 Disassembly 4. The battery will be visible at point on the computer (Figure 2d Figure 2 5. Carefully disconnect the cable , then remove screws (Figure 2e Battery Removal 6. Lift the battery off the computer (Figure 2f (cont’d.) 7. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover). d.

  • Page 31: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 32: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 2 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard.
  • Page 33 Disassembly M.2 SSD-2 Removal Procedure Figure 3 1. Turn off the computer, turn it over, remove the battery (page 2 - M.2 SSD-2 Module 2. The M.2 SSD module will be visible at point on the mainboard. Remove the screw (Figure 3a).

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has four memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) support- Removal ing DDR4 Up to 3200 MHz. The main memory can be expanded up to 32GB. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 5 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 5a).

  • Page 36: Wireless Lan, Combo Module Cables

    Disassembly Wireless LAN, Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identifi- cation as outlined in the table below.

  • Page 37: Part Lists

    Appendix A:Part Lists This appendix breaks down the NP50HP / NP55HP-HM series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 38: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part NP50HP NP55HP-HM Location page A - 3 page A - 4 page A - 5 Bottom...

  • Page 39: Top (Np50Hp

    Top (NP50HP) Figure A - 1 Top (NP50HP) Top (NP50HP) A - 3...

  • Page 40: Top (Np55Hp-Hm

    Top (NP55HP-HM) Figure A - 2 Top (NP55HP-HM) A - 4 Top (NP55HP-HM)

  • Page 41: Bottom

    Bottom Figure A - 3 Bottom Bottom A - 5...

  • Page 42: Main Board

    Main Board Figure A - 4 Main Board A - 6 Main Board...

  • Page 43: Lcd (Np50Hp

    LCD (NP50HP) Figure A - 5 LCD (NP50HP) LCD (NP50HP) A - 7...

  • Page 44: Lcd (Np55Hp-Hm

    LCD (NP55HP-HM) Figure A - 6 LCD (NP55HP-HM) A - 8 LCD (NP55HP-HM)

  • Page 45: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the NP50HP / NP55HP-HM notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 46: System Block Diagram

    Schematic Diagrams System Block Diagram 5V,3.3V,5VS,3.3VS NP50HP System Block Diagram SHEET 55 nVIDIA GPU NVVDD 40x40mm PCIE Gen4 X4 VCCST,VCCSTG,1.8VA GN20-E3 2714 Balls PCIE Gen4 X16 SHEET 56 (Include VRAM, OVRM, NGFF M Key eDP PANEL VDD3,VDD5 Green PAK) PCIE Gen4...

  • Page 47: Processor 1/6

    Schematic Diagrams Processor 1/6 U41C 3 OF 15 PEX4_RX3 PCIE4_RX_P_3 PCIE4_TX_P_3 PEX4_TX3 46 PEX4_RX#3 PCIE4_RX_N_3 PCIE4_TX_N_3 PEX4_TX#3 46 PEX4_RX2 PEX4_TX2 46 PCIE4_RX_P_2 PCIE4_TX_P_2 eDP PANEL PEX4_RX#2 PCIE4_RX_N_2 PCIE4_TX_N_2 PEX4_TX#2 46 PCIe_GEN4 U41O PCIe_GEN4 PEX4_RX1 PCIE4_RX_P_1 PCIE4_TX_P_1 PEX4_TX1 46 DIFF=85ohm PEX4_RX#1 PEX4_TX#1 46 PCIE4_RX_N_1 PCIE4_TX_N_1...
  • Page 48 Schematic Diagrams Processor 2/6 U41B M_B_DQ[63:0] U41A M_A_DQ[63:0] DDR4(IL) / DDR4(NIL) DDR4 M_B_DQ63 DDR4(IL) / DDR4(NIL) DDR4 2 OF 15 DDR1_DQ7_7/DDR1_DQ7_7 DDR1_CLK_P3 M_A_DQ63 1 OF 15 M_B_DQ62 1/29 DDR0_DQ7_7/DDR1_DQ5_7 DDR0_CLK_P3 DDR1_DQ7_6/DDR1_DQ7_6 DDR1_CLK_N3 M_A_DQ62 M_B_DQ61 Rubband DDR0_DQ7_6/DDR1_DQ5_6 DDR0_CLK_N3 DDR1_DQ7_5/DDR1_DQ7_5 DDR1_CLK_P2 M_A_DQ61 M_B_DQ60 DDR0_DQ7_5/DDR1_DQ5_5 DDR0_CLK_P2...

  • Page 49: Processor 3/6

    Schematic Diagrams Processor 3/6 VCCST PCI Express* Static x16 Lanes Numbering Reversal U41E 1: Normal (DEFAULT) CFG2 5 OF 15 CPU_ID <== PCH_CPU_BCLK_R_DP 0: Reversed BCLK_P RSVD_18 PCH_CPU_BCLK_R_DN BCLK CPU_CFG15 100_04 56.2_1%_04 CFG_15 CFG14_PCIE4_LANE R565 *1K_04 PCH_CPU_PCIBCLK_R_DP PCI_BCLK_P CFG_14 CPU_CFG13 eDP enable NEAR CPU PCH_CPU_PCIBCLK_R_DN...
  • Page 50 Schematic Diagrams Processor 4/6 105A VCCIN 4.3A VDDQ VCCIN VCCIN VCCIN VCCIN U41N U41J U41K VCORE 10uF x 25 14 OF 15 10 OF 15 11 OF 15 AH11 AB11 CB30 CG16 CN30 VSS_572 VDD2_1 VCCIN_140 VCCIN_215 VCCIN_1 VCCIN_73 AH12 AC11 CB31 CG17...

  • Page 51: Processor 5/6

    Schematic Diagrams Processor 5/6 Reference Power VCCST 1uF x 1 VCCST 1uF x 1 x 1(0402) x 2(0402) VCCIN_AUX VCCIO_OUT U41L VCCST 12 OF 15 VCCIO_OUT VCCSTG_OUT2 AA34 VCCIN_AUX_1 VCCIO_OUT VCCST VCCST VCCSTG VCCSTG VCCSTG AA36 0.97A VCCIN_AUX_2 AA39 VCCIN_AUX_3 VCCST_1 C163 C287...
  • Page 52 Schematic Diagrams Processor 6/6 U41F U41G U41H U41I 6 OF 15 7 OF 15 8 OF 15 9 OF 15 BN36 CB39 CU27 VSS_412 VSS_492 VSS_252 VSS_332 VSS_92 VSS_172 VSS_1 VSS_46 AL10 BA36 BN39 CC10 U41M VSS_413 VSS_493 VSS_253 VSS_333 VSS_93 VSS_173 VSS_2...

  • Page 53: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] VTT_MEM VDDQ J_DIMMA_1B 2.5V J_DIMMA_1A M_A_DQ[63:0] VDD19 VDD18 M_A_DQ3 PLACE THE CAP CLOSE TO SODIMM M_A_CLK_DDR0 CK0_T VDD17 M_A_DQ0 M_A_CLK_DDR#0 CK0_C VDD16 VPP2 DDR_VREFCA_CHA_DIMM M_A_DQ4 M_A_CLK_DDR1 CK1_T VDD15 VPP1 M_A_DQ7 M_A_CLK_DDR#1 CK1_C VDD14 M_A_DQ2...

  • Page 54: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 VTT_MEM J_DIMMB_1B Channel B SO-DIMM 0[RAM2] VDDQ 2.5V VDD19 VDD18 VDD17 J_DIMMB_1A VDD16 VPP2 M_B_DQ[63:0] VDD15 VPP1 M_B_DQ0 M_B_CLK_DDR0 CK0_T VDD14 M_B_DQ6 M_B_CLK_DDR#0 CK0_C VDD13 3.3VS M_B_DQ1 M_B_CLK_DDR1 CK1_T VDD12 M_B_DQ2 M_B_CLK_DDR#1 CK1_C VDD11 M_B_DQ3 VDD10 VDDSPD M_B_DQ5...

  • Page 55: Vga Pci-E Interface

    Schematic Diagrams VGA PCI-E Interface 1V8_AON 28,63 NVVDD_PWRGD R616 NV PCI EXPRESS 10K_04 2SK3018S3 PEG_CLKREQ# NV recommend del 1V8_AON R614 *10K_04 1V8_AON R615 R611 *10K_04 *10K_04 Place between 1/24 PCI_EXPRESS Place near balls GPU and PS PEX_VDD *2SK3018S3 BR31 PEX_WAKE PEG_WAKE# BF32 PEX_DVDD...

  • Page 56: Frame Buffer Partition A/B

    Schematic Diagrams Frame Buffer Partition A/B PAGE3: GPU FRAME BUFFER PARTITION A/B 3/24 FBB 2/24 FBA FBB_DBI[7..0] FBB_D0 FBB_CMD0 FBA_D0 AC51 FBA_CMD0 FBA_DBI[7..0] FBB_DBI[7..0] 14,15 FBB_D0 FBB_CMD0 FBA_D0 FBA_CMD0 FBB_D1 FBB_CMD1 FBA_DBI[7..0] 12,13 FBA_D1 AB48 AA56 FBA_CMD1 FBB_D1 FBB_CMD1 FBA_D1 FBA_CMD1 FBB_EDC[7..0] FBB_D2...

  • Page 57: Frame Buffer A

    Schematic Diagrams Frame Buffer A FRAME BUFFER PARTITION A 31..0 FBA_W CK01 FBA_DBI[3..0] FBVDDQ FBA_W CK01 M10D FBA_W CK01* FBA_DBI[3..0] FBA_W CK01* FBA_W CK23 FBA_EDC[3..0] VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBA_W CK23 FBA_W CK23* FBA_EDC[3..0] FBA_W CK23* FBA_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBA_W CKB01 FBA_CMD[24..0] FBA_W CKB01 FBA_W CKB01*...
  • Page 58 Schematic Diagrams Frame Buffer A FRAME BUFFER PARTITION A 63..32 FBA_W CK45 FBA_DBI[7..4] FBVDDQ FBA_W CK45 FBA_W CK45* FBA_DBI[7..4] FBA_W CK45* FBA_W CK67 FBA_EDC[7..4] VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBA_W CK67 FBA_W CK67* FBA_EDC[7..4] FBA_W CK67* FBA_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBA_W CKB45 FBA_CMD[52..28] FBA_W CKB45 FBA_W CKB45*...

  • Page 59: Frame Buffer B

    Schematic Diagrams Frame Buffer B FRAME BUFFER PARTITION B 31..0 FBB_W CK01 FBB_DBI[3..0] FBVDDQ FBB_W CK01 M12D FBB_W CK01* FBB_DBI[3..0] FBB_W CK01* FBB_W CK23 FBB_EDC[3..0] VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBB_W CK23 FBB_W CK23* FBB_EDC[3..0] FBB_W CK23* FBB_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBB_W CKB01 FBB_CMD[24..0] FBB_W CKB01 FBB_W CKB01*...
  • Page 60 Schematic Diagrams Frame Buffer B FBB_W CK45 FRAME BUFFER PARTITION B 63..32 FBB_DBI[7..4] FBVDDQ FBB_W CK45 M11D FBB_W CK45* FBB_DBI[7..4] FBB_W CK45* FBB_W CK67 FBB_EDC[7..4] FBB_W CK67 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBB_W CK67* FBB_EDC[7..4] FBB_W CK67* FBB_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBB_W CKB45 FBB_CMD[52..28] FBB_W CKB45 FBB_W CKB45*...

  • Page 61: Frame Buffer Partition

    Schematic Diagrams Frame Buffer Partition GPU FRAME BUFFER PARTITION C/D 5/24 FBD 4/24 FBC FBD_D0 FBD_CMD0 FBC_D0 FBC_CMD0 FBC_D0 FBC_CMD0 FBD_D1 FBD_CMD1 FBC_D1 FBC_CMD1 FBC_DBI[7..0] FBC_D1 FBC_CMD1 FBC_DBI[7..0] 17,18 FBC_D2 FBC_CMD2 FBD_D2 FBD_CMD2 FBC_D2 FBC_CMD2 FBC_D3 FBC_CMD3 FBC_EDC[7..0] FBD_D3 FBD_CMD3 FBC_D3 FBC_CMD3 FBC_EDC[7..0]...

  • Page 62: Frame Buffer C

    Schematic Diagrams Frame Buffer C FRAME BUFFER PARTITION C 31..0 FBC_W CK01 FBC_DBI[3..0] FBVDDQ FBC_W CK01 M14D FBC_W CK01* FBC_DBI[3..0] FBC_W CK01* FBC_W CK23 FBC_EDC[3..0] FBC_W CK23 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBC_W CK23* FBC_EDC[3..0] FBC_W CK23* FBC_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBC_W CKB01 FBC_CMD[24..0] FBC_W CKB01 FBC_W CKB01*...
  • Page 63 Schematic Diagrams Frame Buffer C FRAME BUFFER PARTITION C 63..32 FBC_W CK45 FBC_DBI[7..4] FBVDDQ FBC_W CK45 M13D FBC_W CK45* FBC_DBI[7..4] FBC_W CK45* FBC_W CK67 FBC_EDC[7..4] FBC_W CK67 FBC_W CK67* VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBC_EDC[7..4] FBC_W CK67* FBC_CMD[52..28] FBC_W CKB45 FBC_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBC_W CKB45 FBC_W CKB45* M13A...

  • Page 64: Gpu Gnd

    Schematic Diagrams GPU GND GPU GND 11/24 XVDD 16/24 GND_2/5 21/24 GND_3/5 CONFIGURABLE 15/24 GND_1/5 24/24 GND_5/5 23/24 GND_4/5 POWER CHANNELS AR42 AE35 AL13 AR43 NVVDD (NC on substrate) NVVDD AE36 AL14 AR44 BF52 AE37 AL15 BF54 AE38 AL16 AR50 BG12 AA10 AE39...

  • Page 65: Gpu Nvvdd, Fbvddq

    Schematic Diagrams GPU NVVDD, FBVDDQ GPU NVVDD, FBVDDQ NVVDD NVVDD NVVDD NVVDD 17/24 VDD_1/2 NVVDD NVVDD AB14 AF29 18/24 VDD_2/2 22/24 VDDMS FBVDDQ AB15 AF30 AK38 AP39 FBVDDQ AY27 AB13 AB16 AF31 VDDMS VDDMS AK39 AP40 AY28 AB44 AB17 AF32 VDDMS VDDMS AK40...

  • Page 66: Gpu Decoupling - Nvvdd

    Schematic Diagrams GPU Decoupling - NVVDD Under GPU GPU NVVDD DECOUPLING GPU MSVDD DECOUPLING Under GPU NVVDD NVVDD NVVDD C563 C543 C536 C565 C571 C557 C570 C549 C572 C564 NV_0805 NV_0805 NV_0805 Follow common design NVVDD Co-lay NVVDD C386 C418 C487 C417 C461...

  • Page 67: [24] Gpu Decoupling-Fbvddq

    Schematic Diagrams GPU Decoupling - FBVDDQ FBVDDQ_GPU Under GPU Close to GPU FBVDDQ FBVDDQ Partition A 6x 1uF and 2x 10uF C522 C199 C526 C312 C375 C234 C427 C231 C174 C552 C175 C520 C307 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 10u_4V_X6S_06 10u_4V_X6S_06 NV_0402...

  • Page 68: Misc - Gpio, I2C, Rom

    Schematic Diagrams Misc - GPIO, I2C, ROM 1V8_AON MISC: GPIO, I2C, and ROM 1V8_AON NV3V3 R625 VBIOS ROM 14/24 MISC 2 *10K_04 1V8_AON R623 GPIO26_ROM_WP# 2M-Byte(16M-bit) R673 VGA_ROM_CS# STRAP0 ROM_CS 0_04 STRAP0 0_04 R672 R676 (OPTIMUS) STRAP1 STRAP1 R626 D02,MODS currnet abnormal VGA_ROM_SI *10K_04 *10K_04...

  • Page 69: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface IFP I/O INTERFACE 7/24 IFPAB DL-DVI DVI/HDMI BT10 8/24 IFPC IFPA_AUX BT11 HDMI IFPA_AUX R618 1K_1%_04 BH20 IFPCD_RSET DVI/HDMI BR20 IFPA_L3 40 mil Under GPU R142 1K_1%_04 BH23 BP20 IFPAB_RSET IFPA_L3 IF_PLLVDD BH19 BM10 IFPCD_PLLVDD IFPC_AUX GPU_PLLVDD HDMI_CTRLDATA...

  • Page 70: Straps And Xtal

    Schematic Diagrams Straps and XTAL Near GPU XTAL GPU_PLLVDD Under GPU 13/24 XTAL/PLL 40mil HCB1608KF-300T60 GPU_PLLVDD BG22 SP_PLLVDD 1V8_AON 20mil 30ohm ESR 10mohm bead BG25 VID_PLLVDD C423 C550 C415 1u_6.3V_X6S_04 22u_6.3V_X6S_08 4.7u_6.3V_X6S_06 C430 NV_0402 M-C0805 NV_0603 1u_6.3V_X6S_04 NV_0402 follow common design add 40mil GPCADC_AVDD C540...

  • Page 71: Nvidia Power Sequence

    Schematic Diagrams NVIDIA Power Sequence DEFAULT HW POWER SEQUENCE 3.3VA > 1.8VA > 3.3V 3.3VA FBVDDQ_EN NV_FBVDDQ_EN NV_EN_DOW N VIN_DOWN PEX_VDD_EN NV_PEXVDD_EN 22,65 C730 *0.1u_10V_X7R_04 From EC 12/16 mail OVERT# OVERT# NVVDDS_EN OVERT#_EC Follow common design R390 *200K_04 52,58,63,66 EC_GPIO 1V8_AON_PW RGD SUSB# NVVDD_EN...

  • Page 72: Ovr-M

    Schematic Diagrams OVR-M Output power MEASUREMENT VDD3 3.3VS R193 R225 *0_04 0_04 U812_VCC C602 1u_6.3V_X6S_04 PW R_SRC_NV_VINP_R R197 0_04 PFM_CH1_BS_IN1 U812_VCC BS_IN1 NVVDD PW R_SRC_NV C608 *1000p_50V_X7R_04 R208 *750_04 NV_0402 FBVDDQ PW R_SRC_VINP_R R234 0_04 PFM_CH1_BS_IN2 PFM_CH1_SH_IN_P1_C R198 0_04 PWR_SRC_NV_VINP_R BS_IN2 SH_P1 PW R_SRC_NV...

  • Page 73: Mdp

    Schematic Diagrams Footprint M-SOT23-5 M-SOT23-5A 6/14 Tim NV_MDP_PW R For Safety LPS. 3.3V 1.5A 1.5A VOUT SY6288DAAC C823 C829 *10u_6.3V_X5R_06 10u_6.3V_X5R_06 Layout Swap SY6288D20AAC ESD73034D PCB Footprint = M-SOT23-5 NV_MDP_PW R 50,54 SUSB GND1 I_MDP_D#2 I_MDP_D#2J COMMON I_MDP_D2 I_MDP_D2J GND2 Close to Display PORT I_MDP_D#3 I_MDP_D#3J...

  • Page 74: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL POWER DEFAULT PANEL CONNECTOR SHORT VLED EMC32 EMC33 OPEN_2A LED PANEL (EDP Channel). PLVDD J_LCD1 *MTP3403N3 C168 C104 D02A 1u_6.3V_X5R_02 EMC1 C115 1000p_50V_X7R_04 3.3V C911 0.1u_10V_X5R_04 *0.22u_25V_X7R_06 EDP_TXN_0 C910 0.1u_10V_X5R_04 *4.7K_06 EDP_TXP_0 C908 0.1u_10V_X5R_04 GND5 *150K_04 EDP_TXN_1 GND5...

  • Page 75: Hdmi

    Schematic Diagrams HDMI TMDS_CLOCK#_R EMR2 6.04_1%_04 TMDS_CLOCK#J TMDS_CLOCK_R EMR1 6.04_1%_04 TMDS_CLOCKJ HDMI TMDS_DATA0#_R TMDS_DATA0#J EMR9 HDMI 6.04_1%_04 TMDS_DATA0_R EMR11 6.04_1%_04 TMDS_DATA0J HDMI CONNECTOR HDMI HDMI ESD73034D HDMI HDMI_5VS TMDS_DATA1#_R TMDS_DATA1#J EMR10 6.04_1%_04 J_HDMI1 TMDS_DATA1_R TMDS_DATA1J EMR8 6.04_1%_04 VOUT HDMI C825 C828 C824 TMDS_DATA2#_R...

  • Page 76: Pch 1/8

    Schematic Diagrams PCH 1/8 U46F 6 OF 9 38.4Mhz XTAL38.4_OUT USB3_TXP4 XTAL_OUT USB31_4_TXP Use a shielded crystal GND XTAL38.4_IN USB3_TXN4 and isolation external GND XTAL_IN USB31_4_TXN 4-USB3.2_Gen2 Port 4 TYPE-C_2 USB31_4_RXP USB3_RXP4 R699 60.4_1%_04 XCLK_BIASREF USB31_4_RXN USB3_RXN4 XTAL38.4_OUT 10p_50V_NPO_04 C979 CLOSE TO PCH AC17 USB3_TXP3...

  • Page 77: Pch 2/8

    PCIE11_RXN/SATA0A_RXN PCIE_RXN11_SSD R707 12.1_1%_04 PCH_PECI PCIE10_TXP C1022 0.22u_10V_X5R_04 4,52 H_PECI PCIe 9~12 PECI PCIE10_TXP PCIE_TXP10_SSD PCIE10_TXN C1021 0.22u_10V_X5R_04 PCIE_TXN10_SSD PCIE10_TXN CLEVO PCIE_RXP10_SSD RSVD_10 PCIE10_RXP PCIE_RXN10_SSD RSVD_11 PCIE10_RXN PCIE9_TXP C1020 0.22u_10V_X5R_04 PCIE24_TXP PCIE9_TXP PCIE_TXP9_SSD PCIE9_TXN C1019 0.22u_10V_X5R_04 R372 1K_04 PCIE24_TXN PCIE9_TXN...
  • Page 78 Schematic Diagrams PCH 3/8 PCH DMIC C679 *27p_50V_NPO_04 U46C 3 OF 9 R323 *33_04 PCH DMIC AU21 AY12 DMIC_DATA0 GPP_H23_SSD1_RST# GPP_S7/SNDW4_DATA/DMIC_DATA0 GPP_H23/TIME_SYNC0 R317 *33_04 PCH DMIC AW21 BD10 DMIC_CLK0 GPP_S6/SNDW4_CLK/DMIC_CLKA0 GPP_H22/ISH_I2C1_SCL AY20 BE10 GPP_S5/SNDW3_DATA/DMIC_DATA1 GPP_H21/ISH_I2C1_SDA BB20 GPP_S4/SNDW3_CLK/DMIC_CLKA1 GPP_H20/ISH_I2C0_SCL BC20 GPP_S3/SNDW2_DATA/DMIC_CLKB1 GPP_H19/ISH_I2C0_SDA GPP_H18 BD19...
  • Page 79 Schematic Diagrams PCH 4/8 U46D 4 OF 9 AU29 AW46 GPU_EVENT# GPP_D23/UART3_CTS#/THC1_SPI2_INT# GPP_A14/IMGCLKOUT0 AY30 AV46 GPP_D22/UART3_RTS#/THC1_SPI2_RST# GPP_A13/ESPI_ALERT3# AW29 AV47 GPP_D21/UART3_TXD/THC1_SPI2_IO3 GPP_A12/ESPI_ALERT2# BD30 AU45 GPP_D20/UART3_RXD/THC1_SPI2_IO2 GPP_A11/ESPI_ALERT1# BD35 AU46 SERIRQ_ESPI_ALERT0 GPP_D19/GSPI3_MOSI/THC1_SPI2_IO1 GPP_A10/ESPI_ALERT0# BD34 AU47 GPP_D18/GSPI3_MISO/THC1_SPI2_IO0 GPP_A9/ESPI_CS3# BC34 AT48 GPP_D17/GSPI3_CLK/THC1_SPI2_CLK GPP_A8/ESPI_CS2# BE35 AT46 GPP_D16/GSPI3_CS0#/THC1_SPI2_CS# GPP_A7/ESPI_CS1# SML1_DATA...
  • Page 80 Schematic Diagrams PCH 5/8 U46A 1 OF 9 CPU_C10_WAKE C10_WAKE CLKOUT_PCIE_P15 CLKOUT_PCIE_N15 PCH_CPU_BCLK_R_DP CLKOUT_CPUBCLK_P PCH_CPU_BCLK_R_DN CLKOUT_CPUBCLK_N CLKOUT_PCIE_P14 CLKOUT_PCIE_N14 CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P CPU_24MHZ_R_DN CLKOUT_CPUNSSC_N CLKOUT_PCIE_P13 CLKOUT_PCIE_N13 PCH_CPU_PCIBCLK_R_DP CLKOUT_CPUPCIBCLK_P PCH_CPU_PCIBCLK_R_DN CLKOUT_CPUPCIBCLK_N CLKOUT_PCIE_P12 CLKOUT_PCIE_N12 CLKOUT_CPURTC CLKOUT_CPURTC CLKOUT_PCIE_P11 CLKOUT_CPUBCLK2_P AC11 CLKOUT_CPUBCLK2_P CLKOUT_PCIE_N11 CLKOUT_CPUBCLK2_N AC12 CLKOUT_CPUBCLK2_N CLKOUT_PCIE_P10 CLK_PCIE_CARD AU16...
  • Page 81 Schematic Diagrams PCH 6/8 4,40 VCCST_OVERRIDE U46G 7 OF 9 3.3VA R708 0_04 VCCLDOSTD_OUT_0P85 VCCST_OVERRIDE VCCLDOSTD_0P85_1 VCCLDOSTD_0P85_2 VCCPRIM_3P3_1 VCCLDOSTD_0P85_3 VCC_RTC BF46 AA38 VCCRTC_1 VCCIN_AUX_1 0.01A BG46 AC38 VCCRTC_2 VCCIN_AUX_2 BG47 AC39 VCCRTC_3 VCCIN_AUX_3 AC41 VCCIN_AUX_4 VCCPRIM_1P05_OUT VCCPRIM_1P05 AK22 AC42 VCCPRIM1P05_OUT_PCH_1 VCCIN_AUX_5 AC44 VCCIN_AUX_6...

  • Page 82: Pch 7/8

    Schematic Diagrams PCH 7/8 U46H U46I 8 OF 9 9 OF 9 AJ23 AW25 *C98D98N *C98D98N *C111D111N *C111D111N *C111D111N *C111D111N VSS_163 VSS_240 VSS_1 VSS_78 AJ25 AW39 VSS_164 VSS_241 VSS_2 VSS_79 AJ27 AY25 VSS_165 VSS_242 VSS_3 VSS_80 AJ28 AY43 VSS_166 VSS_243 VSS_4 VSS_81 AK12...

  • Page 83: Pch 8/8

    Schematic Diagrams PCH 8/8 3.3VA 3.3VA R677 R678 100K_1%_04 100K_1%_04 VCCST_OVERRIDE LEVEL SHIFT 3.3_VCCST_OVERRIDE 3.3VS VDD3 R474 *0_04 VDD3 C788 *0.1u_10V_X7R_04 2SK3018S3 U27B U27A 74LVC08APW TO VR_ON & EC R682 1K_04 74LVC08APW 4,38 VCCST_OVERRIDE RSMRST# ALL_SYS_PW RGD_R ALL_SYS_PW RGD PQ19 SUSB# R473 0_04...

  • Page 84: Retimer 1/2

    Schematic Diagrams Retimer 1/2 +VCC3P3_LC_TCP0 +VCC0V9_SVR_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SVR_TCP0 U36D +VCC3V3_SVR_TCP0 INS66041717 U36C +VCC3P3A_SVR_TCP0 SVR_VSS_2 VCC3P3_SX INS66041384 C111 C100 SVR_VSS_1 +VCC3P3_ANA_TCP0 2.2u_6.3V_X5R_04 VCC3P3_ANA VCC3P3_SVR 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 VCC3P3_LC VCC3P3_SVR VSS_ANA VSS_ANA +VCC0P9_SVR_TCP0_PHASE SVR_IND_2 VCC3P3A VSS_ANA VSS_ANA SVR_IND_1 VSS_ANA VSS_ANA VCC0P9_SVR_ANA_1 VSS_ANA VSS_ANA 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04...
  • Page 85 Schematic Diagrams Retimer 2/2 U36B U36A INS66042699 INS66043311 TBT_EE_CLK EE_CLK I2C_SDA RETIMER_I2C_SDA ALL THESE CAPS ARE STUFFED TBT_EE_CS_N EE_CS_N I2C_SCL RETIMER_I2C_SCL C878 0.22u_10V_X5R_02 TCP0_TX0_C_DP TBTA_TXRX1_P_R TBT_EE_DI TCP0_TX0_DP ASSRXP1 BSSRXP1 EE_DI I2C_INT RETIMER_I2C_INT C879 0.22u_10V_X5R_02 TCP0_TX0_C_DN TBTA_TXRX1_N_R TBT_EE_DO TC_RETIMER_FORCE_PW R TCP0_TX0_DN ASSRXN1 BSSRXN1 EE_DO...

  • Page 86: Pd65993, Type-C

    Schematic Diagrams PD65993, Type-C VCC3V3_PD TBTA_VBUS *0_04 VBUS Source 5V,3A TBT_PA_VBUS HCB2012KF-800T80 80Ohm, 0.01Ohm DCR, 8A Idc W NMD2165 main:6-21-B4K20-024 second: 6-21-B4K60-024 ACE_I2C_SDA2 R543 SMD_VGA_THERM 25,52 10K_04 J_TYPEC2 TBT_TPS65993 1u_25V_X5R_06 TBTA_TX_1_P TBTA_TXRX_1_P TBT_RESET_N LDO_3V3 TX0_P RX0_P GPIO0_TBT_RESET_N TBTA_TX_1_N TBTA_TXRX_1_N TX0_N RX0_N 1u_25V_X5R_06 1u_25V_X5R_06...

  • Page 87: Audio Codec

    Schematic Diagrams Audio Codec AUDIO CODEC ALC256 HEADPHONE_R HEADPHONE_L LINE1-VREFO-L LINE1-VREFO-R MIC2_VREFO AUDG C705 10u_6.3V_X5R_06 AUDG 3802K-Q02N-09L R794 CODEC 100K_04 SPKOUTR+ SPKOUTR+_R ANALOG DIGITAL 5VS_AUD CODEC HCB1005KF-121T20 HCB1608KF-800T30 C794 Place next to pin 26 J_SPKR1 C790 180p_50V_NPO_04 CODEC CODEC *1u_6.3V_X5R_02 CODEC C1035 C1041...

  • Page 88: M.2 Wlan+Bt, Pcie 4X Ssd

    Schematic Diagrams M.2 WLAN+BT, PCIE 4X SSD WLAN+BT WLAN HOLD 6-34-P750S-010 J_WLAN1 40 mil WLAN_3.3V GND13 3.3V3 CNVI_WT_CLKP WT_CLKP 3.3V2 WLAN WLAN C706 C718 CNVI_WT_CLKN WT_CLKN PEWAKE1_N WLAN GND12 CLKREQ1_N WLAN 22u_6.3V_X5R_06 0.1u_6.3V_X5R_02 CNVI_WT_D0P WT_D0P PERST1_N WLAN WLAN WLAN CNVI_WT_D0N WT_D0N REFCLK0 BOM need...
  • Page 89 Schematic Diagrams M.2 PCIE 4X SSD NGFF_M (M2) SSD (GEN4 PCIE 4X) 3.3VS >120 mil M2_SSD2_3.3VS ONLY GEN4 PCIe J_SSD2 H: PCIe R803 C770 C769 C764 GND13 *100K_04 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 GND12 3.3V8 22u_6.3V_X5R_06 M.2 SSD M.2 SSD M.2 SSD GND11 3.3V7 M.2 SSD PEDET(NC-PCIe/GND-SATA)

  • Page 90: Type-C & A

    Schematic Diagrams Type-C & A J_TYPEC1 UCF3T-21S01-0P11 USBVCC3.1_1 A_UTXP_SW2_J USB3_RXP4_J 100 MIL A_UTXN_SW2_J TX0_P RX0_P USB3_RXN4_J C1011 6-02-75495-9C0 USB3.1 PORT(PORT1) W/O USB CHARGER TX0_N RX0_N 10u_6.3V_X5R_06 C1013 VDD5 USBVCC_CH USBVCC3.1_1 USBVCC3.1_1 VBUS VBUS 3.3V TYPE-C 80 mil TYPEC_CC1 0.1u_10V_X5R_04 80 mil SBU2 TYPE-C TYPE-C...

  • Page 91: Lan Rtl8111H

    Schematic Diagrams LAN RTL8111H LAN (RTL8111H LDO MODE ONLY) PCH GPI0 4/20/2018 R344 2.49K_1%_04 GPIO_RTD3 AVDD33 Rising time 3.3V_AUX (10%~90%) LAN_LED0 T111 >0.5mS and <100mS. LAN_LED1/GPO T110 LAN_LED2 T112 FOR AC S5 WAKE UP ON LAN GPIO_LAN_PLT_RST# R772 10K_04 LAN_AVDD33 E_PAD (W>60mil PCIE_WAKE#...

  • Page 92: Card Reader

    Schematic Diagrams Card Reader MULTI I/O BOARD RTS5227S/ OZ711LV2 NOTE2: SP7 : Internal pull-down 200K RTD3 confirm If use microSD socket, 1.IF RTD3-COLD IS NEEDED TO BE SUPPORTED, WAKE# MUST BE SD_WP#(#29) can't floating, PULLED-UP TO +3.3V_AUX ON THE MB. DURING D3 COLD, WAKE# must connect to CND WILL BE ASSERTED AT THE EVENT OF SD CARD INSERTION OR REMOVAL.

  • Page 93: Hdd, Click Tp, Audio

    Schematic Diagrams HDD, Click TP, Audio FOR SUPPORT OPTANE project, SATA HDD POWER GATEING HDD CONNECT1 (MASTER) NP5xx/NP6xx not support Angus 0415 J_HDD1 Gen3 JHDD_SATA_TXP3 C1054 0.01u_16V_X7R_04 SATA_TXP3 34 JHDD_SATA_TXN3 C1055 0.01u_16V_X7R_04 DEFAULT SATA_TXN3 34 SHORT SATA_5VS JHDD_SATA_RXN3 C1056 0.01u_16V_X7R_04 SATA_RXN3 JHDD_SATA_RXP3 C1057...

  • Page 94: Led, Ccd, Tpm, Power Sw Bd

    Schematic Diagrams LED, CCD, TPM, Power SW Bd. VDD_TPM R464 *0_04 3.3VA R463 0_04 VDD3 R898 R461 *4.7K_04 4.7K_04 TPM_GPIO GPIO0 R458 4.7K_04 TPM_PP VDD_TPM C768 C789 DEL R713 C781 C773 40,42,45,46,48,49 BUF_PLT_RST# RST# VSS_3 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 TPM_PIRQ# PIRQ# NC_1 NC_2...

  • Page 95: Kbc-Ite It5570

    Schematic Diagrams KBC-ITE IT5570 EC ROM Debug Port ALSPI_* = 1.5"~5.8" C989 VDD3 IT5570 *0.1u_6.3V_X5R_02 1Mbit OPTION ( VDD3 DEBUG PORT PCB Footprint = 85204-04L ALSPI_MSI_L R761 33_04 KBC_AVDD *3801K-Q04N-06L ALSPI_MSO_L HCB1005KF-121T20 R799 33_04 R800 3IN1 3.3K_1%_04 VDD3 45,52 3IN1 IT5570 80CLK ALSPI_CE#_L...

  • Page 96: Rgb Kb

    Schematic Diagrams RGB KB RGB KB Only LCD 17" VDD3 RGBKB_PWR J_KBLED1 R285 *100K_04 KB-LED-RGB KB-LED-RGB LED_KB_PIN4 1K_04 R393 0_06 R283 100_04 RGBKBSW_R KBZONE_R RGBKB-DET#_R RGBKB-DET# KBZONE_B R284 KB-LED-RGB KBZONE_R KB-LED-RGB KBZONE_G SM3422KTDSH EC_PWM_LEDKB_R FP225H-008S11M KB-LED-RGB fp225h-008gxxxm_r P/N = 6-20-94K30-108 R394 0_06 RGBKBSW_G KBZONE_G...

  • Page 97: 5V, 5Vs, 3.3V, 3.3Vs

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS VREG3 VDD3 DD_ON# VDD3 SUSB VREG3 R784 PR116 PR115 VREG3 10K_04 47K_04 DD_ON 100K_04 EMC28 EMC26 EMC25 EMC27 POWER_SWITCH R679 SUSB# DD_ON# SUSB PW R_SW # SUSB 30,50 R698 200K_04 POWER_SWITCH PC85 47K_04 POWER_SWITCH Q63A 2SK3018S3 PC84...

  • Page 98: Vccst, Vccstg, Vccsfr

    Schematic Diagrams VCCST, VCCSTG, VCCSFR 1.8VA_C10 NOTE: 1.05DX_VCCSTG Ton need <65us DEFAULT 40mil VCCSTG SHORT 1.8VA 1.8VA_C10 PJ12 *1mm VCCSFR_OC C738 C734 VCCSTG PJ25 1u_6.3V_X5R_02 VCCSTG 0.1u_6.3V_X5R_02 VCCSFR_OC NOTE: tCPU04: VCCST > VCCSTG VCCSFR_OC VCC1P05_OUT_FET tD-ON VOUT VOUT 1.05DXVCCSTG VDD3 VOUT VBIAS C912...

  • Page 99: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 Angus 0204 Angus 0204 PR111 PR112 20K_1%_04 18K_1%_04 EN_3V EN_5V PJ20 *CV-40mil PC87 1000p_50V_X7R_04 2.5A 2.5A VREG3 PC270 PC273 PC276 PC280 PC279 PC283 PC284 PC285 VDD3 PC72 1u_6.3V_X5R_04 VREG3 PGOOD PC77 PC76 VDD5 PR118 0_06 PR119 0_06 VBST2 VBST1...

  • Page 100: Ddr 1.2V / 0.6Vs, 2.5V

    Schematic Diagrams DDR 1.2V / 0.6VS, 2.5V DDR4 1.2V 1.2V/0.6VS POW ER VDDQ PC193 PC194 SS14W S G5616BRZ1U POW ER VDDQ Angus 0225 VDDQ_R PC192 POW ER VDDQ VTT_MEM(0.6V) Change POW ER VDDQ PC25 PC24 footprint VLDOIN VBST EMR3 10u_6.3V_X5R_06 0.1u_25V_X7R_06 POW ER VDDQ VDDQ_R...

  • Page 101: Vccin

    Schematic Diagrams VCCIN PR205 0_04 VCCIN_TEMP VDD3 PR206 PC107 49.9K_1%_04 1u_16V_X7R_06 PR182 4.7_1%_06 12/23 PR25 0_04 PSYS VCCIN_EN PR211 10K_04 PJ24 *CV-40mil 3.3V *0.01u_50V_X7R_04 PC112 *0.1u_16V_X7R_04 4.7u_6.3V_X6S_06 DEFAULT SHORT PR135 4,31,40,52 ALL_SYS_PWRGD PR24 4.02K_1%_04 2M_1%_04 DEFAULT SHORT VDD3 Angus 0415 Psys setting base on charger spec: 12/23 1.

  • Page 102: Vccin Output

    Schematic Diagrams VCCIN Output VCORE OUTPUT STAGE 5.5A phase 1 3.3V close to ic PC164 PC142 PC132 EMC12 MP86941GQVT-Z 0.01u_50V_X7R_04 VIN1 PC153 VIN2 1u_6.3V_X6S_04 BST_PWM1 AGND VCCIN E-CAP PR223 0_04 PC160 VCCIN_PWM1 105A 1u_25V_X7R_06 SW_PWM1 PR228 0_04 58,59 VCCIN_TEMP VTEP/FLT 100u_25V CMME063T-R15MS0R907 58,59...

  • Page 103: Vnn / V1.05A

    Schematic Diagrams VNN / V1.05A footprint change to qfn13_2*3mm PR301 V1.05A BYPASS RAIL *3.3_06 PR302 *0_04 1.05V_EN PR304 *0_04 PART NUMBER !LPM VOUT (V) PC264 V1.05A_EXT_OUT VCC_V1P05EXT_1P05 *0.22u_10V_X5R_04 0(LPM) 500mA PU24 1.05V PL20 PC61 PC59 PC58 1.05V PJ10 1.05V *2mm *EM-10AM23V07 0.96V PC271...

  • Page 104: Vccin Aux

    Schematic Diagrams VCCIN AUX 3.3VA VCCIN_AUX_VID0 PR150 *100K_04 PR149 100K_04 VCCIN_AUX_VID1 PR147 *100K_04 PR148 100K_04 VCCIN_AUX PR168 PC109 200_1%_04 330p_50V_NPO_04 Die sense or Remote sense PR13 PR163 100_04 10K_1%_04 *20mil short-p VCCIN_AUX_SENSE 5,38 PC94 PR174 *20mil short-p 330p_50V_NPO_04 VSSIN_AUX_SENSE 5,38 PR171 PR179 14.3K_1%_04...

  • Page 105: Charger

    Schematic Diagrams Charger 12/3 J_DC_JACK1 2DC3003-016211F EML1 HCB2012KF-800T80 PQ20 MTB1D5N03H8 EML2 HCB2012KF-800T80 MDU1517 ULTRASO-8 MDU1517 AC Detect 17.2V ULTRASO-8 ULTRASO-8 PRS2 WMCSL0612R005FETA P/N = 6-20-B3J00-003 DC_19V PCB Footprint = 2dc3003-016211f POWER CHARGE PC241 PC255 PC248 PC249 PC242 PC257 PC256 PD11 PC11 PC10 PR17...

  • Page 106: [63] Nvvdd1

    Schematic Diagrams NVVDD1 EC_GPIO 28,52,58,66 EN Type VDD3 1V8_AON NV3V3 1N914BWS Open Drain R11(PTC) close to hot area you concern Push Pull PR277 PR278 PR79 DEL SMBUS, I2C *10K_1%_04 10K_1%_04 *10K_1%_04 D02, del duplicate PH 1V8_AON PR274 0_04 25,28,66 I2CC_SDA_PP PNTC1 Mode EW TF02-104F4F-N...

  • Page 107: Nvvdd2

    Schematic Diagrams NVVDD2 PWR_SRC_NV NVVDD VBoot=0.75V EMC24 EMC20 PC261 PC262 PC277 PC254 PC246 0.01u_50V_X7R_04 0.01u_50V_X7R_04 PC226 1u_25V_X7R_06 M-C0603 PWR_SRC_NV co-lay 3.3V PU21 PC227 1u_25V_X7R_06 NVVDD_DRMOS_VCC PR82 0_06 NVVDD PC250 PC243 noise solution PC218 1u_25V_X7R_06 PC236 PL17 M-C0603 PR85 HPRM-1074-R22-M co-lay 2K_04 1u_6.3V_X6S_04 PU17...

  • Page 108: Pex_Vdd

    Schematic Diagrams PEX_VDD PW R_SRC_NV_FB PEX_VDD PR130 AOZ2261NQI-11 0_06 PEXVDD 3.3V PC119 PC122 PC126 PC90 4.7u_6.3V_X5R_04 PR139 PEXVDD PR191 100K_1%_04 *10K_1%_04 PEXVDD PEXVDD PR142 0_06 PC102 0.1u_16V_X7R_04 PEXVDD PEXVDD PEX_VDD_PWRGD PGOOD PEXVDD PR176 *10K_1%_04 PEXVDD PEXVDD PFM* PEX_VDD PR172 Sheet 63 of 69 10K_1%_04 PEXVDD EM-10AM23V07...

  • Page 109: Fbvddq

    Schematic Diagrams FBVDDQ FBVDDQ EC_GPIO 28,52,58,63 3.3VS to VDD3 1N914BWS 1V8_AON NV3V3 VDD3 VDD3 EN Type R11(PTC) close to hot area you concern Open Drain PR18 PR12 Push Pull PR22 1V8_AON *10K_04 *10K_04 *10K_1%_04 *10K_1%_04 PR200 PR19 Mode DEL I2C 10K_1%_04 *10K_04 FBVDDQ=1.25V/1.35V...

  • Page 110: 1V8_Aon, Nv3V3, 3.3Va

    Schematic Diagrams 1V8_AON, NV3V3, 3.3VA Angus 0204 1.8VA 1.8VA C803 C804 VDD3 1V8_AON 1V8_AON 1V8_AON 1V8_AON FA7601 10u_6.3V_X5R_06 0.1u_6.3V_X5R_02 1V8_AON 1V8_AON 1V8_AON 1.8VS R889 R888 EMC34 EMC35 100K_04 10_06 1V8_AON OUT1 OUT2 1.8VS 1V8_AON 1V8_AON 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 OUT1 OUT2 C802 C801 C797 0.1u_6.3V_X5R_02...

  • Page 111: Audio Board + Redriver

    Schematic Diagrams Audio Board + Redriver USB2.0 CON AC25 22u_6.3V_X5R_06 AGND USB3.0 CON 6-71-NP5H8-D02 60 mil AUDIO BOARD AC24 0.1u_6.3V_X5R_02 A_USBVCC1 AGND AUDIO BOARD AC20 22u_6.3V_X5R_06 AUDIO BOARD AGND 1AR1 *0_02 4AR1 *0_02 AC26 22u_6.3V_X5R_06 60 mil AUDIO BOARD AGND AC22 22u_6.3V_X5R_06 A_USBVCC_CH...

  • Page 112: Led Board

    Schematic Diagrams LED Board 1LR1 *0_02 4LR1 *0_02 6-71-NP5H4-D01 2LR1 *0_02 5LR1 *0_02 3LR1 *0_02 6LR1 *0_02 7LR1 *0_02 8LR1 *0_02 LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD 6-52-55001-021 Angus 0302 GREEN YELLOW HDD LED 750_1%_04...

  • Page 113: Power Sw Board

    Schematic Diagrams Power SW Board 1BR1 *0_02 4BR1 *0_02 6-71-NP5HS-D01 2BR1 *0_02 5BR1 *0_02 POWER SW BOARD 3BR1 *0_02 6BR1 *0_02 7BR1 *0_02 8BR1 *0_02 POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD Sheet 68 of 69 Power SW Board POWER...

  • Page 114: Power Sequence

    Schematic Diagrams Power Sequence NP50HP POWER ON SEQUENCE EVT M/B(BIOS P1, EC P1C) VDD3 AC IN DSW_PWROK 77.29ms (to VDD3) SLP_SUS# 95.95ms (to DSW_PWROK) M_BTN# VA_EC_EN 381.39ms (to M_BTN#) DD_ON 10.25ms (to VA_EC_EN) RSMRST# 143.26ms (to VA_EC_EN) PWR_BTN# 0ms (to RSMRST#)
