Introduction

Specifications


Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.

CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
1 - 2 Specifications
Processor Options
Intel® Core™ i7 Processor
i7-1165G7 (2.70GHz)
12MB Smart Cache, 14nm, DDR4-3200MHz, TDP 28W
Intel® Core™ i5 Processor
i5-1135G7 (2.30GHz)
8MB Smart Cache, 14nm, DDR4-3200MHz, TDP 28W
Intel® Core™ i3 Processor
i3-1115G4 (2.70GHz)
6MB Smart Cache, 14nm, DDR4-3200MHz, TDP 28W
BIOS
128Mb SPI Flash ROM
Insyde BIOS
Memory
Dual Channel DDR4
On Board DDR4 8GB
One 260 Pin SO-DIMM Socket Supporting DDR4 3200MHz
Memory
Memory Expandable up to 32GB
Compatible with 8GB, 16GB or 32GB Modules
(The real memory operating frequency depends on the FSB
of the processor.)
LCD Options
14" (35.56cm), 16:9, F HD (1920x1080)
Storage
One M.2 SATA/PCIe Gen3 x4 Solid State Drive (SSD)
(Factory Option) One M.2 SATA Solid State Drive (SSD)
Video Adapter
Intel UHD Graphics 630
HDR Support
Rec. 2020
Microsoft DirectX® 12 Compatible
Pointing Device
Built-in Touchpad (with Microsoft PTP Multi Gesture & Scroll-
ing Functionality)
Keyboard
White-LED Keyboard
Or
(Factory Option) Keyboard
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Array Microphone
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel PTT for Systems Without TPM Hardware
(Factory Option) TPM 2.0
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for PCIe Gen4 x4 SSD
(Factory Option) Slot 3 for SATA or PCIe Gen3 x4 SSD or
4G-Module
Card Reader
MicroSD Card Reader
