REFRIGERATION
HIPRO
A30, A40, C40, C60, N30, N40
Minibar
EN
Operating manual.....................................................3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIPRO A30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic HIPRO A30

Summary of Contents for Dometic HIPRO A30

  • Page 1 REFRIGERATION HIPRO A30, A40, C40, C60, N30, N40 Minibar Operating manual.............3...
  • Page 2 Copyright © 2024 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or pending patent. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved.

  • Page 3: Table Of Contents

    This product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com.

  • Page 4: Safety Instructions

    3 Safety instructions General safety WARNING! Electrocution hazard Ensure that the minibar has been installed by a qualified technician in accordance with the Dometic installation manual. Do not operate the minibar if it is visibly damaged. If this minibar's power cable is damaged, it must be replaced by the manufacturer, a service agent or a similarly qualified person in order to prevent safety hazards.
  • Page 5 Dometic HiPro Alpha, Evolution   EN This device is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the device by a person responsible for their safety.

  • Page 6: Accessories

    • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. 6 Technical description The minibars are available with different cooling techniques: •...
  • Page 7 Dometic HiPro Alpha, Evolution   EN • Thermoelectric cooling: N30S1, N30S2, N30P1, N30P2, N30G1, N30G2, N40S1, N40S2, N40P1, N40P2, N40G1, N40G2 All materials used are compatible for use with foodstuffs. The refrigerant circuit is maintenance-free. The minibar has depending on the version one or two shelves and one or two door racks. There is a door rack intended for bottles.
  • Page 8 EN   Dometic HiPro Alpha, Evolution Operating elements of the minibar ...
  • Page 9 Dometic HiPro Alpha, Evolution   EN Explanation No. in Fig.  on page 8 Interior light and control element 1 Shelf 2 Shelves (A40S2, A40P2, A40G2, C40S2, C40P2, C40G2, C60S2, C60G2, N40S2, N40P2, N40G2) Upper door rack (for A40S1, A40S2, A40P1, A40P2, C40S1, C40S2, C40P1, C40P2, C60S1,...

  • Page 10: Operation

    EN   Dometic HiPro Alpha, Evolution Color Status Description Flashing An error occurred (see chapter Troubleshooting page 14) – Off Minibar is switched off or in silent mode 7 Operation Before first use NOTE Do not store goods in the device for the first 4 hours aer start-up.
  • Page 11 Dometic HiPro Alpha, Evolution   EN Positioning the door rack To position the door rack proceed as shown in Fig.  on page 11.  Switching on the minibar NOTE Aer switching on, the minibar needs several hours to reach the set cooling temperature.
  • Page 12 EN   Dometic HiPro Alpha, Evolution To set the temperature proceed as shown in Fig.  on page 12.  4 °C/39 °F 12 °C/54 °F 7 °C/45 °F Switching off the minibar To switch off the minibar proceed as shown in Fig.  on page 12.

  • Page 13: Cleaning

    Dometic HiPro Alpha, Evolution   EN  Defrosting The minibar is equipped with an auto-defrost function. Storing If the minibar is not to be used for a longer period of time, proceed as follows: 1. Pull the power plug out of the socket.

  • Page 14: Troubleshooting

    EN   Dometic HiPro Alpha, Evolution Check the condensate drain regularly. Clean the condensate drain when necessary. If it is blocked, the condensate collects on the bottom of the minibar. For absorber versions: Use a brush or so cloth annually to remove dust from the absorber unit.
  • Page 15 Dometic HiPro Alpha, Evolution   EN Problem Possible cause Suggested remedy Note: After a longer period of time without troubleshooting, the LED changes back to the interval of flashing 5x. Minibar is not cooling. Interior light is For versions with absorber cool- Check the cooling unit for leaks.

  • Page 16: Disposal

    EN   Dometic HiPro Alpha, Evolution 10 Disposal WARNING! Fire hazard The refrigerant is highly flammable. Do not open or damage the refrigerant circuit. The insulation of the device contains an insulating gas (see data plate). Do not damage the insulation. Recycling packaging material: Place the packaging material in the appropriate recycling waste bins wherever possible.
  • Page 17 Dometic HiPro Alpha, Evolution   EN HiPro HiPro C 40S1, C 40S2, C 40P1, C60S1, C60S2, C60G1, C60G2 C 40P2, C 40G1, C 40G2 Rated input power 45 W Noise emission 33 dB(A) 38 dB(A) Refrigerant R600a Weight: Test/ certificates HiPro HiPro...

This manual is also suitable for:

Hipro a40Hipro c40Hipro c60Hipro n30Hipro n40Hipro alpha a30s1 ... Show all
