- Page 1 Installation Guide...
- Page 2 Information, specifications, diagrams, images, and instructions herein are subject to change without notice. Obsidian Control Systems logo and identifying product names and numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
- Page 3 Energy Saving Matters (EuP 2009/125/EC) Saving electric energy is a key to help protecting the environment. Please turn off all electrical products when they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power when not in use.
-
Page 4: Table Of Contents
C O N T E N T S GENERAL INFORMATION LIMITED WARRANTY SAFETY GUIDELINES OVERVIEW INSTALLATION INSTRUCTIONS MAINTENANCE SPECIFICATIONS DIMENSIONS... -
Page 5: General Information
G E N E R A L I N F O R M AT I O N INTRODUCTION Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device. These instructions contain important safety and use information. UNPACKING Every device has been thoroughly tested and has been shipped in perfect operating condition. - Page 6 CUSTOMER SUPPORT Contact your local Obsidian Controls Systems dealer or distributor for any product related service and support needs. Also visit forum.obsidiancontrol. with questions, comments, or suggestions. OBSIDIAN CONTROL SERVICE EUROPE Monday - Friday 08:30 to 17:00 CET +31 45 546 85 63 | support@obsidiancontrol.com OBSIDIAN CONTROL SERVICE USA Monday - Friday 08:30 to 17:00 PST...
-
Page 7: Limited Warranty
Obsidian Control Systems factory unless prior written authorization was issued to purchaser by Obsidian Control Systems; if the product is damaged because not properly maintained as set forth in the product instructions, guidelines and/or user manual. - Page 8 (including negligence), misrepresentation, strict liability, breach of warranty of Elation or Obsidian Control Systems or any supplier, and even if Elation or Obsidian Control Systems or any supplier has been advised of the...
- Page 9 L I M I T E D W A R R A N T Y ( U S A O N LY ) WARRANTY RETURNS: All returned service items, whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number.
-
Page 10: Safety Guidelines
This device is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. OBSIDIAN CONTROL SYSTEMS is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. - Page 11 S A F E T Y G U I D E L I N E S Do not expose the device to rain or moisture. Refer all service to a qualified technician. Do not modify the device or install other than genuine Netron parts. CAUTION: Risk of Fire and Electrical Shock.
-
Page 12: Overview
O V E R V I E W The NETRON BS10 is an elegant wall station for cue or preset recall from the EN12i EtherDMX Node. 10 Backlit and numbered buttons provide easy feedback, and the RJ45 connection combines power and data for simple and efficient connectivity to the NETRON node over standard CAT5 wiring. - Page 13 O V E R V I E W ETHERNET DATA CONNECTION The Ethernet cable is connected on the back of the BS10 device. The BS10 employs a proprietary data protocol, rendering it incompatible with conventional Ethernet devices such as switches or personal computers.
-
Page 14: Installation Instructions
I N S TA L L AT I O N I N S T R U C T I O N S DISCONNECT POWER BEFORE PERFORMING ANY MAINTENANCE! ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. Device MUST be installed following all local, national, and country commercial electrical and construction codes and regulations. - Page 15 I N S TA L L AT I O N I N S T R U C T I O N S All wiring and connections must be performed by a qualified electrician. Secure the cover plate to the junction box with (2x) screws.
-
Page 16: Maintenance
M A I N T E N A N C E The Obsidian Control Systems Netron BS10 is designed as a rugged device. The only required service is occasional cleaning. For other service-related concerns, please contact your Obsidian Control Systems dealer, or visit www.obsidiancontrol.com. -
Page 17: Specifications
S P E C I F I C AT I O N S CONNECTIONS: RJ45 CAT5e up to 300ft (100m) REQUIREMENTS: Compatible with NETRON EN12i PHYSICAL: Length: 1.4 in. (35mm) Width: 2.8 in. (70mm) Height: 4.5 in. (114mm) ELECTRICAL: 12V (from EN12i) ORDERING: INCLUDED ITEMS: Netron Decora 1-Gang wall plate (US Model) -
Page 18: Dimensions
D I M E N S I O N S 1.6in. [41.4mm] 1.8in. [46.0mm] 1.3in. [34.3mm]... - Page 19 1.3in. [34.3mm] D I M E N S I O N S 2.7in. [69.7mm] 1.3in. [34.3mm]...
