OBSIDIAN CONTROL SYSTEMS Information, specifications, diagrams, images, and instructions herein are subject to change without notice. Obsidian Control Systems logo and identifying product names and numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted. - Page 3 Energy Saving Matters (EuP 2009/125/EC) Saving electric energy is a key to help protecting the environment. Please turn off all electrical products when they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power when not in use. Thank you! Document Version: An updated version of this document may be available online.
-
Page 4: Table Of Contents
C O N T E N T S FCC Statement General Information Limited Warranty (USA Only) Safety Guidelines Overview Installation Instructions Connections Maintenance Specifications Dimensions... -
Page 5: Fcc Statement
FCC STATEMENT Please note that changes or modifications to this product that have not been expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 6: General Information
G E N E R A L I N F O R M AT I O N INTRODUCTION Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device. These instructions contain important safety and use information. UNPACKING Every device has been thoroughly tested and has been shipped in perfect operating condition. -
Page 7: Customer Support
G E N E R A L I N F O R M AT I O N CUSTOMER SUPPORT Contact your local Obsidian Controls Systems dealer or distributor for any product related service and support needs. Also visit forum. obsidiancontrol.com with questions, comments, or suggestions. -
Page 8: Limited Warranty (Usa Only)
Obsidian Control Systems factory unless prior written authorization was issued to purchaser by Obsidian Control Systems; if the product is damaged because not properly maintained as set forth in the product instructions, guidelines and/or user manual. - Page 9 Use of Software and Firmware: To the maximum extent permitted by applicable law, in no event shall Elation or Obsidian Control Systems or its suppliers be liable for any damages whatsoever (including, but not limited...
- Page 10 L I M I T E D WA R R A N T Y ( U S A O N LY ) WARRANTY RETURNS: All returned service items, whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number.
-
Page 11: Safety Guidelines
This device is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. OBSIDIAN CONTROL SYSTEMS is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. - Page 12 S A F E T Y G U I D E L I N E S DISCONNECT the device from power before removing any part, and when not in use. Use only a source of AC power that complies with local building and electrical codes and has both overload and ground-fault protection.
- Page 13 S A F E T Y G U I D E L I N E S DO NOT operate device if power cord is frayed, crimped, damaged and/or if any of the power cord connectors are damaged, and does not insert into the device securely with ease.
-
Page 14: Overview
O V E R V I E W INTRODUCTION The NETRON EP1D is a DIN-Rail Ethernet to DMX gateway with a single RDM compatible port. It is configurable via the internal web remote or the NETRON CLU tool. EP1D is powered over Ethernet or via the convenient USB-C connection. - Page 15 O V E R V I E W SOFTWARE AND OPERATION To ensure optimal setup and functionality of software features, we recommend using the NETRON CLU application, which can be downloaded from: https://obsidiancontrol.com/netron-clu The NETRON CLU application not only contains the most current firmware, but also provides a user-friendly interface for discovering, configuring, and updating NETRON devices.
-
Page 16: Installation Instructions
I N S TA L L AT I O N I N S T R U C T I O N S DISCONNECT POWER BEFORE PERFORMING ANY MAINTENANCE! ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. CAUTION WHEN POWER... -
Page 17: Din Rail Mount
I N S TA L L AT I O N I N S T R U C T I O N S DIN RAIL MOUNT This unit is designed to be DIN rail mounted in either horizontal or vertical orientation. To install the device, locate the mounting tab beneath the 3-pin Phoenix port, and pull the tab outwards. -
Page 18: Power Connections
Damage resulting from incorrect or improper connection is not covered under warranty. The Netron EP1D is designed for operational flexibility, supporting Power over Ethernet (PoE) for integrated setups, a DC input range of 9-48V for fixed installations, and the ability to be temporarily powered via any USB-C adapter or battery pack during setup or configuration. - Page 19 C O N N E C T I O N S USB-C Power Port Power Indicator Indicator Indicator Link Indicator Indicator Reset Indicator 3-pin Phoenix DMX/RDM Port Phoenix RJ45 PoE DC Input Port DMX INDICATORS The DMX Indicator LED flashes different colors to indicate various statuses.
- Page 20 C O N N E C T I O N S DMX PORTS STATUS INDICATOR LEDS LED Color Solid Blink Routing DMX Ports Red DMX Ports Green DMX In DMX Lost DMX Out DMX Ports Blue DMX Lost Stable Flash on DMX Ports White RDM packets...
-
Page 21: Maintenance
M A I N T E N A N C E The Obsidian Control Systems Netron EP1D is designed as rugged, roadworthy device. The only required service is occasional cleaning. For other service-related concerns, please contact your Obsidian Control Systems dealer, or visit www.obsidiancontrol.com. -
Page 22: Specifications
S P E C I F I C AT I O N S Mounting DIN Rail mounted horizontally or vertically Front Reset button and ID button USB-C power option (5V, 2A) (4x)LED indicator RJ45 Gigabit Ethernet (POE) Phoenix 9-48V DC Input Bottom 3pinPhoenix DMX/RDM optically isolated port Bidirectional for DMX In and Output... -
Page 23: Dimensions
D I M E N S I O N S 3.4in (87mm) 4.2in (106mm)
