- Page 1 Type 2933, 2934, 2935, 2973, 2974, 2975 2/2-way-diaphragm valve with manually operated actuator 2/2-Wege-Membranventil mit handbetätigtem Antrieb Vanne à membrane 2/2 avec actionneur manuel Operating Instructions Bedienungsanleitung Manuel d‘utilisation...
- Page 2 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © Bürkert Werke GmbH & Co. KG, 2023 - 2024 Operating Instructions 2407/01_EU-ML_00815442 / Original DE...
-
Page 3: Table Of Contents
Type 2933, 2934, 2935, 2973, 2974, 2975 Set stroke limit ............44 OPERATING INSTRUCTIONS ..........29 Lock handwheel ............45 Symbols ..............29 Install inductive proximity switch....... 46 1.2 Definition of terms ............. 29 MAINTENANCE ..............47 INTENDED USE ..............30 Cleaning ..............47 BASIC SAFETY INSTRUCTIONS ........ -
Page 4: Operating Instructions
Definition of terms DANGER Term Definition for these instructions Warning of an immediate danger. Device Diaphragm valve Type 2933, 2934, 2935, ▶ Failure to comply will result in death or serious injury. 2973, 2974 and 2975 Ex area Potentially explosive atmosphere... -
Page 5: Intended Use
INTENDED USE BASIC SAFETY INSTRUCTIONS These safety instructions do not take into account any unforeseen The diaphragm valve Type 2933, 2934, 2935, 2973, 2974 and circumstances or events that occur during installation, operation 2975 is designed to control the flow of media. The authorised and maintenance. The operator is responsible for observing media are listed in chapter “Technical data”. - Page 6 Type 2933, 2934, 2935, 2973, 2974, 2975 Basic safety instructions ▶ The process must be restarted in a defined or controlled manner Medium may leak out if the diaphragm is worn. after an interruption in the power supply or pneumatic supply. ▶ Inspect relief bore for any medium leakages. ▶ Change the diaphragm if there is escaping medium. ▶ Operate the device only when it is in perfect condition and in accordance with the operating instructions. ▶ If the medium is hazardous, secure the area around the leak- age to prevent risks. ▶ For applications planning and operation of the device, observe the plant-specific safety regulations.
-
Page 7: General Notes
Type 2933, 2934, 2935, 2973, 2974, 2975 General notes GENERAL NOTES PRODUCT DESCRIPTION Contact addresses Structure and description Germany The device is a manually operated valve, consisting of an actuator, a diaphragm and a valve body. Bürkert Fluid Control Systems Sales Centre The manual actuator is available in the following sizes: Christian-Bürkert-Str. 13–17 Diaphragm Handwheel Desig- Handwheel Slope per... - Page 8 Valve body Port connection Port connection Fig. 4: Example of valve with tank bottom body, Type 2935 Fig. 2: Example of 2/2-way valve, Type 2933 5.2.2 Type 2934 with T-body 5.2.4 Type 2973, 2974 or 2975 Handwheel with lock Handwheel...
-
Page 9: Function
Type 2933, 2934, 2935, 2973, 2974, 2975 Product description Function 5.3.1.2 Actuator DN15 to DN50 By manually overriding the handwheel, the force is transmitted via a spindle and the valve is opened or closed. The medium in the valve body is either approved or blocked off. Turning the handwheel anticlockwise opens the valve, turning it clockwise closes it. To protect the actuator, we recommend not closing the actuator with more force than is required to close the valve tightly. -
Page 10: Product Identification
Type 2933, 2934, 2935, 2973, 2974, 2975 Product description Product identification 5.4.2 Labelling on forged steel valve body 5.4.1 Type label XX F D-74653 Ingelfingen XXXXXXXX/XXX 1.4435/316L(VS) XXXX TYP 2933 DN15 EA PN16/CWP150 XXXXXX Tmed: -10...+130°C NO21 S/N: 170492 W3XAG... - Page 11 Type 2933, 2934, 2935, 2973, 2974, 2975 Product description 5.4.3 Labelling on the cast valve body 5.4.4 Labelling on tube valve body 1.4435 316L(VP) XXXXXXXX PN16 / CWP150 XXXXXXXXXX XXXXXXXX / XXX XXXX / XXXXXX Fig. 10: Labelling on tube valve body Fig.
-
Page 12: Technical Data
Type 2933, 2934, 2935, 2973, 2974, 2975 Technical data TECHNICAL DATA Port connections valve body Stainless steel valve body Welded connection Standards and directives Clamp connection The device complies with the valid EU harmonisation legislation. Threaded connection In addition, the device also complies with the requirements of the Flange connection laws of the United Kingdom. - Page 13 Type 2933, 2934, 2935, 2973, 2974, 2975 Technical data 6.4.2 Permitted medium pressure Medium temperature for diaphragms EPDM (AD) –10...+143 °C Permitted medium pressure plastic valve body depending on medium temperature: steam sterilisation up to +150 °C for 60 min FKM (FF) 0...+130 °C no steam, dry heat up to +150 °C for 60 min PTFE (EA) –10...+130 °C to DIN EN ISO 16138 steam sterilisation up to +140 °C for...
-
Page 14: Installation
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation INSTALLATION Maximum permitted medium pressure The values are valid for valve bodies made from: DANGER • Plastic, • Stainless steel: block material, forged or casted and tube Risk of injury due to high pressure and escaping medium. ▶ Switch off the pressure before working on the device or valve body. system. Vent or empty the lines. Diaphragm size... -
Page 15: Information For The Correct Installation Position
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Information for the correct • The marking on the port connection of the valve body serves as an orientation aid. The marking must point upwards. installation position • The actual self-draining angle must be set with a suitable mea- Depending on the valve body, the installation position of the dia- suring tool. phragm valve is different. • For valve bodies without angle information, you can find the Installation for leakage detection: self-draining angle on the internet: country.burkert.com/Type/ Manuals/Supplementary information One of the relief bores in the diaphragm bonnet for moni- “Angle information for self-drainage of diaphragm valves”. -
Page 16: Preparatory Work
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Preparatory work 7.1.2 Installation position of T-body The following installation positions are recommended for the instal- → Clear impurities from pipes (seal material, metal chips, etc.). lation of the T-valve in circular pipes: → Support and align pipes. When medium is fed: When removing a medium: Device with adhesive or welded connection: The actuator and diaphragm must be dismantled before welding or bonding the valve body. -
Page 17: Install Device
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Install device For information on containers and instructions for welding, refer to the ASME VIII Division I standard. Check the batch NOTE number indicated on the manufacturer’s certificate 3.1 The following must be heeded when installing the device in supplied before starting welding work. the system: ▶ The device and relief bore must be accessible for inspections Observe the applicable laws of the country with regard to and maintenance work. the qualification of welders and the execution of welding work. - Page 18 Type 2933, 2934, 2935, 2973, 2974, 2975 Installation 7.4.2 Tightening torques Diaphragm Tightening torques [Nm] size VS, VG, PP, PVC-C, VA, VP (nominal PVC-U, PVDF Body reinforcement diameter EPDM/ PTFE EPDM/ PTFE Fig. 14: Body reinforcement for PP variants (DN15, DN20, DN25) →...
-
Page 19: Set Stroke Limit
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Set stroke limit → Mount handwheel on actuator. The square on the spindle and the hexagon head of the nut must be correctly aligned to the The stroke limit can be set optionally. geometry of the handwheel so that they fit into each other. 7.5.1 Set minimum stroke limit, Type 293x NOTE A minimum stroke limit can be set for Types 2933, 2934 and 2935. -
Page 20: Lock Handwheel
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Lock handwheel → Move the valve to the desired maximally open position. → Loosen the screw on the handwheel and remove the The handwheel lock option is available for Type 2973, 2974 and handwheel. 2975 to provide protection against accidental or unauthorised operation of the valve (from diaphragm size DN15 to DN50). The... -
Page 21: Install Inductive Proximity Switch
Type 2933, 2934, 2935, 2973, 2974, 2975 Installation Signal position open: The locking pin has a bore (Ø 3.8) and can be secured against unauthorised use with a padlock (not included in → With the valve open, screw in the inductive proximity switch scope of delivery). -
Page 22: Maintenance
Type 2933, 2934, 2935, 2973, 2974, 2975 Maintenance MAINTENANCE 8.2.2 Inspection intervals → After the first steam sterilisation, or when required, retighten DANGER fastening screws crosswise. Risk of injury due to improper maintenance. → After a maximum of 10 switching cycles check the diaphragm ▶ Switch off the pressure before working on the device or for wear. -
Page 23: Changing The Diaphragm
Type 2933, 2934, 2935, 2973, 2974, 2975 Maintenance Changing the diaphragm The diaphragm is attached in different ways: Diaphragm Fastening types for diaphragm size PTFE/advanced PTFE EPDM/FKM/GYLON® Handwheel (nominal diameter Buttoned Bayonet catch Fastening nuts Diaphragm Bayonet catch Threaded connection Fastening screws Tab. 4: Fastening types for diaphragm →... - Page 24 Type 2933, 2934, 2935, 2973, 2974, 2975 Maintenance NOTE Observe tightening torques in accordance with the tables in chapter “7.4.2”. Damage to the diaphragm with threaded connection due to energised pin. 8.3.1 Switch between PTFE and EPDM ▶ First screw on the diaphragm hand-tight, then loosen it by diaphragm one-half turn anticlockwise.
-
Page 25: Spare Parts
Type 2933, 2934, 2935, 2973, 2974, 2975 Spare parts SPARE PARTS NOTE Damage to the diaphragm with threaded connection due to CAUTION energised pin. ▶ First screw on the diaphragm hand-tight, then loosen it by Risk of injury and/or damage due to incorrect parts. -
Page 26: Ordering Spare Parts
Type 2933, 2934, 2935, 2973, 2974, 2975 Spare parts Ordering spare parts 9.1.2 Ordering diaphragm The diaphragm can be ordered according to the table below. It is 9.1.1 Ordering actuator labelled with a material code that specifies it. The material code → Open country.burkert.com. is located on the identification tab or, in the case of two-part dia- phragms, on the tab of the backing diaphragm and the diaphragm → Enter the article number from the type label in the search bar. shield (see “Fig. 20”). The material code may differ for older mate- →... - Page 27 Type 2933, 2934, 2935, 2973, 2974, 2975 Spare parts Advanced PTFE/EPDM Laminate made from Diaphragm EPDM PTFE/EPDM (EU*) GYLON® and EPDM (ER*) size (AD*) (FF*) (EA*) Article Material Article Material Article Material Article Material Article Material number code number code...
-
Page 28: Transportation, Storage, Disposal
Type 2933, 2934, 2935, 2973, 2974, 2975 Transportation, storage, disposal 9.1.3 Order spare parts in eShop TRANSPORTATION, STORAGE, DISPOSAL → Open Bürkert eShop on the internet. → Log in or register. CAUTION → Find spare parts via the article number. This can be seen on Risk of injury due to heavy device. - Page 30 www.burkert.com...
