Cleaning and Maintenance:
Replacing the light modules
• You cannot replaced the light bulbs, the entire light module has to be replaced.
• When changing the light modules, the contacts are live.
• Before changing the light module(s), unplug the appliance from the mains or
switch off the circuit breaker in the fuse box.
• Only use a light module that is the same type and same power (details below),
please contact customer services on 0345 208 8750 or
mda.russellhobbs.com
Diameter
70mm
1. Remove the grease filter and carefully remove the 2 screws from each side on
the opening (a cross headed screwdriver will be needed to remove the screws).
2. Lower the control panel at the front by carefully pulling it downwards. You can
now access the light module and terminals.
Max Power Voltage
1.5W DC 12V
- 21 -
visit
Lamp cap ILCOS D code
- DSR-1.5-5-7
