- Page 1 RHFGCH601 SS/B Operating Manual RHFGCH901 SS/B COOKER HOOD REGISTER YOUR WASH MESH FILTER Remove & wash the mesh filter with FREE 1 YEAR hot water and liquid detergent at least every 3 months GUARANTEE REPLACE FILTERS TODAY MONTHS If recirculating air, replace charcoal filters every 6 months...
-
Page 2: Guarantee
P a g e GUARANTEE At Russell Hobbs, we take all our customer feedback seriously. 0345 208 8750 Feel free to contact our Product Care Team, on who will be more than happy to assist you. This product is guaranteed for 12 months from the date of the original purchase. -
Page 3: Table Of Contents
Safety Instructions Parts List Dimensions Installation Location Installation Location & Fitting Installation – Fitting Installation – Ventilation/Recirculation Installation – Chimney Cover Usage Instructions Cleaning Instructions Charcoal Filter Installation/Replacement LED Module Replacement Problem Solving Technical Specification GT Series Cooker Hoods Revision 2.0... -
Page 4: Safety Instructions
• Do not open the mesh filter during operation. • Do not use the appliance without the filters in place. • Keep the appliance and plug away from water; do not allow it to get wet. GT Series Cooker Hoods Revision 2.0... - Page 5 • Never place your fingers or other objects into any part of the appliance. Be aware that loose clothing or hair may become trapped if improperly used. • ALWAYS ensure correct wall fittings are used. GT Series Cooker Hoods Revision 2.0...
-
Page 6: Parts List
Hood fixing bracket 6) Charcoal Filters (Pack of 2) 7) Screws 5x50 (7 pieces) Chimney Fixing Bracket (2 Pieces) *Always ensure correct wall plug fixing is used for the wall type GT Series Cooker Hoods Revision 2.0... -
Page 7: Dimensions
WARNING – Ensure minimum clearance levels are maintained as outlined in the diagrams above. We recommend the use of a spirit level and square to gauge the surface before installing, to ensure a flush fit. GT Series Cooker Hoods Revision 2.0... -
Page 8: Installation Location
P a g e INSTALLATION – LOCATION Chimney 400+390 40-377 GT Series Cooker Hoods Revision 2.0... -
Page 9: Installation Location & Fitting
• Fix a Chimney fixing bracket [13] with 2 screws [7] (5 x 50) at the horizontal line B. • Fix a Chimney fixing bracket[13] with 2 screws [7] (5 x 50) at the horizontal line A. *Always ensure correct wall plug fixing is used for the wall type GT Series Cooker Hoods Revision 2.0... -
Page 10: Installation - Fitting
• Fix the Chimney fixing bracket [13] with 2 screws [7] (5 x 50) at the horizontal line A. • Affix the glass to the top of the main unit with 4x screws [9] GT Series Cooker Hoods Revision 2.0... -
Page 11: Installation - Ventilation/Recirculation
• Remove charcoal filters if present. Internal Recirculation When installing for internal recirculation, the flexible pipe is not required to be installed. Ensure charcoal filters are installed (see page 15) and maintained to schedule in this manual. GT Series Cooker Hoods Revision 2.0... -
Page 12: Installation - Chimney Cover
• Fix the upper chimney onto the bracket [13] with 2 screws [10] (4.2 x 9.5) supplied with the hood. • Fix the chimney fixing bracket [13] with 2 screws [7] (5x50) at the horizontal line B. GT Series Cooker Hoods Revision 2.0... -
Page 13: Usage Instructions
WARNING – Washing the aluminium filter in a dishwasher may damage the filter. NOTICE – If using charcoal filters for internal circulation, these cannot be washed and must be replaced every 3-6 months. GT Series Cooker Hoods Revision 2.0... -
Page 14: Cleaning And Maintenance
Charcoal Filters These filters are not washable and cannot be regenerated, and must be replaced approximately every 3-6 months of operation, or more frequently with heavy usage GT Series Cooker Hoods Revision 2.0... - Page 15 • Remove the metal grease filters. • Remove the saturated activated charcoal filter by twisting anti- clockwise, and pulling. • Fit the new filters by pushing and twisting clockwise. • Replace the metal grease filters. GT Series Cooker Hoods Revision 2.0...
-
Page 16: Led Module Replacement
When changing the light modules, the contacts are live. Before changing the light module(s), unplug the appliance from the mains or switch off the circuit breaker in the fuse box. ILCOS D Diameter Voltage Power code DSR-1.5- 70mm 1.5W DC 12V GT Series Cooker Hoods Revision 2.0... -
Page 17: Problem Solving
If you are still experiencing difficulties with the appliance please contact us BEFORE returning the appliance to the retailer it was purchased from: Website: mda.russellhobbs.com Telephone: 0345 208 8750 Address: Product Care Customer Service, Green Bank Business Park, Hindley Green, Wigan, WN2 4AY GT Series Cooker Hoods Revision 2.0... -
Page 18: Technical Specification
440 - 820 mm x 900mm x 500mm Wattage 108W Operating Voltage / Frequency AC220-240V, 50Hz Current 0.8A Max. Extraction Rate 440m3/h Energy Usage 54kWh/a Energy Efficiency Rating Noise level 65dB Extraction Rating Light Rating Filtration Rating GT Series Cooker Hoods Revision 2.0... - Page 19 Additional cover can be purchased through the website. REGISTER REGISTER ONLINE BY PHONE Visit our website to Call our friendly Product Care register your full parts team. and labour guarantee online. mda.russellhobbs.com 0345 208 8750 GT Series Cooker Hoods Revision 2.0...
- Page 20 Made by Product Care Trading Limited under license from Spectrum Brands (UK) Limited. Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd. Russell Hobbs Support: call 0345 208 8750 or visit mda.russellhobbs.com...
